Summary of Contents for Audio Analogue SRL maestro
- Page 1 AUDIO ANALOGUE soundpleasure maestro DIGITAL AUDIO PROCESSOR COMPACT DISC PLAYER OWNER’S MANUAL MANUALE D’ISTRUZIONI...
- Page 2 Per ottenere il meglio dal Suo nuovo lettore, Le consigliamo di usare solo componenti e cavi di alta qualità; segua i nostri consigli e maestro Le regalerà anni di piacere musicale. La preghiamo di spendere qualche minuto per leggere questo manuale prima di installare il Suo nuovo lettore di compact disc.
- Page 3 AUDIO ANALOGUE maestro DIGITAL AUDIO PROCESSOR & COMPACT DISC PLAYER OWNER’S MANUAL MANUALE D’ISTRUZIONI PAGE/PAGINA INSTALLATION INSTALLAZIONE CONTROL COMANDI DISPLAY DISPLAY CONNECTIONS COLLEGAMENTI REMOTE CONTROL TELECOMANDO OPERATION FUNZIONAMENTO FUNCTIONS SPECIFIC TO THE REMOTE CONTROL FUNZIONI SPECIFICHE DEL TELECOMANDO NOTES ON THE USE OF THE STANDBY FUNCTION PARTICOLARITÀ...
- Page 4 INSTALLATION INSTALLAZIONE UNPACKING The shipping box should contain the following items apart from the CD player and this APERTURA DELL’IMBALLO ownerís manual: Remote control unit 2 AA-type batteries for remote control AC Power Cord Please check if all has been included: if not, contact your dealer. After opening the box, carefully extract the CD player and remove its protective plastic bag, check for any damage that may have been caused by poor transport.
- Page 5 STOP Press this key to end the music reproduction. If a program is stored in the CD player’s memory, it’s possible to delete it by pressing the STOP key with the disc already stopped.
- Page 6 TRACK PROGRAM SCAN SHUFFLE D I S P L AY TRACK D I S P L AY PROGRAM SCAN SHUFFLE TRACK Track counter: gives information about tracks in the CD, as described in the next sections. TRACK Contatore di traccia: fornisce informazioni sulle tracce contenute nel CD con modalità...
- Page 7 RCA. TRACK TOTAL SHUFFLE REPEAT 1 PAUSE EDIT TRACK TOTAL REPEAT 1 PAUSE EDIT TRACK TOTAL REPEAT 1 PAUSE EDIT TRACK TOTAL REPEAT 1 PAUSE maestro DIGITAL AUDIO PROCESSOR TIME TIME TIME TIME EDIT AC MAINS POWER...
- Page 8 Per effettuare questa operazione è necessario rimuovere il cavo di rete dalla vaschetta. 7 POWER ON/OFF SWITCH INTERRUTTORE D’ACCENSIONE The CD player has one pair of line-level unbalanced output RCA sockets, one single OUTPUT CONNECTIONS S/PDIF-type digital input RCA socket and one single S/PDIF-type digital output RCA COLLEGAMENTO DELLE socket.
-
Page 9: Remote Control
REMOTE CONTROL TELECOMANDO... -
Page 10: Operation
OPERATION FUNZIONAMENTO Turn the power on by pressing the key on the rear panel near the IEC mains socket. TRACK TOTAL TIME The player will start searching for a disc. If there is already a disc in the tray, the total time and number of tracks wiIl be displayed;... - Page 11 Programming. A program consists of a collections of track. When a program is stored in the CD player’s memory, only the tracks collected in the program can be accessed, until the program is deleted by pressing the STOP key when the CD is already stopped.
- Page 12 15, premere “1” e subito dopo “5”. Programmazione. Un programma è una lista di brani. Quando viene memorizzato un programma nel CD player, solo le tracce contenute nel programma possono essere riprodotte, finchè il programma non viene cancellato premendo il pulsante STOP con il CD già...
-
Page 13: Operation Modes Selection
MAESTRO must be connected to a digital signal processor (DSP) input. The DSP output in turn has to be connected to the MAESTRO digital input. This way, MAESTRO’s D/A converter will convert the CD signal processed by the external DSP. -
Page 14: Specifications
AUDIO DIGITAL PROCESSOR COMPACT DISC PLAYER SPECIFICATIONS Analogue Output Level / Livello dell’uscita digitale 2 Vrms (unbalanced / sbilanciato) SPECIFICHE 4 Vrms (balanced / bilanciato) TECNICHE Analogue Output Impedance / Impedenza dell’uscita analogica <40 (unbalanced / sbilanciato) 110 (balanced / bilanciato) Digital Output Level / Livello dell’uscita digitale... -
Page 15: Safety Precautions And Maintenance
SAFETY Avoid opening the unit - No further servicing than that described in this manual should be attempted. Refer all servicing to authorised Audio Analogue dealers and qualified PRECAUTIONS AND technicians. MAINTENANCE Do not expose the unit to heat - Keep it away from heat sources such as direct sun, cookers, radiators, etc. -
Page 16: Troubleshooting
Check and connect cables properly REMEDY Player in pause mode CAUSE Press PAUSE button REMEDY External source selected or Loop Mode selected without any DSP connected to the Maestro CAUSE Select CD mode REMEDY No sound when external source is used SYMPTOM... -
Page 17: Ricerca Guasti
Nessun suono in modalità Loop mentre il disco gira Il DSP esterno è spento CAUSA Accendere il DSP esterno RIMEDIO I collegamenti di ingresso e uscita sono invertiti al DSP o al Maestro CAUSA Ripristinare le corrette connessioni RIMEDIO SINTOMO Il suono “salta”... - Page 18 audio analogue Head Office / Ufficio commerciale: srl Via C. Bottai, 88B 51015 Monsummano Terme (PT) Italy tel. (+39) 0572 954513 · fax (+39) 0572 958099 e-mail: info@audioanalogue.com www.audioanalogue.com info@audioanalogue.com soundpleasure...
