  • Page 1 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A...
  • Page 2 "as is". Should the programs prove defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User’s Manual of PLANET Z-Wave Ceiling-mount Smoke Detector Model: HZS-300 Rev: 1.00 (October, 2015)

  • Page 4: Table Of Contents

    Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Table of Contents Chapter 1.  Product Introduction ..............5  1.1 Package Contents ................5  1.2 Overview..................... 5  1.3 Specifications..................7  Chapter 2.  Hardware Interface................ 8  Chapter 3.  Z-Wave Device Setting ............... 10  3.1 Configuring Z-Wave Device via HAC-1000........10 ...

  • Page 5: Chapter 1. Product Introduction

    Safeguarding Homes Conveniently via the Multi-functional Sensor PLANET HZS-300, a Z-Wave 4-in-1 Multi Sensor, has four sensors integrated into one device, thus enabling you to monitor the security of doors and windows, humidifiers, lightings, and thermostats of your home at site...
  • Page 6 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A or there is a change in humidity, luminosity and temperature. It not only helps to protect homes, offices and other establishments from theft, but also helps to keep humidity, luminosity and temperature in these places within their ideal range.

  • Page 7: Specifications

    Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Getting Started is as Easy as 1-2-3 1. Via the Cloud Home App (including Home Automation Controller Pad and Control Gateway): Press Inclusion/Exclusion to include/exclude Z-Wave device. 2. On the Z-Wave device: Press the Pair button to establish a connection with the control gateway.

  • Page 8: Chapter 2.  Hardware Interface

    Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Chapter 2. Hardware Interface Model HZS-300E/HZS-300A Dimensions (W x D x H) 69 x 28 x 19 mm Weight 40g (gross weight) Front Panel LED/Test/Program Switch Sensor Interface Description Opening/Closing the door/window Tamper switch Temperature changed...
  • Page 9 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Bottom Program Switch...

  • Page 10: Chapter 3. Z-Wave Device Setting

    Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Chapter 3. Z-Wave Device Setting 3.1 Configuring Z-Wave Device via HAC-1000 Please refer to the following steps to add Z-Wave device via HAC-1000 web. 1. The default username and password are both admin. 2. Click Z-Wave.
  • Page 11 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A 4. Click Device Configuration. Step 1. Include a Z-Wave device via web. a) Go to "Z-Wave" and click "Device Configuration". b) Click” Include New Device” and the screen will appear with "Add Device: Waiting for a user action."...
  • Page 12 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Step 2. Set up the location and room for Z-Wave device via HAC-1000 web. a. Create rooms in your environment. b. Edit device. Step 3. Create a scene via web. a. Click “Create Scene” and name new scene.
  • Page 13 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A b. Select a device from this scene. c. Select ON or OFF from this scene. d. You can click “RUN” to run this scene.

  • Page 14: Configuring Z-Wave Via Smart Phone

    Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Step 4. Create trigger via web a. Click “Create a Trigger” and name new trigger. b. Select a Z-Wave device for this trigger. c. Select when it triggers, it will alarm or bypass. d. Select when it triggers, it will run which scene.
  • Page 15 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Step 1. Include a Z-Wave device via smart phone (Android/iOS). a. Register a user account. b. Setting c. Inclusion/Exclusion d. Click Inclusion to add device.
  • Page 16 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A e. The distance between HZS-300 and HAC-1000 is suggested to be in one meter. Press the program switch 3 times within 3 seconds to be included.
  • Page 17 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Step 2. Set up the location and room for Z-Wave device. a. Create rooms in your environment. b. Click “No Room” to show the device. And place the new device in a room. c. Select “Name” to name this device d.
  • Page 18 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A e. Click “Back” to save. Done successfully.
  • Page 19 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Step 3. Create a scene via smart phone. a. Click “Add” and name a new scene. b. Click “Add” to add a Z-Wave device. d. Click ON or OFF for the device you c. Select a Z-Wave device.
  • Page 20 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A e. Click “Back” to save. Done successfully.
  • Page 21 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Step 4. Create Trigger via smart phone. a. Click “Add”. b. Name this new Trigger. d. Select a mode for a Z-Wave device. e. Select a scene. c. Select the Z-Wave device and click Select the time for the trigger and next.
  • Page 22 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A g. Done successfully. h. If you enable Save and send alarm notification, when it triggers, it will have a log. You can check this in Notification History.

  • Page 23: Configuring Z-Wave Via Hts-1000P

    Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A 3.3 Configuring Z-Wave via HTS-1000P Step 1. Fill out the IP of control gateway to connect with gateway. Click the “Gateway” button. Click the magnifying glass to search the IP of gateway. Control pad found an IP of gateway.
  • Page 24 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Step 2 Include a Z-Wave device via HTS-1000P. Click the “Z-Wave devices” button Z-Wave devices to gateway. Click “Include Device” button Z-Wave device. When you see the message “Waiting for user action”, you can press the match button...
  • Page 25 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A distance between HZS-300 and HAC-1000 is suggested to be in one meter. Press the program switch 3 times within 3 seconds to be included. device added successfully, it will show the message: Command completed successfully device No.
  • Page 26 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Step 3. After including Z-Wave devices in gateway, you can create different scenes with this function. You can set scenes to control your devices in Scene mode. Click the “Scene” button. Click “Create Scene” and name the new scene.
  • Page 27 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Click the “Plus” button to add device. Select the status of device (ON or OFF). Click “All Scenes” to check the scene. Step 4 In Trigger mode, the trigger time is set. An alarm notification is sent via sensor. If a sensor is not installed, this step can be skipped.
  • Page 28 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Click “Create Trigger”. Trigger: Name this trigger. Device: Select a Z-Wave device. Mode: Select “Arm” to enable alarm. Scene: When it triggers, the fan will turn on. Optional: After triggering seconds, the fan will turn off by itself.
  • Page 29 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Step 5 After configuring this part, you can control Z-Wave devices and scenes via control pad. Click the “Control Panel” button. Click the three-line button on the upper right corner and click “Add Panel”. There are two types of panel that you can choose from.
  • Page 30 Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Click and hold for two seconds to select the device or scene. Click on the Device field. Go back to the main page and click the “Control” button. You can control scenes and devices here.

  • Page 31: Appendix A: Troubleshooting & Frequently Asked Questions

    Z-Wave 4-in-1 Multi Sensor HZS-300E/HZS-300A Appendix A: Troubleshooting & Frequently Asked Questions Features The frequency is different between Z-Wave and ZigBee. ZigBee is 2.4GHz and Z-Wave is about 900MHz. This difference between Z-Wave and ZigBee The outdoor distance is different. ZigBee is 10~75 meters and Z-Wave is about 30 meters.
