HEIL N4H3 Product Specifications

EFFICIENT 13 SEER 3−PHASE HEAT PUMP
ENVIRONMENTALLY SOUND R−410A REFRIGERANT
2−1/2 THRU 5 TONS SPLIT SYSTEM
208 / 230 Volt, 3−phase, 60 Hz
460 Volt, 3−phase, 60 Hz
REFRIGERATION CIRCUIT
S
Scroll compressors on all models
S
Crankcase Heaters factory installed on all models
S
Suction line accumulator factory installed
S
Bi−flow filter−drier included for field installation
S
Integrated solid state control with Time−Temperature Defrost
S
High and Low pressure switches
S
Copper tube / aluminum fin coil
EASY TO INSTALL AND SERVICE
S
Phase monitor board detects issues with 3−phase line
voltage
S
Easy access service valves on all models
S
Innovative control box design
S
External high and low refrigerant service ports
S
Only two screws to access control panel
S
Factory charged with R−410A refrigerant
BUILT TO LAST
S
Baked−on powder coat finish over galvanized steel
S
Post−painted (black) coil fins
S
Coated, weather−resistant cabinet screws
S
Coated inlet grille with 3/8" (10mm) spacing for extra
protection (hail guard)
WARRANTY
S
5 year compressor limited warranty
S
1 year parts limited warranty
Model
Voltage
Number
N4H330GHE 208/230
N4H336GHE 208/230
N4H336GLE 460
N4H342GHE 208/230
N4H348GHE 208/230
N4H348GLE 460
N4H360GHB 208/230
N4H360GLB 460
Size Nominal
Min. Circuit
(tons) Btu/hr Ampacity
2−1/2 30,000 13.6
14.1
3 36,000
7.9
3−1/2 42,000 17.8
18.5
4 48,000
9.0
21.1
5 60,000
10.4
Specifications subject to change without notice.
Product Specifications
Use of the AHRI Certified TM Mark indicates a
manufacturer's participation in the program. For
verification of certification for individual products,
go to www.ahridirectory.org .
Operating Dimensions
Max. Fuse
height x width x depth
or Breaker
in. (mm)
28-15/16 x 31-3/16 x 31-3/16
20
(735 x 792 x 792)
20
32-15/16 x 31-3/16 x 31-3/16
10
(821 x 792 x 792)
28-15/16 x 31-3/16 x 31-3/16
30
(735 x 792 x 792)
30
35-3/4 x 31-3/16 x 31-3/16
10
(908 x 792 x 792)
30
28-15/16 x 35 x 35
15
(735 x 889 x 889)
N4H3
Ship / Operating
Weight lbs. (kg)
180 / 146
(82 / 66)
178 / 152
(81 / 69)
229 / 193
(104 / 88)
251 / 216
(114 / 98)
282 / 250
(128 / 113)
506 11 3101 04 March 2011
