Summary of Contents for TSH GAUI X2
-
Page 1: Assembly Instruction
GAUI ASSEMBLY INSTRUCTION V1.0.4 Recommendation: We highly recommand using the latest version of the Assembly Instruction Manual. To download the latest version, please visit the Offi cial TSH GAUI web site: www.gaui.com.tw 取得最新的手冊： 我們非常建議您取得最新版本的手冊。 請到泰世網站下載最新的手冊，並且取代目前的手冊。 gaui@gaui.com.tw... -
Page 3: Table Of Contents
Preface Mair Rotor Assembly 前言 主旋翼總成組裝 Tail Rotor Assembly Tools for Assembly 自備工具 尾旋翼總成組裝 Upgrade & Replacement Parts Assembly Notice, 組裝代號說明，產品規格 升級維修零件表 Main Frame assembly 機體總成組裝 Preface Belt Direction Check P.1 ~ P.2 前言 皮帶方向確認 P.13 Main Gear Assembly Academy of Model Aeronautics (AMA) 主齒盤安裝... -
Page 4: Safety Precautions
TAI SHIH HOBBY CORPORATION 前言 Thank you for purchasing GAUI High Performance RC Helicopter from Tai Shih Hobby Corporation (TSH). We hope you will enjoy the joy of flight. 感謝您購買泰世科技出品的 GAUI 高性能遙控直升機，我們希望您可以盡情享受 飛行的樂趣。 In order to understand full assembly sequences, this instruction manual shows the assembly information of this model, even though some elements are supplied as pre-assembled. - Page 5 GAUI LIABILITY DISCLAIMER TAI SHIH HOBBY CORPORATION 免責聲明 LIABILITY DISCLAIMER This product is for a radio controlled (RC) helicopter. Improper operation, maintenance or assembly can potentially cause a RC helicopter to pose a danger to persons or objects including but not limited to the possibility of causing serious physical injury and even death.
-
Page 6: Radio Control
GAUI Academy of Model Aeronautics (AMA) TAI SHIH HOBBY CORPORATION For United States market, The Academy of Model Aeronautics (AMA) is a national organization representing modelers in the United States. Please refer the National Model Aircraft safety code from Academy of Model Aeronautics. -
Page 7: Tools For Assembly
GAUI Tools for Assembly TAI SHIH HOBBY CORPORATION 自備工具及設備 2.0mm Hexagon Screw Driver 2.5mm Hexagon Screw Driver Philips Screw Drive Scissor 2.0mm 六角螺絲起子 2.5mm 六角螺絲起子 十字螺絲起子 剪刀 Needle-nosed pliers Diagonal cutting plier Ball Link Plier Dial Pitch Gauge 尖嘴鉗 斜口鉗 拔豆鉗... -
Page 8: Assembly Notice
GAUI Symbols for Assembly Notices TAI SHIH HOBBY CORPORATION 組裝代號說明 Attention: Pay attention, care should be taken Apply general thread lock. Apply special thread lock. during assembly. To tighten screw, apply thread lock. To tight screw and apply thread lock. 注... - Page 9 GAUI Front Fuselage Assembly TAI SHIH HOBBY CORPORATION 上前側板組裝 Make sure to assemble the Upper / Apply thread lock on all a.M2x5 Lower Mount at the correct position screws in this section. as shown in Figure. 螺絲均需上止滑劑 b.M2x3.2 組裝伺服機座鋁柱時請注意方向性 Upper Mount c.M1.4x6 Lower Mount b.M2x3.2...
-
Page 10: Motor Assembly
GAUI TAI SHIH HOBBY CORPORATION Front and Back Fuselage Assembly 前後側板組裝 Apply thread lock on all a.M2x3.2 screws in this section. 螺絲均需上止滑劑 b.M1.4x6 Make adjustment to the servo horns with the servo in neutral position. 請在伺服器中立狀態下， 組裝伺服器舵片並修剪多餘的舵片。 a.M2x3.2 3.5mm 短球頭 Ball without Stand b.M1.4x6 a.M2x3.2... - Page 11 GAUI TAI SHIH HOBBY CORPORATION Bottom Fuselage Assembly 下側板組裝 a.B3x6x2 b.M2x3.2 b.M2x3.2 a.B3x6x2 c.M2x5 d.M1.4x7 Apply thread lock on all screws in this section. 螺絲均需上止滑劑 b.M2x3.2 b.M2x3.2 c.M2x5 d.M1.4x7 c.M2x5 d.M1.4x7 GAUI Upper & Lower Fuselage Assembly TAI SHIH HOBBY CORPORATION 上下側板組裝...
- Page 12 GAUI TAI SHIH HOBBY CORPORATION Rotor Blade Clamp Assembly 旋翼夾頭組裝 Apply thread lock on all Tighten the ball link screw a.M2x8 screws in this section. using the screw driver 螺絲均需上止滑劑 使用內附的六角板手將球頭旋緊。 b.W2x5.8x1.4 c.B2x6x3 d.B3x6x2.5 e.W3.1x4.6x1 f.M2x8.4 d.B3x6x2.5 g.W2x3.5x0.5 e.W3.1x4.6x1 d.B3x6x2.5 c.B2x6x3 b.W2x5.8x1.4 f.M2x8.4...
- Page 13 GAUI TAI SHIH HOBBY CORPORATION Swash Plate Assembly 十字盤組裝 a.M1.4x6 b.M1.4x15 c.P1.4x2x9.5 Apply thread lock on all screws in this section. 螺絲均需上止滑劑 a.M1.4x6 a.M1.4x6 b.M1.4x15 c.P1.4x2x9.5 a.M1.4x6 a.M1.4x6 GAUI Main Rotor Blade Ball Links Adjustment TAI SHIH HOBBY CORPORATION 主旋翼拉桿配置 1.製作兩支主旋翼拉桿並扣上。...
- Page 14 GAUI TAI SHIH HOBBY CORPORATION Tail Rotor Base Assembly 尾殼組裝 Apply thread lock on all a.M1.4x4 screws in this section. 螺絲均需上止滑劑 b.W1.4x2.5x0.4 a.M1.4x4 b.W1.4x2.5x0.4 c.B2x7x3 d.B2x5x2.5 c.B2x7x3 e.W2x3.5x1 f.M2x4.6 d.B2x5x2.5 e.W2x3.5x1 Insert belt into pulley of tail rotor shaft and assemble tail rotor base as described by exploded view.
- Page 15 GAUI TAI SHIH HOBBY CORPORATION Tail Rotor Clamp Assembly 尾旋翼夾頭組裝 Do not over tighten the a.M1.4x5 M1.4x4 screw 鎖緊e.M1.4x4時不可過份鎖緊。 b.W1.4x2x0.5 c.B2x5x1.5 d.P2x3.5x1 g.M1.4x7 e.M1.4x4 a.M1.4x5 b.W2x3.5x0.5 f.P1.4x1.7x2.15 c.B2x5x1.5 d.P2x3.5x1 g.M1.4x7 c.B2x5x1.5 h.M2x2 e.M1.4x4 h.M2x2 f.P1.4x1.7x2 Apply thread lock on all screws in this section.
-
Page 16: Check
GAUI TAI SHIH HOBBY CORPORATION Belt Direction Check 皮帶方向確認 When installing the tail boom assembly. Please make sure the direction and position of the belt. 安裝尾管總承時請確認皮帶方向無誤 不可纏繞 GAUI TAI SHIH HOBBY CORPORATION Main Gear Installation 主齒盤安裝 Apply thread lock on all a.M3x3 screws in this section. -
Page 17: Check
GAUI TAI SHIH HOBBY CORPORATION Tail Servo Assembly 尾伺服機組裝 a.M2x5 a.M2x5 b.M2x4.6 b.M2x4.6 c.M1.4x6 d.M2x8 1. Install tail servo and tail boom support rods. Adjust tail servo rod length. 2. Adjust position of servo base (figure 1-1). 3. Adjust position of servo base by turning around the tail boom so that the c.M1.4x6... - Page 18 GAUI Check - 2 TAI SHIH HOBBY CORPORATION 機構檢查-2 1.Move the throttle stick upward, check and make sure 3 linkages of swashplate all moved upward, if any one of the CCPM servos does not push up the swash plate. Go to the transmitter setting to set Norm/Reverse to set the correct movement. 2.Move the AIL stick rightward, check and make sure the swashplate tilt to right side, if it tilt to the opposite side, set the “AIL %”...
- Page 19 GAUI Upgrade & Replacement Parts TAI SHIH HOBBY CORPORATION 升級維修零件表 212003 X2 Kit X2 Kit 212005 X2 Super Combo X2 Super Combo 212100 X2 CNC Stop Plate X2 CNC煞車盤 212101 X2 FES Rotor Head(Titanium anodized) X2 FES 主旋翼頭(電鍍鈦) X2 CNC New FES Main Grips set for 212102 X2 CNC新無平衡桿主旋翼夾頭組(鈦色) H255(Titanium anodized)
- Page 20 GAUI Upgrade & Replacement Parts TAI SHIH HOBBY CORPORATION 升級維修零件表 212324 X2 Aluminum Frame posts X2 碳纖側板鋁柱包 X2 CNC Tail Pulley and Output Shaft 212400 X2 金屬尾齒輪組(15T皮帶版用) Assembly(15T for belt version) 212401 Bearing(2x7x3)x2pcs 軸承包(2x7x3)x2個 212402 X2 Tail Hub Set X2 尾旋翼頭 212403 X2 CNC Tail Support Clamp X2 CNC 水平尾翼及尾支撐桿座...
- Page 22 GAUI http: //www.gaui.com.tw E-mail: gaui@gaui.com.tw F A X: +886-2-2610-5567 MADE IN TAIWAN...
