Summary of Contents for Optima PC
-
Page 1: Table Of Contents
OPtima PC Contents 1. Introduction ... 2 2. Installation ... 2 CE EMC Compliance ... 2 Mounting ... 2 Wiring ... 2 Adding Hardware ... 7 3. Peripheral Devices ... 9 4. The Operating System ... 9 BIOS Password Settings ... 9 5. -
Page 2: Introduction
“touchscreen” display and an (optional) floppy disk drive. The PC is supplied with a minimum of 64 MB of EDO RAM, with support for up to 128 MB. It also has 2 MB of on-board display memory, which is not expandable. -
Page 3: Figure 1. Model Dsa2 Dimensions For Flange Mount
Include a switch or circuit breaker in the installation. It must be placed in close proximity to the equipment, within easy reach of the operator and must be marked as the disconnecting device for the equipment. 12.620 .375 5.000 1.873 7.483 19.462 7.483... -
Page 4: Figure 2. Model Dsa2 Dimensions For Panel Mount
Include a switch or circuit breaker in the installation. It must be placed in close proximity to the equipment, within easy reach of the operator and must be marked as the disconnecting device for the equipment. 0.550 7.450 11.000 Figure 2. Model DSA2 Dimensions for Panel Mount Page 4 Shock mounts are 1/4-20 threads... -
Page 5: Figure 3. Model Dsb2 Dimensions For Flange Mount
Include a switch or circuit breaker in the installation. It must be placed in close proximity to the equipment, within easy reach of the operator and must be marked as the disconnecting device for the equipment. .180 Note that this panel cutout applies to both the Model DSB2 and 11.640... -
Page 6: Figure 4. External Floppy Drive Cutout And Dimensions
6.86 (139.7) (101.6) Cable Clearance Side View External Floppy Drive Dimensions shown in inches; millimeters in parenthesis ( ). Drive must be mounted within 15 in. (381 mm) of OPtima floppy cable connector. Figure 4. External Floppy Drive Cutout and Dimensions Page 6 6.0 (152.4) 0.688... -
Page 7: Adding Hardware
Address 61 is entered as “001111” (60). With the PC off, place the board in the ISA slot closest to the back. Screw down the board and replace the cover. - Page 8 2. Power up the OPtima. From Control Panel (in Settings) select Add/Remove Programs and click Install. Insert the SW-LNET-INT disk in the floppy drive and select “A:setup.exe.” Install the file to the C:\Modicon\WinConX\MBX Driver di- rectory. If the installer will not create this directory, create it first, and then perform the installation again.
-
Page 9: Peripheral Devices
Consult your peripheral device (printer, etc.) for appropriate settings for these ports. 4. The Operating System The operating system for the OPtima PC is Windows NT 4.0. The BIOS is Award FLASH BIOS. 4.1 BIOS Password Settings It is not recommended that users change the factory defaulted BIOS settings. -
Page 10: Setup
When creating screen sets for use with the InTouch development system, the user MUST use fonts that are also installed in the OPtima PC. It is recommended to download sample screens before developing an entire screen set, in order to make certain that fonts (and other items) appear as desired. -
Page 11: Installing The Wonderware License
8. Select File and Exit from the toolbar to close the App Manager window. 5.3 Power Shutdown/Battery Backed Power Supply Due to the way Windows NT operates, it is recommended that the OPtima PC be powered down through the Start menu Shut Down sequence. Inadvertent power loss or shut down may cause application anomalies. -
Page 12: Keyboard Functionality (Model Dsa2 Only)
Go to Note that a “button template” (“OPtima PC Button Temp.doc”) for creating key Button Template labels is included in the “Other Files” folder of the instruction manual CD. It is in Microsoft Word format and can be edited to suit individual needs. -
Page 13: Left/Right Mouse Buttons
Interbus-S port. The bus connections are made with the two small D-sub connectors on the side of the Optima PC. The machine function keys are Bits 0 - 23 of the 2 input words. The LED’s are Bits 0 - 23 of the 2 output words. -
Page 14: Automatic Logon To Windows Nt
9. Automatic Logon to Windows NT Since the Model DSB2 OPtima PC has no built-in keyboard functions, it is shipped from the factory with the Windows NT AutoLogon feature enabled. This has been accomplished by setting a username and password (under Start/Programs/Ad- ministrative Tools/User Manager) and matching that password with the DefaultPassword in the system registry (see below). -
Page 15: Troubleshooting/Application Tips
OEM). Wonderware Screens do not look “right” when transferred from the Development Computer to the OPtima PC: Check the resolution mode in which the screen set was developed. The DSA2 is an 800 x 600 pixel resolution and cannot perform XGA (1024x768) resolution. Also, check in Control Panel\Display that the window title bar sizes are set to 18. -
Page 16: Disconnecting The Display
11. Disconnecting the Display If for any reason it is necessary to open the case, it may also be necessary to disconnect and remove the display from the rest of the case. In order to detach the display from the rear portion of the case, you must remove the connector located on the backside of the display (refer to Figure 7). -
Page 17: Description Of Other Rights And Limitations
• Storage/Network Use. If the SOFTWARE PRODUCT is installed on the • Back-up Copy. If Manufacturer has not included a copy of the SOFTWARE 2. DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS • Limitations on Reverse Engineering, Decompilation, and Disassembly. • Single SYSTEM. The SOFTWARE is licensed with the SYSTEM as a single •... -
Page 18: Upgrades And Recovery Media
3. UPGRADES AND RECOVERY MEDIA • If the SOFTWARE is provided by Manufacturer on media separate from the • If the SOFTWARE is provided by Manufacturer on separate media and 4. COPYRIGHT. All title and copyrights in and to the SOFTWARE (including but not limited to any images, photographs, animations, video, audio, music, text and “applets,”... - Page 19 1660-IN-010-0-04 Page 19...
- Page 20 Barber-Colman Company / Eurotherm Controls, Inc. 741-F Miller Drive, Leesburg, VA 20175 Phone: 703-443-0000 Fax: 703-669-1300 http://www.barber-colman.com http://www.eurotherm.com An Invensys Company Copyright © 2001 Barber-Colman Company...
