Prizm 4 Port 10/100/1000 Mbps Ethernet Switch
(P/N: 201640-xxx)
Users' Manual
And
Troubleshooting Guide
February 23, 2009
Rev. C
Moog Components Group
Springfield Operations
750 West Sproul Road
Springfield, PA 19064
E-Mail:
mcg@moog.com
URL:
www.moog.com/components
Tel: 610-328-4000 Fax 610-605-6216
24/7 Technical Customer Support Hotline: 610-605-6101
Advertisement
Table of Contents
Summary of Contents for PRIZM 201640 series
-
Page 1: Troubleshooting Guide
Prizm 4 Port 10/100/1000 Mbps Ethernet Switch (P/N: 201640-xxx) Users’ Manual Troubleshooting Guide February 23, 2009 Rev. C Moog Components Group Springfield Operations 750 West Sproul Road Springfield, PA 19064 E-Mail: mcg@moog.com URL: www.moog.com/components Tel: 610-328-4000 Fax 610-605-6216 24/7 Technical Customer Support Hotline: 610-605-6101... -
Page 2: Table Of Contents
February 23, 2009 (201640-xxx) TABLE OF CONTENTS Prizm 4 Port 10/100/1000 Mbps Ethernet Switch (P/N: 201640-xxx) Overview ............3 4 Port 10/100/1000 Mbps Ethernet Switch Revision History:………………………………………......3 4 Port 10/100/1000 Mbps Ethernet Switch Dash (-) Number Definitions:………………………………………….3 4 Port 10/100/1000 Mbps Ethernet Switch Operation………………………………………………………………3 4 Port 10/100/1000 Mbps Ethernet Switch Indicators and Controls………………………………………………...5... -
Page 3: Prizm 4 Port 10/100/1000 Mbps Ethernet Switch (P/N: 201640-Xxx) Overview
4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) 1 Prizm 4 Port 10/100/1000 Mbps Ethernet Switch (P/N: 201640- xxx) Overview The 4 Port 10/100/1000Mbps Ethernet Switch is designed to be used as one of a pair to provide a 1Gbps Ethernet fiber optic data link between two 4 port switches. -
Page 4: Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February
Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) The transmit portion (uplink from vehicle to surface) of the 4 Port 10/100/1000 Mbps Ethernet Switch takes in 4 standard 10/100/1000Mbps Ethernet signals via RJ-45 connectors and processes the received signals through an onboard Ethernet switch. -
Page 5: Port 10/100/1000 Mbps Ethernet Switch Indicators And Controls
Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) 1.4 4 Port 10/100/1000 Mbps Ethernet Switch Indicators and Controls LEDS: There are 7 surface mount (SMD) and 4 dual through hole LED indicators on the 4 Port 10/100/1000 Mbps Ethernet Switch. - Page 6 Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) Labeled ‘3.3V’, surface mount, located in the middle of the bottom edge of the D9 (Green) board. When ‘ON’ indicates the on-board 5V to 3.3V converter is operational Labeled ‘5V’, surface mount, located in the lower right corner of the board.
- Page 7 Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) FUSE: A 2.6A PTC fuse, F4, protects the +5VDC input to the board. NOTE: the fuse is a positive temperature coefficient self-resetting fuse and does not require replacement SWITCHES: There are no switches on the 4 Port 10/100/1000 Mbps Ethernet Switch.
- Page 8 Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) Led Status o o 2 PTC FUSE PORT1 LINK o o 4 PORT1 DUPLEX PORT2 LINK o o 6 PORT2 DUPLEX PORT3 LINK o o 8 PORT3 DUPLEX PORT4 LINK o o 10 PORT4 DUPLEX...
- Page 9 Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) 11(FIBER LINK) LOW to indicate a valid link between the onboard MAC and PHY. LOW to indicate a FULL DUPLEX link between the onboard MAC and PHY. 12(FIBER DUPLEX) HIGH to indicate HALF DUPLEX.
-
Page 10: Port 10/100/1000 Mbps Ethernet Switch Specifications
Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) 1.5 4 Port 10/100/1000 Mbps Ethernet Switch Specifications: Optical Link Data Rate: up to 1.25 Gbps full duplex Fiber Options: Single mode or Multimode Laser Wavelengths: 1310 and 1550 nanometers , CWDM Optical Output Levels: 0dBm transmitter power output at 1550 nm, typically 0dBm transmitter power output at 1310 nm, typically... -
Page 11: Power Section Testing
Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) 1.6 Power Section Testing Note: The +1.2V Power LED (D1) is not functional. The board will operate properly and +1.2CVDC is being supplied to the board whether this LED is illuminated or not. If the +5V Power LED, the +3.3V Power LED, and the +2.5V Power LED are out: •... -
Page 12: Diagnostic Overview
This capability is accessed via a 2 pin Phoenix connector on the front panel that carries bi-directional RS-485 telemetry to the modem. The diagnostics modem will typically be used in conjunction with a user-supplied PC on the surface, which has been loaded with PRIZM Modem Monitoring S/W. - Page 13 Moog Components Group 4 Port 10/100/1000 Mbps Ethernet Switch February 23, 2009 (201640-xxx) Figure 1- Typical Cabling/Wiring for Back plane Diagnostics Telemetry Page 13 of 13...
