Summary of Contents for Kisae Portable Powerpack 800
- Page 1 Portable Powerpack 800 Portable Powerpack 800i Owner’s Manual...
- Page 2 90 days. Disclaimer While every precaution has been taken to ensure the accuracy of the contents of this guide, KISAE Technology assumes no responsibility for errors or omissions. Note as well that specifications and product functionality may change without notice.
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION....................4 PRODUCT DESCRIPTION ................5 FEATURES ......................5 OPERATION ...................... 6 TROUBLESHOOTING ..................9 SPECIFICATIONS ................... 10 WARRANTY..................... 11 Page 3 ... -
Page 4: Introduction
1. INTRODUCTION Thank you for purchasing the KISAE Portable Powerpack unit. With our state-of-the-art, easy-to- use design, this product will offer you reliable service for providing a rechargeable power source for your home, cabin, or campsite. With its highly technical design and comprehensive features, the Portable Powerpack unit will provide you with a simple yet effective system during power outages, and a reliable source of AC power everywhere you need it. -
Page 5: Product Description
CE EMC INFORMATION This equipment has been tested and found to comply with the limits for the CE EMC standard. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 6: Operation
conductive contaminants. • When placing the unit, allow a minimum of three inches of space around the unit for optimal ventilation. • Charge battery immediately upon purchasing this product. • To ensure optimum battery run time and life expectancy, leave Portable Powerpack continuously plugged into utility power with the AC Charger. - Page 7 The USB Port on the system provides standard 5V 2.1A power to power up USB powered handheld devices. The USB Port will automatically turn ON when a USB cable is plugged into the port. Unplugging the USB cable will turn off the USB output. Reminder: Unplug the USB Cable from the unit when the USB port is not in use.
- Page 8 Jump Start Cable’ port have enough energy present to cause a spark, creating an explosion hazard, or to cause burns if a metal object contacts both terminals. The following jump-start procedure is provided for your reference: • Turn OFF the vehicle or boat ignition and all accessories. •...
-
Page 9: Troubleshooting
Estimated Run time of AC Load Following run times are estimates. Actual run times may vary. Estimated Load Estimate Run time Consumption Cordless Phone 33 hrs Home Alarm System 33 hrs Clock/Radio 24 hrs Table Lamp 5 hrs 20” LCD TV 5 hrs Table Lamp 3.5 hrs... -
Page 10: Specifications
6. SPECIFICATIONS Note: Specifications are subject to change without notice. Portable Powerpack Portable Powerpack Specification PP800 PP800i -EU,-UK, -AU Inverter Output Power 800W 800W Output Current 6.7A 3.5A Surge Power 1600W Output Voltage 120 VAC 230 VAC Output Frequency 60 Hz 50 Hz Output Waveform Modified Sinewave... -
Page 11: Warranty
The limited warranty program is the only one that applies to this unit, and it sets forth all the responsibilities of KISAE. There is no other warranty, other than those described herein. Any implied warranty of merchantability of fitness for a particular purpose on this unit is limited in duration to the duration of this warranty.
