SOME TYPICAL SET-UP EXAMPLES:
Modelling System/Pre-amp/Multi FX in Mono To Single Cab
POWER
MATRIX
on
NB: No need to connect
a load to Output B
Modelling System/Pre-amp/Multi FX in Mono To Two Cabs
POWER
MATRIX
on
Main Mono/L Out to
Input A on Matrix Amp
Matrix mode
GT FX
switch set to
POWER AMPLIFIER
A B
SIGNAL SIGNAL
CHANNEL LEVELS
Stereo
Matrix Output A to Mono Input of Cab
Main Mono/L Out to
Input A on Matrix Amp
Matrix mode
GT FX
switch set to
POWER AMPLIFIER
A B
SIGNAL SIGNAL
CHANNEL LEVELS
Parallel
Matrix Output A to Mono Input of Cab 1
Matrix Output B to Mono Input of Cab 2
