Onkyo RC- 480M Using Manual

Onkyo universal remote manual rc-482m, rc- 480m
Hide thumbs

Advertisement

Table of Contents

Using remote controller
*
Diagram for RC-482M
RCVR MODE
CH
RCVR MODE
Overview
The RC-482M/480M remote controller is a useful tool that can not
only operate the TX-SR700/700E/600/600E, but also all the other
components of your home theater as well. To operate any
component, first press the Mode button on the remote controller that
corresponds to the component that you wish to control. Then simply
press the desired operation button and the component will operate
accordingly. For example, if you wish to select the CD input source
at the TX-SR700/700E/600/600E with the remote controller, first
press the RCVR MODE button to select the TX-SR700/700E/600/
600E and then press the CD (INPUT SELECTOR) button.
Calling up a preset radio station
1. Press the RCVR MODE button.
The RCVR MODE button lights green.
2. Press the TUN input selector button.
3. Press the desired operation button.
VOL
Operation buttons:
CH
MUTING
You may also use the following buttons:
VOL
MUTING: Activates muting function at TX-SR700/700E/600/
600E
TUN
Controlling an Onkyo cassette tape deck
The
connected to the TX-SR700/700E/600/600E (see page 29).
1. Press the RCVR MODE button.
The RCVR MODE button lights green.
2. Press the desired operation button.
The buttons shaded in the figure to the left are the operation
buttons that can be used to control an Onkyo cassette tape deck.
Operation buttons:
VOL
: Play
: Stop
MUTING
: Rewind
TAPE
: Fast forward
operation
: Skips to beginning of next track during playback
buttons
: Skips to beginning of current track during playback
REC: Record/Pause
: Reverse playback
You may also use the following buttons:
VOL
MUTING: Activates muting function at TX-SR700/700E/600/
600E
Note:
Even for devices with the
may cause them not to work properly.
: Selects the desired preset station number
: Adjusts volume at TX-SR700/700E/600/600E
connector of the Onkyo cassette tape deck must be
: Adjusts volume at TX-SR700/700E/600/600E
and
buttons, signal discrepancies
63

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC- 480M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Onkyo RC- 480M

  • Page 1 The RCVR MODE button lights green. 2. Press the desired operation button. The buttons shaded in the figure to the left are the operation buttons that can be used to control an Onkyo cassette tape deck. Operation buttons: : Play...

  • Page 2: Using Remote Controller

    STANDBY 2. Press the desired operation button. The buttons shaded in the figure to the left are the operation buttons that can be used to control an Onkyo compact disc player. Operation buttons: ON: Turns on and off the compact disc player (same as the...
  • Page 3 The DVD MODE button lights green. 2. Press the desired operation button. The buttons shaded in the figure to the left are the operation buttons that can be used to control an Onkyo DVD player. Operation buttons: ON: Turns DVD player on and off STANDBY: Turns DVD player off (Some sets may not respond to this button.
  • Page 4 2. Press the desired operation button. STANDBY The buttons shaded in the figure to the left are the operation buttons that can be used to control an Onkyo MD recorder. MD MODE Operation buttons: ON: Turns on and off MD player (same as the STANDBY button on...
  • Page 5 First enter 601 and if it does not operate properly, enter 613. No. 600: This code is for Onkyo DVD players that have an terminal that you are connecting to the TX-SR700/700E/600/600E with an cable.
  • Page 6 (i.e. if the first code does not work, then try the next). BRAND SETTING No. DENON 602, 609 HITACHI KENWOOD MAGNAVOX 606, 613 MARANTZ MITSUBISHI 608, 613 ONKYO 600, 601, 613 PANASONIC PIONEER PROSCAN SONY TOSHIBA YAMAHA 609, 614 ZENITH 613, 615 BRAND SETTING No.

  • Page 7: Operating Your Programmed Remote Controller

    Operating your programmed remote controller After entering a pre-programming by following the procedure given above, the following modes become enabled for use. TV/VCR TV MODE TV/VCR DVD MODE (DVD Player Mode) Operations are the same as explained on page 65. VCR MODE (VCR Mode) 1.

  • Page 8: Programming The Commands Of Remote Controllers For Other Devices Into The Remote Controller

    Programming the commands of remote controllers for other devices into the remote controller 2 to 6 inches (5 to 15 cm ) Programming procedure When programming the commands of another remote controller to the RC-482M/480M remote controller, you must first decide under which MODE button you want the commands to be linked.
  • Page 9 You may, however, use these buttons to program the codes for other remote controllers. If you wish to restore the Onkyo preset codes after you program new codes, you must first erase the new codes (see page 72).

  • Page 10: Erasing The Programmed Command From One Button

    Programming the commands of remote controllers for other devices into the remote controller Erasing the programmed command from one button SEND/LEARN indicator You can only erase memorized commands and not preset ones. 1. Press and hold down the MODE button for the command, press the ENTER button, and then release both buttons.

  • Page 11: Using The Macro Function

    Using the macro function What is the macro function? A macro function enables you to program a series of button operations (up to 16) on the remote controller into a single button. The series of operations are then called a macro. For example, to play a compact disc player connected to the TX-SR700/700E/600/ 600E normally, you must perform the following steps: 1.
  • Page 12 Using the macro function MACRO 1 Erasing a macro from the MACRO 1 (or 2) button SEND/LEARN 1. Press and hold down any one of the six MODE indicator buttons, press the MACRO 1 (or 2) button, and then release both buttons. When you press the MODE button, it lights green and the SEND/LEARN indicator lights.
