Summary of Contents for Point Source Audio CM-i3
- Page 1 CM-i3 Intercom Headset Earphone Replacement / Installation...
- Page 2 Measure your desired cable “drop” from the ear hook, allowing enough cable length for a taut but comfortable fit. Align the earphone cable to the ear hook groove to prepare for installation.
- Page 3 Use the “wide” side of the installation tool to insert the cable into the ear hook groove. Continue to install the cable along the ear hook through one side of the headband. Repeat for the second side. Both left and right cables should be installed and dressed down the center of the headband.
- Page 4 Attach your earphone connector to the female end of the earphone jack.
- Page 5 Gather both the microphone and earphone cables and insert into the opening of the installation tool. Insert the small end of the tool into the cable wrap.
- Page 6 Push the top side of the installation tool through the cable using care to hold the cables and the cable wrap together to avoid separation.
- Page 7 Slowly, continue to push the installation tool along the cable wrap until all the cables are fully installed inside the cable wrap.
