Summary of Contents for Yeti Cycles 2011 DJ
- Page 1 2011 DJ OWNER’S MANUAL YETI CYCLES 600 CORPORATE CIRCLE, UNIT D GOLDEN, CO 80401 888.576.9384...
- Page 2 Table of Contents Brand Overview Frame Features Geometry Maintenance Schedule Bike Setup ū Cable Setup ū Dropout Adjustment Warranty Contact Information...
-
Page 3: General Information
Overview welcOme tO the tribe Congratulations on your purchase of a new Yeti bicycle and welcome to the Yeti Tribe. We are confident your new bicycle will exceed your expectations for value, performance and ride quality. Each frameset and component has been custom specified and designed to enhance your riding experience. - Page 4 Frame Features headtube The DJ utilizes a tapered headtube for added stiffness with no weight penalty. tubinG Oversized custom hydroformed tube set with integrated yokes sqaure lOOpstays Singular square loopstays provides added stiffness and a sleek aesthetics. Accommodates a 2.5’’ tire. bOttOm bracket 73mm shell, for use with a 113mm spindle.
- Page 5 Geometry GeO me tr y dJ 100 mm fOrk 13.8 13.8 13.8 22.6 23.6 24.6 68.5 68.5 68.5 70.5 70.5 70.5 15.6-16.1 15.6-16.2 15.6-16.3 40.4-41.0 41.4-42.0 42.4-43.0 12.5 12.5 12.5 27.1 26.9 26.7 4.50 4.50 4.50 18.5 18.5 18.5 *All measurements are in inches. GeOmetry...
- Page 6 maintenance? Not sure how to work on your own bike? Contact your authorized Yeti dealer or visit www.parktool.com and check out the repair help section. This section contains detailed instruction on many of the service items listed in the maintenance schedule. Maintenance maintenance tOrque...
- Page 7 bOlt-On cable Guides 2011 Yeti frames use bolt-on cable guides for routing brake and shift housing. The guides allow for clean cable routing and thier two-piece design keeps the housing from contacting the frame and marring the finish. Cable Setup The DJ has full cable housing.
- Page 8 Adjustable Dropouts drOpOut adJustment Tighten the two M6x34mm tension bolts The 2010 DJ has adjustable dropouts that allow the chainstay length of the frame to be changed from 395mm on the frame with a 5mm allen key to achieve proper chain tension. to 410mm.
- Page 9 Fork, DH-9, AS-X, 4X, DJ, SX) disclaimer Yeti Cycles will repair or replace, at its option, any frame it determines to be defective materials and / or Yeti Cycles is not responsible for any damages to you or others arising from riding, transporting or other workmanship.
