- Page 1 Single Board Computer SBC2516 User's Manual...
-
Page 2: Regulatory Compliance Statements
Any implied warranties of merchantability or fitness for any particular purpose is also disclaimed. Acknowledgements SBC2516 is a trademark of PCW Microsystems Inc. All other product names mentioned herein are registered trademarks of their respective owners. Regulatory Compliance Statements This section provides the FCC compliance statement for Class A devices and describes how to keep the system CE compliant. -
Page 3: Table Of Contents
Table of Contents Chapter 1 General Information ......... 1.1 Features .................. 5 1.2 Specifications ................5 1.3 Board Layout ................8 1.4 Checklist & Mechanical Drawing ..........9 Chapter 2 Jumper Setting ............10 2.1 Functions of Jumpers .............. 12 2.2 Setting Jumpers .............. -
Page 4: Chapter 1 General Information
Chapter 1 General Information... -
Page 5: Features
1.1Features Socket 478 Intel Pentium 4 processor up to 3.2GHz with 800MHz FSB ® ® Intel 865G/ICH5 chipsets ® Max. 2GB DDR 400/dual channel memory in 2 DIMM slots Integrated VGA, CRT connector x 1 Intel 82547EI gigabit Ethernet controller in CSA port and Intel 82551QM 10/100 Ethernet controller Serial ATA port (150MB/s) x 2/USB 2.0 port (480Mbps) x 2 1.2 Specifications... -
Page 6: On Board Lan
On Board LAN - Intel 82547EI gigabit Ethernet controller (dedicated by CSA port directly from the Intel 865G GMCH) and Intel 82551QM 10/100 Ethernet controller x 1 for SBC2516 - Compliant with PCI V2.1/V2.2, IEEE802.3, IEEE 802.3u, IEEE802.3x, IEEE802.3y, IEEE8023ab – WfM 2.0, PC2001 compliant... - Page 7 ISA signals for supporting ISA cards up to 20 on the backplane ISA slot Dimensions -338.58mm(L) x 122mm(W) (13.3”(L) x 4.8”(W) Power Requirements -+5V, +12V, -12V, ATX/AT Power Consumption: Model SBC2516 (G) 3.0G 2.4G +12V 6.5A 4.5A 5.4A +3.3V 0.5A...
-
Page 8: Board Layout
Channel Memory in 2 up to 3.2GHz+ with 800MHz FSB DIMM Slots Serial ATA Connector x 2 Intel 82551QM 10/100 Ethernet Controller Dual LAN Intel 82547EI Gigabit/CSA Ethernet Controller or Intel 82562EX 10/100 LCI Ethernet Controller Figure 1-1: SBC2516 Front Layout... -
Page 9: Checklist & Mechanical Drawing
1.4 Checklist After opening the package of SBC2516 Series, please check and make sure you have all of the following items: ✍ One SBC2516 series SBC (A mechanical drawing of this model is shown below.) ✍ One SBC2516 Manual Guide ✍... -
Page 10: Chapter 2 Jumper Setting
Chapter 2 Jumper & Switch Settings... -
Page 11: Before You Begin
Hold electronic circuit boards (such as the SBC2516 board) by the edges only. Do not touch the components on the board unless it is necessary to do so. Don’t flex or stress the circuit board. -
Page 12: Functions Of Jumpers
2.1 Functions of Jumpers You can use jumpers to set configuration options. The table below defines function of each jumper: Function Connector AC’97 Primary IDE SATA 0 Secondary IDE SATA 1 USB 2.0 Connector USB Exernal Power Connector Floppy DVI Connector(optional) CPU Fan System Fan COM1... -
Page 13: Setting Jumpers
2.2 Setting Jumpers A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is SHORT. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is OPEN. -
Page 14: Location Of Jumpers
2.3 Location of Jumpers The illustration below shows the location of the mainboard jumpers: *= Pin 1 Figure 2-2 : Location of Jumpers... -
Page 15: Jumping Setting
2.4 Jumper Setting Switch Setting Table (* = default setup) Device Select SW1.1 SW1.2 SW1.3 SW1.4 ON Board LAN 82551 Enable ON Board LAN 82551 Disable ON Board TMDS Enable * ON ON Board TMDS Disable DDR VDDQ Select *2.5V 2.6V 2.7V 2.8V... -
Page 16: Connector Pin Definition
2.5 Connector Pin Definition AC’97 connector Definition Definition AC_SDOUT_R ACRST# AC_SYNC +12V AC_SDIN0 AC_SDIN1_R ACBTCLK 10 ACSDIN2R J2/J4: IDE connector Pin Definition Pin Definition Pin Definition Pin Definitio 1 IDRST# 2 GND 1 IDRST# 2 GND 3 PDD7A 4 PDD8A 3 SDD7A 4 SDD8A 5 PDD6A... - Page 17 J3/J5:SATA connector Definition Definition SATA0TXPC SATA0TXNC SATA0RXNC SATA0RXPC Definition Definition SATA1TXPC SATA1TXNC SATA1RXNC SATA1RXPC J6:USB connector Definition Definition +5VSBY DATA0- DATA0+ DATA1- DATA1+ J7:USB External Power connector Definition Definition +5VSBY J8:FDD connector Definition Definition DENSEL# INDEX# MOTEA# 11 GND DRVB# 13 GND DRVA# 15 GND...
- Page 18 J9:TMDS DVI connector Definition Definition TMDSTX2N TMDSTX2P TMDSTX1N TMDSTX1P HotPlugDet 10 TMDSTX0N 11 TMDSTX0P 12 GND 13 TMDSTXCP 14 TMDSTXCN 15 GND 16 GND 17 DVICLK 18 DVIDATA 19 NC 20 NC J10/J11:CPU FAN & SYSTEM FAN connector Definition Definition +12V SENSE J12/J13: COM1/COM2...
- Page 19 J16:External Keyboard Definition Definition KBCLK KBDATA JP2:SPEAKER External connector Definition Definition SPEAKERR# JP4:IDE Active LED connector Definition Definition IDE_LED JP7:GPIO connector Definition Definition GP27_D_IN1 ( PIN20 ) GP23_D_OUT 1 ( PIN24 ) GP26DIN2 ( PIN21 ) GP22DOUT 2 ( PIN25 ) GP25_D_IN3 ( PIN22 ) GP21_D_OUT 3 ( PIN26 ) GP24_D_IN4 ( PIN23 )
- Page 20 JP13:82747EI/82562EX LAN External SPEED 100 LED connector Definition Definition +3VSBY LINK100 JP16:82747EI LAN External SPEED 1000 LED connector Definitio Definition +3VSBY LINK1000 JP17:Hardware Reset connector Definition Definition RESET JP18: 82747EI/82562EX LAN External ACTIVE&LINK LED connector Definition Definition LINK_UP ACTIVITY JP20:SMBUS connector Definition Definition SMBCLK...
- Page 21 CON3:82547/82562 RJ45 connector Definition Definition LAN2 MDX 0P TXP LAN2 MDX 0N TXN LAN2 MDX 1P RXP LAN2 MDX 2P LAN2 MDX 2N LAN2 MDX 1N RXN LAN2 MDX 3P LAN2 MDX 3N LAN2 LINK1000 10 +3VSBY 11 LAN2_LINK_UP 12 LAN2_ACTIVITY CON4: AUX +12V Power Connector Definition Definition...
-
Page 22: Chapter 3 Expanded Capabilities
Chapter 3 Expanded Capabilities... -
Page 23: System Memory
CPU board. The CPU board contains two memory banks: Bank 0 and 1, corresponds to connector DIMM1, DIMM2. The table below shows possible DIMM configurations for the memory banks. Please be noted that the SBC2516 Series supports Double Data (DDR333) SDRAM. Configurations using different brands of memory modules are not recommended. -
Page 24: Installing Dimm
3.2 Installing DIMM To install DIMM: 1. Make sure the two handles of the DIMM sockets are in the “open” position, i.e. the handles stay outward. Figure 3-1 : How to Install DIMM (1) 2. Slowly slide the DIMM modules along the plastic guides in the both ends of the socket. - Page 25 3. Then press the DIMM module down right into the socket, until a click is heard. That means the two handles automatically locked the memory modules into the right position of the DIMM socket. Figure 3-3 : How to Install DIMM (3) 4.
-
Page 26: Changing Cpu
3.3 Changing CPU To change the CPU: 1. Pull the handling bar of the socket upward to the other end to loosen the socket’s openings. Carefully lift the existing CPU up to remove it from the socket. 2. Place the new CPU on the middle of the socket, orienting its beveled corner to line up with the socket’s beveled corner. -
Page 27: Installing The Fan Heatsink
3.4 Installing the Fan Heatsink 1. Use the following instructions for installing the fan heatsink: The heatsink has thermal interface material attached to the bottom, shown in Figure 3-7. Be careful not to damage the thermal interface material 2. Align the fan heatsink and clip assembly (A in Figure 3-6) with the retention mechanism (the fan heatsink is symmetrical) and place it on the processor (as shown in Figure 3-7). - Page 28 Lastly, connect the processor fan cable to the motherboard fan power header (Figure 3-10). Consult the motherboard manual to determine the correct fan header to use Figure 3-6: Installing the Fan Heatsink (1) Fan Heatsink and Clip Assembly Terminology Figure 3-8: Installing the Fan Heatsink (3) Push Down Clip Frame Corners to Secure...
- Page 29 Heatsink (2) Align Fan Heatsink and Clip Assembly...
- Page 30 Figure 3-9a: Installing the Fan Figure 3-9b: Installing the Fan Heatsink (4) Heatsink (5) Close Clip Levers, Close Clip Lever (1), One at a Time While Holding the Topside of Fan Heatsink (A) Figure 3-9c: Installing the Fan Figure 3-10: Installing the Fan Heatsink (6) Heatsink (7) Close Clip Lever (2),...
-
Page 31: Serial Ata
On-Chip Serial ATA Setting On-Chip Serial ATA The setting is used to specify te SATA controller. Settings: Disable, Auto, Combined Mode, Enhanced Mode, SATA only If <Combined Mode> is selected, PATA and SATA will be combined. If <Enhanced Mode> is selected, PATA and SATA will both be enabled. If <Auto> is selected, PATA and SATA will be arranged by BIOS, and you will be able to see the IDE Device Status listed in the Standard CMOS Features.
