SERVICE MANUAL
Ver. 1.0 2005. 02
• SS-GNX60 is front speaker system in
MHC-GNX60.
• SS-GNX66 is front speaker system in
MHC-GNX66.
• SS-GNX88 is front speaker system in
MHC-GNX77/GNX88.
• SS-GNX100 is front speaker system in
MHC-GNX70/GNX80/GNX100/GX9900.
Sony Corporation
9-879-462-01
Audio Group
2005B02-1
Published by Sony Engineering Corporation
© 2005.02
Photo : SS-GNX100
SPECIFICATIONS
• SS-GNX100 (MHC-GNX100/GNX80/GNX70/GX9900)
SS-GNX60 (MHC-GNX60)
Speaker system
2-way, 2-unit, bass-reflex type
Speaker units
Woofer:
20 cm, cone type
Tweeter:
2.5 cm, horn type
Nominal impedance
6 ohms
Dimensions (w/h/d) (Approx.)
280 x 416 x 305 mm
Mass (Approx.)
6.5 kg net per speaker
• SS-GNX88 (MHC-GNX88/GNX77)
SS-GNX66 (MHC-GNX66)
Speaker system
2-way, 2-unit, bass-reflex type, magnetically
shielded
Speaker units
Woofer:
20 cm, cone type
Tweeter:
2.5 cm, horn type
Nominal impedance
6 ohms
Dimensions (w/h/d) (Approx.)
280 x 416 x 305 mm
Mass (Approx.)
7.1 kg net per speaker
Design and specifications are subject to change without notice.
SS-GNX60/GNX66/
GNX88/GNX100
SS-GNX60/GNX66/GNX88/GNX100
Australian Model
SPEAKER SYSTEM
US Model
SS-GNX100
E Model
SS-GNX60/GNX100
