Aiwa NSX-SZ6 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NSX-SZ6
LH
SERVICE MANUAL
COMPACT DISC
BASIC TAPE MECHANISM : ZZM-2 YPR1NC
STEREO SYSTEM
BASIC CD MECHANISM : KSM-213 CDM
CD
REMOTE
SYSTEM
SPEAKER
CASSEIVER
CONTROLLER
NSX-SZ6
CX-NSZ6
SX-NSZ1
RC-AAS08
S/M Code No. 09-00C-433-8S3

Advertisement

Table of Contents
loading

Related Manuals for Aiwa NSX-SZ6

Summary of Contents for Aiwa NSX-SZ6

  • Page 1 NSX-SZ6 SERVICE MANUAL COMPACT DISC BASIC TAPE MECHANISM : ZZM-2 YPR1NC STEREO SYSTEM BASIC CD MECHANISM : KSM-213 CDM REMOTE SYSTEM SPEAKER CASSEIVER CONTROLLER NSX-SZ6 CX-NSZ6 SX-NSZ1 RC-AAS08 S/M Code No. 09-00C-433-8S3...

  • Page 2: Specifications

    SPECIFICATIONS <FM tuner section> <Compact disc player section> Tuning range 87.5 MHz to 108 MHz Laser Semiconductor laser (λ =780 nm) Usable sensitivity (IHF) 13.2 dBf Antenna terminals 75 ohms (unbalanced) <Speaker system SX–NSZ1> Speaker system 1 way, bass reflex <AM tuner section>...

  • Page 3: Protection Of Eyes From Laser Beam During Servicing

    PROTECTION OF EYES FROM LASER BEAM DURING SERVICING CAUTION This set employs laser. Therefore, be sure to follow carefully the instructions below when servicing. Use of controls or adjustments or performance of proce- dures other than those specified herin may result in WARNING!! hazardous radiation exposure.

  • Page 4: Note On Before Starting Repair

    NOTE ON BEFORE STARTING REPAIR 1. Forced discharge of electrolytic capacitor of power supply block When repair is going to be attempted in the set that uses relay circuit in the power supply block, electric potential is kept charged across the electrolytic capacitors (C101, 102) even though AC power cord is removed.
  • Page 5 In such a case, check also if the POWER AMPLIFIER circuit or power supply circuit has any abnormalities or not. 2-2. Regarding reset There are cases that the machine does not work correctly because the MICROCOMPUTER is not reset even though the AC power cord is re-inserted, or the software reset (pressing the STOP key + POWER key) is performed.

  • Page 6: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C101 87-012-284-080 CAP, U 6800P-50 C102 87-012-284-080 CAP, U 6800P-50 87-A21-591-010 C-IC,LC78641NE-D C103 87-010-544-080 CAP, ELECT 0.1-50V 87-A21-722-010 IC,LA6548D C104 87-010-544-080 CAP, ELECT 0.1-50V 87-A21-419-040 C-IC,NJM14558MD-TE2 C105...
  • Page 7 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C375 87-010-759-080 C-CAP,U, 0.1-25F C771 87-010-263-080 CAP, ELECT 100-10V C376 87-010-263-080 CAP, ELECT 100-10V C772 87-012-286-080 CAP, U 0.01-25 C377 87-010-759-080 C-CAP,U, 0.1-25F C782 87-012-286-080 CAP, U 0.01-25 C378 87-010-759-080 C-CAP,U, 0.1-25F...
  • Page 8 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C984 87-012-286-080 CAP, U 0.01-25 C278 87-012-195-080 C-CAP,U 100P-50CH C985 87-012-195-080 C-CAP,U 100P-50CH C279 87-010-405-040 CAP,E 10-50 C987 87-012-286-080 CAP, U 0.01-25 C280 87-010-759-080 C-CAP,U, 0.1-25F C989 87-012-286-080 CAP, U 0.01-25 C281 87-012-270-080...

  • Page 9: Transistor Illustration

    CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Wattage Type Tolerance Symbol Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W 2125 1.25 0.45 1/8W 3216 0.55 TRANSISTOR ILLUSTRATION B C E E C B E C B...
  • Page 10 WIRING – 1 (MAIN) – 10 –...
  • Page 11 SCHEMATIC DIAGRAM – 1 (MAIN 1/3) – 11 –...
  • Page 12 SCHEMATIC DIAGRAM – 2 (MAIN 2/3: TUNER SECTION) – 12 –...
  • Page 13 SCHEMATIC DIAGRAM – 3 (MAIN 3/3: CD SECTION) – 13 –...
  • Page 14 SCHEMATIC DIAGRAM – 4 (FRONT) – 14 –...
  • Page 15 WIRING – 3 (DECK) – 15 –...
  • Page 16 WIRING – 4 (CD MOTOR) C CD MOTOR C.B – 16 –...

  • Page 17: Ic Block Diagram

    IC BLOCK DIAGRAM – 17 –...
  • Page 18 FL (HNA-10SS15T) GRID ASSIGNMENT & ANODE CONNECTION GRID ASSIGNMENT ANODE CONNECTION – 18 –...
  • Page 19 IC DESCRIPTION IC, M38B57MCH - E249FP Pin No. Pin Name Description — Not connected. I-HOLD Hold input. I-TRAY SW CD tray SW AD input. I-D-SW CD door open/close AD detection input (Not used). I-KEY2 Key AD input 2. I-KEY1 Key AD input 1. O-DSP DATA —...
  • Page 20 Pin No. Pin Name Description FL grid output (G1). — Not used. — Not used. FL segment output (P20). FL segment output (P19). FL segment output (P18). FL segment output (P17). FL segment output (P16). FL segment output (P15). FL segment output (P14). FL segment output (P13).
  • Page 21 IC, LC78641NE-D Pin No. Pin Name Description PDO1 Internal VCO control phase comparator output pin. (Pull down) Internal VCO control phase comparator output pin. PDO2 OFF for rough servo, ON for phase servo. (Pull down) VVSS — Internal VCO ground pin. PCKIST —...
  • Page 22 Pin No. Pin Name Description EFLG C1, C2 error correction monitor pin. (Not used) TEST Test input pin. (Connected to GND) Emphasis pin. Which becomes an input pin after reset and can be controlled externally. This EMPH becomes an emphasis monitor pin under control by command. (Not used) MUTEL L channel mute output pin.
  • Page 23 Pin No. Pin Name Description Synchronization signal detection output pin. FSEQ Outputs a high level when the synchronization signal detected from the EFM signal and the internally generated synchronization signal agree. (Not used) Defect pin. Which becomes an input pin after reset and can be controlled externally. This becomes DEFECT the defect monitor pin under control by command.
  • Page 24 ADJUSTMENT <TUNER / DECK / FRONT> < TUNER SECTION > 1. Clock frequency Check 2. Head Azimuth Adjustment (DECK 1, DECK 2) Settings : • Test point : TP2 (CLK) Settings : • Test tape : TTA–330 Method : Set to AM 1710kHz and check that the test point is •...

  • Page 25: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1 / 1 PWB, FFC GUIDE KSM213CDM ZZM-2 HT-SINK, TR LOW PWB GUIDE, H-WIRE – 25 –...

  • Page 26: Mechanical Parts List

    MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8A-NED-005-010 WINDOW,CASS 1 26 8A-NED-201-010 HLDR,TOP L 2 8A-NED-006-010 WINDOW,CASS 2 27 8A-NED-202-010 HLDR,TOP R 3 82-NF7-218-010 SPR-T,CASS 28 8A-NEC-013-010 PANEL,LEFT 4 8A-NED-002-010 BOX,CASS 1 29 8A-NED-025-010...

  • Page 27: Tape Mechanism Exploded View

    TAPE MECHANISM EXPLODED VIEW 1 / 1 TERMINAL,LB1 TERMINAL,LB1 – 27 –...

  • Page 28: Tape Mechanism Parts List

    TAPE MECHANISM PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-ZM1-254-310 SPR-C,REEL R 36 8Z-ZM1-220-110 LEVER,REC SENSOR 2 8Z-ZM1-225-110 GEAR,REEL R 37 8Z-ZM1-249-210 SPR-T,FR 3 8Z-ZM1-253-210 SPR-C,AUTO SENSOR 38 8Z-ZM1-242-310 SPR-T,FF/REW 4 8Z-ZM1-217-110 LEVER,AUTO SENSOR...

  • Page 29: Cd Mechanism Exploded View

    CD MECHANISM EXPLODED VIEW 1 / 1 COVER SPINDLE MOTOR (M1) (M2) SLED MOTOR P.W.B CD MECHANISM PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION 1 9X-262-620-210 MOTOR CHASSIS ASSY 2 92-626-907-010 GEAR(A) 3 87-A90-468-010 PICK UP KSS-213C 4 92-626-908-010 SHAFT SLED 5 92-627-003-020...

  • Page 30: Speaker Disassembly Instructions

    SPEAKER DISASSEMBLY INSTRUCTIONS Type.1 Type.4 Insert a flat-bladed screwdriver into the position indicated by the TOOLS arrows and remove the panel. Remove the screws of each speaker 1 Plastic head hammer unit and then remove the speaker units. 2 (() flat head screwdriver 3 Cut chisel How to Remove the PANEL, FR Type.2...
  • Page 31 SPEAKER PARTS LIST (SX-NSZ1) <YJSL> REF. NO. PART NO. KANRI DESCRIPTION 1 8A-NSN-001-010 PANEL, FR 2 8A-NSN-002-010 GRILLE, FRAME ASSY 3 8A-NSN-008-010 CORD, SPKR 4 8A-NSM-602-010 SPKR, 100 – 31 –...
  • Page 32 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9820572 0251431 Printed in Singapore...
