Ruby Tech 2000/MKII User Manual page 4

INsTRuCTIONs :
Follow these instructions for safe, trouble free juicing.
1
sTeP . Upon unpacking your
juicer perform an initial inspection.
Make sure that the juicer is free of
damage that may have occurred
during transport, and that all parts
have been supplied.
Your box should contain the
following items;
• 1 x Ruby 2000 juicer
• 1 x Exhaust Tube
• 1 x 7/8 combination spanner
• 1 x Pusher / Plunger
• 1 x Users Manual
2
sTeP . It is now time to look
for a place to set up your juicer.
• We recommend a minimum
working area approximately
.
500mm x 500mm in size
• You will also require a
power supply.
10amp
• The Ruby 2000 has 8 positions
for the juice spout
2 for the exhaust tube, making
it suitable for most locations.
3
sTeP . Once you have found
a suitable location for your juicer
remove the top cover. You should
see the 7/8 locking nut that holds
the cutting blade and strainer
in place. Loosen this with your
spanner removing it along with the
strainer, blade and collection pan.
Locate the juice spout in the hole
that best suits your workspace.
Replace the strainer making sure
it locks into position over the 2
pins. Replace the blade, turning it
till it locks into place. Replace the
7/8 nut, tightening it firmly with
your spanner.
4
sTeP
fasten the lock latches on each
side. these latches are adjustable.
to tighten the latches turn the
hooks clockwise and to loosen
them do the opposite.
Do not over tighten the latches,
this will stretch or brake them.
5
sTeP
making sure step 3 has been
completed and the juicer is
220~240V,
switched off. You may now turn
on the juicer. Your juicer should
run smoothly.
and
6
sTeP .
make your first juice.
. Replace the lid and
. Plug in your juicer,
You are now ready to
