iWB installation Manual
• Do not expose this whiteboard to rain or
moisture in order to reduce the risk of fire or
electric shock.
• Do not expose this whiteboard to fire,
electric shock and long time direct sunlight.
• Use appropriate expansion bolts to fix the
device to the wall.
• Do not stare directly at the light from the
projector. Especially the kids should be
warned about this.
• Make sure the USB connection between this
device and computer is safe.
• Use only the USB cable provided with the
whiteboard. Other cables might not work
properly with this product.
• Do not touch, cut or scratch the panel and
frame with sharp or hard objects. Do not
drill holes or nail in any place of the product
since it might damage the device.
Advertisement
Summary of Contents for ligra Luxiboard 6 TOUCH
- Page 1 iWB installation Manual • Do not expose this whiteboard to rain or • Make sure the USB connection between this moisture in order to reduce the risk of fire or device and computer is safe. electric shock. • Use only the USB cable provided with the •...
-
Page 2: General Informations
1. General informations 1.1 Introduction This interactive whiteboard uses IR scan and sensor technology. It works seamlessly with a projector and computer as a large touch display. Any projected image can be directly operated by pens or fingers. Thus, it provides the ideal interactive platform for presentations and lecturers. Writing: the user can write and draw with pens or fingers directly on the display panel and show his/hers writing during speech and lecture. - Page 3 2. iWB installation 2.1 Wall mounting There are 4 pieces of whiteboard wall mount brackets in the accessory box as follow. Place them on the wall according to the position of the hooks on the back of whiteboard and fix them with expansion bolts.
-
Page 4: How To Install Software
3. How to Install Software 3.1 Driver and software installation Before software installation, exit the antivirus or virus protection softwares in your computer. The software installation instructions in this manual are based on Microsoft Windows 7 system. There is an installation disc in the accessory box. Insert the installation disc and you can see the instructions. - Page 5 4. Calibration Follow these steps: Step 1 Connect all necessary devices and make sure the whiteboard service program has been auto runed once the computer is power on. If not, click “Start > All Programs > HHAP > WhiteBoard Driver > WhiteBoard Driver” and run the whiteboard service program. Step 2 Wait for seconds and the whiteboard driver icon in taskbar notification area will turn green from red and this indicates that the device and drive are connected.
- Page 6 4. Calibration Click “Calibration” and the whiteboard will be in calibration interface as follows: Step 4 Vertically touch the centre of the flashing “+“ with the interactive whiteboard pen tip until the flashing “+“ move to the next calibration point and thus one point is calibrated. Follow the instructions in the calibration interface and complete the calibration of other points thus the interactive whiteboard calibration is finished.
