General Description
The ACS-101 (Antenna Combiner Splitter 10 to 1) is an
amplified and filtered broadband splitter-combiner. It allows up
to 10 base stations to use only one (1) transmit and one(1)
receive antenna.
The antenna combiner section contains innovative hybrid
coupling, amplifying and matching technology to combine 10
transmitters to one (1) output with very low intermod distortion.
Specifications
Overall
Antenna Connectors....................................................................................................................................Standard TNC Receptacles
AC Input Power .....................................................................................................................................100–120VAC, 60Hz, 6A max.
AC Input Fuse ............................................................................................................................................................. 10A, 250V, 3AG
DC Output Power...................................................................................................................................... 12VDC, 5A for each output
DC Output Jacks .......................................................................................................................................Two, 5.5mm x 2.1mm Jacks
DC Output Fuses............................................................................................................................................ 5A, 250V, 5mm x 20mm
Size..................................................................................................... 3.50" (88.9mm) H x 16.75" (426mm) W x 14.63" (372mm) D
Weight ................................................................................................................................................................... 10lbs., 4oz. (4.65kg)
Antenna Splitter
Frequency Range..............................................................................................................................................................614–746MHz
Output IP3 ................................................................................................................................................................ Greater than 30dB
Net Gain ............................................................................................................................................................................. 0dB, typical
Noise Figure.................................................................................................................................................................. less than 4.5dB
Minimum Isolation....................................................... 20dB between adjacent ports; greater than 20dB between non-adjacent ports
Antenna Combiner
Frequency Range..............................................................................................................................................................470–608MHz
Net Gain ................................................................................................................................................................................. 0dB max.
Noise Figure...................................................................................................................................................................... 10dB typical
Output IP3 ......................................................................................................................-55dBc @ +17dBm input on each transmitter
Bosch Security Systems, Inc.
Instruction Sheet
ACS-101
Amplified Broadband UHF Combiner-Splitter
Installation Sheet
The antenna splitter section has broadband input filtering and
amplification to maintain signal levels through the splitters.
High output isolation between pots is also achieved.
The industrial strength power supply of the ACS-101 supplies
voltage and current to two (2) outputs on the product. Each
output can supply up to 5Amps at 12VDC.
IMPORTANT:
Using products that deliver more than
50mW of transmit power to the ACS-101
is not recommended, and may cause
damage to the unit or accompanying gear.
F.01U.XXX.XXX Rev. 0X
Advertisement
Table of Contents
Summary of Contents for RTS ACS-101
-
Page 1: Specifications
High output isolation between pots is also achieved. The ACS-101 (Antenna Combiner Splitter 10 to 1) is an amplified and filtered broadband splitter-combiner. It allows up The industrial strength power supply of the ACS-101 supplies to 10 base stations to use only one (1) transmit and one(1) voltage and current to two (2) outputs on the product. -
Page 2: Instruction Sheet
Instruction Sheet ACS-101 Product Features Ideal for use with BTR-1, BTR-500, BTR-600, BTR-700 wireless intercom systems. • Two (2) power outputs to supply up to 10 transceivers (5 on each daisy-chain run) which makes large • systems easier to implement Standard IEC 320 power input connector •... - Page 3 RECEIVE 5A SLOW BLOW ANTENNA DC OUT 12V 5A ACS-101 Rear View FIGURE 5. DC Outlet Fuses 5Amp, SlowBlow, 250VDC. Size 3AG IEC Power Inlet with Fuse IEC-320 power inlet with a 10Amp, 250VDC Fuse. Size is 5mm by 20mm.
-
Page 4: System Configuration
Instruction Sheet System Configuration Figure 6 illustrates the typical system configuration using the ACS-101 to support 10 BTR-1 base stations. RECEIVE TRANSMITTER ANTENNA ANTENNA Power Power Power Power Power Power Power Power Power Power Power FUSE DC OUT 5A SLOW BLOW... -
Page 5: Antenna Requirements
Instruction Sheet Antenna Requirements The ACS-101 may be used with a variety of antennas. For best results, use a pair of ALP-450 directional log periodic antennas (See Figure 5Figure 2.) or, the ALP-600 Bi-directional log periodic antenna (See Figure 1). -
Page 6: Antenna Placement For Optimum Range And Rack Mounting
Rack Mount Brackets FIGURE 7. Rack Mounting Rack mount brackets are supplied with the ACS-101. To attach the brackets, do the following: Align the rack mount bracket with the holes on the side of the unit (Figure 8). Install flat head machine screws in two (2) holes. -
Page 7: Acs-101 Accessories And Replacement Parts
Instruction Sheet ACS-101 Accessories and Replacement Parts ALP-600 450-900 MHz Log Period Antenna. Includes mounting hardware and 10ft (3m) coaxial cable with TNC connectors 480-800MHz Bi-Directional log periodic antenna. Includes mounting hardware and 10ft. (3m) coaxial cable with TNC Order No. 71147000 connectors.
