Apacer AM700
Thank you for purchasing Apacer AM700 3-in-1 USB OTG
(on-the-go) card reader. This document will provide instructions of
how to use this exciting product properly. Please be aware of the
following before you proceed.
1. This device is primarily made for USB OTG (On-The-Go) functions. Please check
if your smartphone/tablet supports this standard. If you are uncertain about
whether your device supports OTG or not, please consult with the place where
you purchased your smartphone/tablet.
2. This quick start guide is intended for Android system users only. This device is not
workable on iOS products.

Application

DC 5V power supply (for the
USB port operations)
SD/microSD card (microSD
requires SD adapter)
© 2014 Apacer Technology Inc.
Mobile Card Reader
AM700
Mini OTG Card Reader
Smartphones/tablets (for Android
system ONLY)
USB devices
Rev. 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AM700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Apacer Technology AM700

  • Page 1 AM700 Apacer AM700 Mini OTG Card Reader Thank you for purchasing Apacer AM700 3-in-1 USB OTG (on-the-go) card reader. This document will provide instructions of how to use this exciting product properly. Please be aware of the following before you proceed.
  • Page 2 AM700 File Sharing & Playback via Smartphone/Tablet 1. When AM700 is connected to an Android smartphone or tablet as shown in the image below, users may just plug SD card, microSD card or USB memory device onto corresponding ports of AM700.
  • Page 3 Once properly installed, the App will always detect and a dialogue box will pop up when your smartphone/tablet is connected with a USB OTG device. 3. For detailed usages of the App, please refer to the Apacer FileBridge App user manual. © 2014 Apacer Technology Inc. Rev. 1.1...
  • Page 4 Apacer AM700 can function like a hub for external devices and additional power input. DC IN 5V: As illustrated below, the DC IN 5V USB port of AM700 is used for additional power supply, such as USB mobile power bank.
  • Page 5 - Green: AM700 is properly connected to a smartphone/tablet. - Blue: accessing files File Sharing & Playback via a Desktop/Laptop Since AM700 is built with a micro USB connector, which is not commonly found on a desktop/laptop computers, users may need a standard USB adapter.
  • Page 6 USB2.0 up to 480Mbps (Backward Compatible with USB1.1) Socket -SD/SDHC/SDXC/MMC -microSD/microSDHC/microSDXC Material Plastic Dimensions (mm) (L)58 x (W)29.1 x (H) 11.2 Weight (g) USB Flash Driver, Card Reader, Hub, Portable Hard Drive, Compatibility keyboard, mouse © 2014 Apacer Technology Inc. Rev. 1.1...
  • Page 7 1301, No.251,Xiaomuqiao Road, Shanghai, 200032, China Tel: 86-21-5529-0222 Fax: 86-21-5206-6939 sales@apacer.com.cn India Apacer Technologies Pvt Ltd, # 535, 1st Floor, 8th cross, JP Nagar 3rd Phase, Bangalore – 560078, India Tel: 91-80-4152-9061 Sales_india@apacer.com © 2014 Apacer Technology Inc. Rev. 1.1...
