IPC HD-IP CAMERA User Manual

IPC Fast Operation
User Manual
HD-IP CAMERA
Please refer to the complete User manual
for more information from the CD.
Features
Δ Weatherproof IR Camera IP66
Δ Advanced H.264 High profile compression
Δ Support browsers: IE
Δ Support several servers, IP address, DDNS, FTP,SMTP
Δ Support single, dual, three streams
Δ Support iPhone, iPad, Android remote monitor
Δ Support connect to NVR
Δ Support ONVIF2.0
Δ Reliability and compatibility
Δ Low streams and high resolution image
Connection
DC12V
RJ45
switch/router/FOT
IPC
PC
Network Structure
IPC-BN25W3200T
Specifications
Model IPC-BN25W3200T
Image Sensor 1/3" 2.4 Megapixel CMOS Image sensor
Resolution
1920×1080
Minimum Illumi-
nation
S/N Ratio
Focus Mode Manual Focus
Day/Night IR cut filter with auto switch, IR sensor.
1 RJ45 Ethernet interface, 10/100M adapta-
Network
Delay Within The LAN 0.3S
Frame Rate 25/30 FPS (adjustable)
Video Compres-
H.264 /JPEG
sion
Protocol RTSP/FTP/DDNS/NTP/SMTP
POE Yes(optional)
Onvif
Support Onvif 2.0（port:8999）
User Permission Multi-user Classification Management
Power/Current DC 12V/1A or POE
Consumption
3 Megapixel HD
Lens
Board Lens 3.6mm/F2.0
IR Status
IR LED: ￠5X30PCS IR range: 25M
Dimension (mm) 142(W) x 68(H) x 66(D)mm
Weight (g)
Temperature -20～55℃
Humidity 0%-90%RH,Without Condensation
NO. Name Model
1. HD-IP Camera IPC-BN25W3200T
2. CD IPC-BN25W3200T
IPC Fast Op-
NVR 3. eration User IPC-BN25W3200T
Manual
Access to the IP Cam-
era via IE
1. Use correct power supply.
2. Make sure the device IP address
is in the same LAN with the
router, the default IP address of
the IPC is 192.168.1.168.
3. Go to CD->IPCSearch.exe and
>1Lux
copy it to your computer.
4. Open IPC Search, click "Search",
>50db
you will find the device IP, and
you also can modify the IP infor-
mation, see the picture (1)
5. Factory default IP setting:
IP Address : 192.168.1.168
Subnet Mask: 255.255.255.0
Gateway: 192.168.1.1
tion
User name: admin
Password: admin
6. After modifying IP, click "Search"
again, you will find the new IP of
the your device. Double-click the
new IP, you can access to the IPC
via IE, or enter the IP Address in
the address bar of IE, then click
"Enter", the download_OCX
controls interface please see the
picture (2), Please click here
to download the OCX
controls.
7. as is shown in picture (3), Click
run, the system will automatically
download the OCX.
8. Click "yes" as the picture (4),Then
3.0W
it will install the OCX，when
complete ,Click "OK" and refresh
the page. You will enter the login
interface, as is shown in picture
(5)
9. Enter your username and pass-
word, you can start to access and
control your IP Camera.
500g
Access to the IP Cam-
era via HSCMS
Go to CD, find "HerospeedCMS.exe.
Number (pcs)
" Copy "HerospeedCMS.exe " to
your computer and install it, then
1
run it. See the picture (6):
1
. Device list:
1
See the picture (7):
Here you can manually add your
1
IP Cameras. Also can click
"Search device" to search your IP
Cameras in local area network.
You can add different areas to
manage your device. Below the
area you can search all the
devices in LAN, then check the
IP info to add the camera.
See the picture (8):
You also can click "Manually
add" to enter the IP Info manu-
ally. See the picture (9):
Then you can view the images
and remote config the IP Cam-
era, such as Alarm, Video, Net,
Camuser, Date, etc. Please refer
（1）
to Herospeed CMS Customer
Manual for detail.
2. View the images
After adding the devices, you
can see the devices in "Device
List" of the main interface, you
can double _click the device to
control it to play or stop.
Access to the IP Camera
via Android mobile
（2）
Search and download the
surveillance software "Danale" to
your mobile from electronic mar-
kets or the Mobile Assistant, then
install it. Then you can see the icon
of the software ,click it to
（3）
run.
1. Login
The picture (10) shows the login
interface:
2. List
As is shown in picture (11)
2.1 Add Camera
（4）
Click "add camera", as is shown
in picture (12):
Edit the camera name, input the
username, password, you can
input the camera ID manually or
scan the QR code directly. Click
"finish" to finish and save it.
3. Video Mode
Click to set the Video
Mode.
（5）
4.Settings
Click to set the IPC.As is
shown in picture (13):
4.1 User name password manage-
ment
Here you can edit the device
name, username and password.
（6）
4.2 NetWork Settings
Here you can set the local
network and WIFI according to
your need.
4.3 Basic information
Here you can view the basic
information of the IPC, including
device information, storage
information, etc.
（7）
(8)
(9)
(10)
(11)
(12)
(13)
