User Info Select
The User Info Select registers are designed to provide the
user with information about the manometer's hardware
and software. This register provides read only information
on the sensor's accuracy, software version, date of
manufacture and serial number. It also allows the user to
edit the Auto Shut-Off, Lockout and Start-Up Header
Name features.
To configure the User Info Select registers, follow the
steps below.
Keystroke
1. From the Measure
Mode press the PRGM
key.
2. Press the up arrow
key twice
3. Press the PRGM
key.
4. Press the up arrow
key.
5. Press the up arrow
key.
6. Press the up arrow
key. Instructions to set
AUTO SHUT-OFF are
in this manual.
7. Press the up arrow
key.
8. Press the up arrow
key. Instructions for
using LOCKOUT are
on page 12.
9. Press the up arrow
key. Instructions for
editing the Header are
on page 13.
10. Press the left arrow
key to go back to
"USER INFO SELECT"
screen.
(Accuracy, SW version, Mfr date, SN)
Display
Top line reads "PROGRAM
MODE" and bottom line
reads "UNITS SELECT".
Bottom line changes to
"USER INFO SELECT".
Bottom line shows accuracy
in % of Full Scale
Bottom line shows software
version number.
Bottom line shows sensor
manufacture date.
Top line reads "AUTO SHUT
OFF" and bottom line reads
"ENTER TO SELECT".
Bottom line shows serial
number of the manometer.
Top line reads "LOCKOUT
CODE" and bottom line reads
"ENTER TO SELECT".
Top line reads "HEADER
NAME" and bottom line reads
"MERIAM". The cursor
flashes at bottom left.
Top line reads "PROGRAM
MODE" and bottom line
reads "USER INFO
SELECT".
11
