Summary of Contents for XXL INSIDE XA1000
- Page 1 Italian Style STEREO POWER AMPLIFIER CLIP LIMIT OPERATING PROTECTION 0dBV POWER ON 0dBV ENGLISH USER'S MANUAL Italian Style...
-
Page 2: Safety Related Symbols
Protective Grounding Make sure to connect the protective grounding to prevent any electric shock before turning ON the apparatus. 1 XA500/XA1000 Never cut off the internal or external protective grounding wire or disconnect the wiring of protective grounding terminal. Operating Conditions... - Page 3 In the best way, conscious that you are our best richness. Thank you very much. XXL AUDIO TEAM 2 XA500/XA1000 and your comments. staff, there to make possible the realization USER'S MANUAL...
-
Page 4: Table Of Contents
1. INTRODUCTION... 2. FEATURES ..4 3. CONTROL ELEMENTS 3.1 The Front Panel 3.2 The Rear Panel 4. APPLICATION 4.1 Stereo Mode 4.2 Bridge Mode 5. TECHNICAL SPECIFICATIONS 6. WARRANTY ... 3 XA500/XA1000 ...4 ...5 ...8 ...11 ...12 USER'S MANUAL... -
Page 5: Features
Solid and durable, can be mounted into a cabinet. User-controllable clip limiter. 2x300 Watts EIAJ on 4 ohms for XA500. 2x500 Watts EIAJ on 4 ohms for XA1000. Stereo (dual-channel), or bridge mono operating modes. Balanced XLR inputs / parallel outputs to ensure noiseless long wiring. -
Page 6: Front Panel
When at protection status, the Led is off. Power Led This Led lights up when the unit is powered. Level Control for Channels 1 & 2 Adjust the output signal level to avoid signal distortion. 3.2 Rear Panel 5 XA500/XA1000 CLIP LIMIT OPERATING PROTECTION 0dBV... - Page 7 - Stereo In this mode, Channel 1 and Channel 2 operate independently ( just as traditional stereo amplifier). The signal input into channel 1 can be output from channel 1 only, similarly, the signal input into channel 2 can be output from channel 2 only.
-
Page 8: Application
4.1 Stereo Mode In this mode, Channel 1 and Channel 2 operate independently ( just as traditional stereo amplifier). The signal input into channel 1 can be output from channel 1 only, similarly, the signal input into channel 2 can be output from channel 2 only. - Page 9 1 and 2 simultaneously. The volume of channel 1 or channel 2 can be controlled separately. MODE Release this button MODE Release this button 8 XA500/XA1000 Input Connector Balanced INPUT TIP/PIN 2 RING/PIN 3 SLEEVE/PIN 1 TIDE...
- Page 10 MODE Release this button MODE Release this button 9 XA500/XA1000 Input Connector Balanced INPUT POWER OUTPUTS TIP/PIN 2 RING/PIN 3 SLEEVE/PIN 1 TIDE POS NEG POS NEG BRIDGE MODE LIMITER STEREO PARALLEL INPUT BRIDGE POS NEG OUTPUT OUTPUT1 TIP/PIN 2...
-
Page 11: Bridge Mode
2 should be turn down to smallest (turn the volume control at counterclockwise). control of channel 1 is used to control the volume of whole system. MODE Release this button Input Connector MODE Release this button 10 XA500/XA1000 Input Connector Balanced INPUT TIP/PIN 2 RING/PIN 3 SLEEVE/PIN 1... -
Page 12: Technical Specifications
Input Sensitivity @ 4 ohms Input Clipping Input Impedance Controls Indicators (1 per channel) Connectors, each channel Cooling Load Protection Power Requirements Dimensions Net Weight 11 XA500/XA1000 XA500 190W 300W 600W <0.05% 20Hz-20KHz 1dB, -3dB points: 10Hz-60KHz >300 at 8ohms 102dB 40x (32dB) 1Vrms... -
Page 13: Warranty
3.6 This warranty gives you the specific rights, and these rights are compatible with the state laws, you may also have other statutory rights that may vary from state to state. 12 XA500/XA1000 USER'S MANUAL... - Page 14 Web site: www. x-x- l.it E-mail: info@ x-x -l.it New materials and design refinements are introduced into existing products without previous notice. Present XXL Systems may differ in some respects from those presented in this brochure. USER'S MANUAL XA500/XA1000 NF01809-1.0...
