Summary of Contents for Eliet E600
- Page 1 M A N U A L E600...
- Page 2 © ELIET Copyright 2008 ELIET. All rights reserved. The texts, images and other information in this manual are protected by copyright and also by other intellectual property rights. Therefore, nothing from this manual may be used for commercial or other purposes.
-
Page 3: Introduction
1. Introduction 1.1 Read this operating manual carefully ELIET machines are designed for safe and reliable use if they are operated in accordance with the instructions provided. Carefully read these operating instructions before using the machine. Failure to do so may result in personal injury of damage to the equipment. -
Page 4: Welcome
Welcome to the family of ELIET users. We thank you for the trust that you have placed in ELIET and we are convinced that you have purchased the very best machine. The operating life of your ELIET machine depends to a great extent on how you care for your machine. -
Page 5: Table Of Contents
4. Table of contents 1. Introduction ...........................3 1.1 Read this operating manual carefully ....................3 1.2 Identification data – ELIET Compactor E600 ................3 2. Warranty ..........................3 2.1 Warrantycard ............................3 3. Welcome ..........................4 4. Table of contents ........................5 5. Operator safety warnings....................7 5.1 For your information ..........................7... - Page 6 9.9 Lawn treatment after dethatching ....................28 9.10 Fault diagnosis ..........................29 9.10.1The engine fails to start after idle periods................29 9.10.2Engine switches off during operation .................. 30 9.10.3A trail of damage to the lawn ....................31 10. Transporting the machine ....................32 11.
-
Page 7: Operator Safety Warnings
5. Operator safety warnings ELIET cannot anticipate every situation in which a risk or danger can occur. The warnings in this operating manual and the labels on the machine are therefore not comprehensive. Even though this will be minimal, a residual risk will always be present. If you apply a working method, opera- tion or technique as the operator of the machine that is not explicitly recommended by ELIET, ensure in any case that this will not present a danger for bystanders. -
Page 8: Main Parts
6. Main parts To fully understand the content of this operating manual you need to be fully conversant with the terminology used for the descriptions. In this chapter you can find a set of parts identified by name. It is a good idea to take time to study the machine beforehand for a better understanding of the descriptions provided in this operating manual. -
Page 9: Operation
Your ELIET dealer remains at your service for any maintenance or advice, ensuring your ELIET machine is always in perfect condition. You can contact him for original ELIET parts and lubricants at any time. These service parts are manufactured according to the same strict rules and craftsmanship as the original equipment. -
Page 10: Engine
6.3 Engine 1. Spark plug 11. Fuel tap 2. Exhaust 12. Fuel supply 3. Silencer 13. Carburettor 4. Air filter 14. Engine axis 5. Fuel Tank 15. Oil filler cap / dipstick 6. Fuel filler cap 16. Oil drain plug 7. -
Page 11: Safety Instructions
7. Safety instructions 7.1 Safety messages Safety messages are provided via stickers that are applied to the machine. Take good notice of the symbols and warning messages displayed. Some safety instructions are symbolised by icons: This sticker is affixed on the belt protection cover and warns about the danger of hand injuries. - Page 12 European standards in the form of a CE label. Caution: If due to cleaning or use, safety stickers or parts displaying safety information have been damaged, removed or become illegible, they must be replaced immediately. Stickers and parts can be obtained from any authorised ELIET dealer.
-
Page 13: Safety Features
7.2 Safety features Dead man’s handle: Releasing the dead man’s handle disengages the blade drive from the engine, causing the blade axle to come to a stop. Steel compartment and mud flap: The blades are encapsu- lated in a firm steel compartment; together with the mud flap it stops moss, grass and pebbles from flying up. -
Page 14: Safety Instructions
Always refer to this instruction manual if you have any doubts about an operation that you are about to perform. • If the instructions stated in this manual are not clear to you, do not hesitate to contact your ELIET dealer for further explanation. The help desk at NV ELIET is at your service to answer all of your questions on +32 56 77 70 88. • Read the chapter meant for the dealer and verify whether the machine has been delivered in accordance with the instructions. -
Page 15: Operator's Responsibilities
• Dethatching must only be done in a forward travelling direction. In view of general safety, ELIET advises against dethatching in a backward direction. • Never dethatch when the ground is frozen. • It is recommended to work a dry lawn. Wet lawns increase the risk of accidents; extra care is necessary under these circumstances. • If the lawn is too dehydrated after a period of drought, dethatching is not recommended. The dust generated from the lawn would increase wear of the machine. -
Page 16: Personal Protective Equipment (Ppe)
Shoes with a steel top are highly recommended. • For protection of the most sensitive senses, ELIET recommends hearing protection and safety goggles. • Dethatching can produce a considerable amount of dust. If it irritates your respiratory airways, ELIET recommends you wear a dust mask (in compliance with the 89/686/EEC standard). 7.3.5 Danger zone The safe position for the operator is behind the machine, with both hands on the handlebar. • Never allow bystanders within the danger zone stretching up to 10 m around the machine dur- ing work. -
Page 17: Periodic Maintenance
(see § 11.2; page 27). A maintenance meter helps you keep track of the ma- chine’s hours of operation. • When parts require replacement as a result of wear or defect, always request original ELIET replacement parts from your ELIET dealer. This is of key importance for your own safety. (find an authorised ELIET dealer near you on www.eliet.eu) • Since wearing hearing protection can impair the ability to hear warning sounds (such as yell- ing, signal tones, etc.), increased alertness is required under those circumstances. -
Page 18: Dealer's Duties
8. Dealer’s duties 8.1 Unpacking the machine • ELIET machines are packaged in accordance with common rules for proper transportation. Deliveries are always ex factory. ELIET cannot, therefore, be held liable for any damage occurred during transport. • If the packaging is damaged upon receipt of the goods, check the state of the machine to ensure it is not damaged. Report any irregularity on the delivery order before signing for receipt. -
Page 19: Positioning The Handlebar
• The dealer makes a final test drive and checks that all devices operate properly. • The dealer checks that all safety features work perfectly. • Every Eliet dealer warrants a long life span of Eliet machines. He will lubricate the hinges before delivering the machine to the client. - Page 20 Caution: The dealer ensures that the warranty card is filled out and signed for reasons of avoiding warranty disputes. Please read the warranty conditions for more details.
-
Page 21: Operating Instructions
9. Operating instructions 9.1 Preliminary checks Caution: Try making a habit of checking the following points before getting to work with the machine: Checklist • Check the machine’s hours of operation and compare this number with the maintenance table • Check the oil level. Pull out the dipstick and check whether the oil level is below minimum. • Check that the fuel tank is full. -
Page 22: Refuelling
Warning: Wear gloves to perform this procedure. Depth adjustment is carried out by positioning the front wheels (continuous – stepless -) of the scarifi er. • Carefully place the scarifi er on an even and hard sur- face. Make sure that the blades don’t get damaged. • Place a level object of approx. -
Page 23: Preparing The Work Site
• Never refuel with the engine running. Always allow the engine to cool down for several minutes prior to refuelling. • Use fresh petrol only. ELIET is environmentally conscious and therefore recommends using unleaded petrol. Additives may be used for extended fuel freshness. -
Page 24: Starting The Engine
engine. • Use of the machine on severely dry soil is not recommended for the following reasons: • The grass will recover much slower than usual. • The lawn will be badly damaged. • The blades wear faster and require replacement sooner. • More dust will be produced, soiling the engine more quickly. • Greater dehydration of the soil than was the case already. • We strongly recommend to the treat the grass with an anti-moss herbicide or a weed killer approximately 1 week prior to dethatching so as to ensure that the moss is dead and dry. It will help the grass to thicken more easily after dethatching. 9.5 Starting the engine Caution: Never start the machine when dust has settled on the engine or between its... -
Page 25: Operating The Machine
Warning: For optimum protection of your hearing, please put on the supplied hearing protection prior to starting the engine. Engage the engine by firmly pulling the starter cord. • The engine running, set the choke handle to “Open”. This prevents the engine from getting too much fuel. Should this be forgotten, the engine will slow down and start to smoke heavily, and eventually come to a stop. -
Page 26: During Work
Warning: Never tilt the machine forward over the front wheels as this may inadvertently engage the blades. 9.6.2 During work For dethatching, the following procedure must be followed: • Always place the machine on the lawn before engaging the blades. • Push the handlebar down slightly to lift the blades. The blades should be lifted approximately 3 to 4 centimetres from the surface • Pull the dead man’s handle against the handlebar to engage the blades. • Allow the engine to acquire the proper speed. -
Page 27: Stopping The Engine
9.8 After finishing the work 9.8.1 Cleaning the machine ELIET recommends cleaning the machine after each use. We recommend performing an inspec- tion each time you clean the machine to check component and machine integrity. It allows timely intervention and prevention of any defects, ensuring a longer service life of your machine. -
Page 28: Lawn Treatment After Dethatching
Allow the engine to cool down properly before treating it with water. Any necessary replacement and/or repair works must be undertaken immediately. Visit your authorised ELIET dealer to have them carried out (find an authorised ELIET dealer near you on www.eliet.eu). -
Page 29: Fault Diagnosis
surface parasites such as moss. Opening up the soil requires aeration at a deeper level. • Sanding: Sanding the lawn can help to provide air to the top layer. Sanding can best be done after dethatching or aeration. Sharp sand is the best choice. •... -
Page 30: 2Engine Switches Off During Operation
petrol can still be incredibly flammable. c. Bad sparkplug Without the proper ignition, it will be impossible to get the engine up and running. For this reason, check the sparkplug. (Read § 11.4.1.7 Switching off the engine) d. Low on oil The engine’s crankcase is filled with engine oil to lubricate and cool the pistons. -
Page 31: Trail Of Damage To The Lawn
11.4.1.1.1), the oil safety system may be disengaged temporarily. Do not forget to switch it back on after the work is finished. Note: Neither ELIET, nor Subaru shall accept warranty claims based on a lack of oil in the machine. -
Page 32: Transporting The Machine
10. Transporting the machine • To move the machine, push the handlebar down slightly to lift the blades from the surface. • The engine must be turned off if the machine is moved for transport. • It is also recommended to remove the collector unit before loading and unloading the machine. • Only adults are permitted to move or transport the machine. • During transport children, unauthorised people or animals must not be allowed within a 10 m radius of the machine. • Carefully choose a clear and free transport path, preferably one with as few obstructions as possible. The transport path should preferably be flat, with an even surface. • If the machine topples over for some reason, set it upright as quickly as possible. It prevents oil from the crankcase entering the air filter. • Use non-slip planks for loading the machine into a van or onto a trailer. Ensure that the planks are properly fastened to the vehicle or trailer. - Page 33 • The machine’s ground clearance is 40 mm (blades in highest position). • It is recommended to cross 40-60 mm stoops in reverse. • A ramp must be provided to cross steps or curbs higher than 60 mm. For your information Machine breakage or defects resulting from incompetent operation are excluded from the warranty conditions. • Make sure the machine is properly attached in the vehicle during transport. Use the fixed chas- sis parts for attaching the ropes. For your information Always close the petrol tap on the machine before transport. Failure to do so may result in excessive amounts of petrol being fed into the engine, causing starter problems and the risk of having to change the spark plug.
-
Page 34: Maintenance
11. Maintenance 11.1 General ELIET recommends that the machine be brought to an official ELIET dealer for a major overhaul each year (find an authorised ELIET dealer near you on www.eliet.eu). Your ELIET dealer is at your service for maintenance and advice at all times. Your dealer will stock original ELIET re- placement parts and lubricants. -
Page 35: Periodic Maintenance Schedule
11.2 Periodic maintenance schedule A. Routine check before each operation • Visual check of the state of the machine • Oil level check • Cleaning the air filter • Checking and setting the depth control • Belt tension check • Lubricating chains and chain wheels. • Cleaning the machine. B. Maintenance after every 20 hours of operation • Daily maintenance • Changing the oil • Checking and/or changing the spark plug • Changing the air filter • General lubrication treatment • Belt tension adjustment... -
Page 36: Oil Level Check And Filling Up Oil
Consult your authorised ELIET service centre for assistance if necessary or to obtain replace- ment parts. Find an ELIET service centre nearest you at www.eliet.eu. 11.4.2 Oil level check and filling up oil If the oil level in the engine drops below a certain level, the electronics in the machine will go into safe-mode and the engine will switch off. -
Page 37: Belt Tension Check
automobile. • Sponge filters can be cleaned by rinsing them with some petrol and blowing them with com- pressed air. • Paper filters are cleaned by dusting them down or treating them with compressed air. • After cleaning, replace all parts in their original positions. Caution: In the event the machine has toppled over for some reason, check the air filter immediately. The unusual position of the engine may have caused oil to seep from the crankcase via the carburettor onto the air filter. Oil on the filter paper obstructs the air passage. - Page 38 Re-attach the gear box with the two tightening bolts (spanner size 10). Check the belt tension again as well as the alignment of the two pulleys. Adjust as needed. gearbox Blade shaft drive belt tension. These two belts are tightened with a flat tensioning roller that is pulled against the back of the belt when pressing down the dead man’s handle.
-
Page 39: Lubricating The Chains And Sprockets
• Wipe away any old grease before applying new lubricant. • So as to prevent the lubricant from wearing away too quickly due to the rotation of the line shaft or the gravitational pull of the line, we opt for a less viscous and more adhesive oil. • Since both the chain inside and the contact surface with the gears need to be lubricated, ELIET recommends using a combination of two lubricants. • NOVATIO PTFE OIL is a thin liquid lubricant and will easily penetrate the chain links. • NOVATIO CLEARLUBE, a more viscous oil, will cling to the outside of the chain. This lubricant diminishes the friction between the chain and the sprockets. -
Page 40: Maintenance After 20 Hours Of Operation
• At the rear of the engine, below the engine foot, a plug is screwed into the crankcase. (See the engine manual.) • Get a one litre collection reservoir before unscrewing the plug. • Empty the full contents (approx. 0.75 l) from the engine. • Replace the plug. Wipe away any spilled oil with a clean cloth. • Refill the engine with fresh 4 stroke oil. ELIET recommends a top quality high-detergent oil: SUNOCO DENALUBE SAE 20W50 API SF / CC. • Fill approx. 0.75 litres of oil into the oil filler opening. Remove any spilled oil after filling. For an accurate dipstick reading of the oil level, allow sufficient time for the oil to settle in the crank- case. -
Page 41: Checking And/Or Changing The Spark Plug
Caution: The action described here may slightly differ from what applies to your model. Read the engine manual to be sure. 11.5.2 Checking and/or changing the spark plug The type of machine is equipped with a two-cylinder engine. This means that it has two spark plugs. -
Page 42: Changing The Air Filter
11.5.3 Changing the air filter • This procedure is exactly the same as for cleaning the air filter (see § 11.4.3, ). • New, suitable air filters are available from your Eliet dealer or an authorised service centre of the relevant engine brand. - Page 43 • To reach the points indicated, some protective covers will have to be removed. (Read § 15.1 if necessary) • The bearings have dust seals to keep the dirt out. However, the lubricant applied on the bearing at the factory will also become old and dry. To compensate this lack of lubricant, new lubricant must be added from outside. • To prevent any dirt from penetrating the bearing together with the lubricant, the bearing must be cleaned first. • Spray NOVATIO KLEENSPRAY onto the bearing seals and joints. The liquid will soak off any dust attached to the bearing. • Leave the cleaning liquid to work for a few minutes.
-
Page 44: Belt Tension Adjustment
• To reach the points indicated, some protective covers and shields will have to be removed. • To avoid wear and subsequent play on hinges, lubricant must be applied to the contact surfaces that undergo friction. • It is essential to remove all old dirty lubricant and sticking dust before applying fresh lubricant. • Where possible, the hinging parts must be disassembled for proper cleaning of all elements within. • To dissolve lubricant, ELIET recommends using ELIET NOVATIO KLEENSPRAY-S. Spray the product onto the hinging parts. Leave the product for a few minutes to enable it to perform its degreasing action. • Wipe the parts clean. Repeat the procedure if necessary to ensure that the parts are completely clean. • Make sure that all of the cleaning agent is either evaporated or wiped away. - Page 45 When checking the chain tension, also check the chain and the sprocket for extensive wear. If the teeth are worn the sprockets and chain must be replaced. Visit your authorised ELIET dealer for assistance. Caution: Use this maintenance to lubricate the chain (read § 11.4.5).
-
Page 46: Changing The Blades
Chain for the transmission of the blade shaft, input rollers, pinch roller and pressure roller. • To reach the chain transmission, some protective covers will have to be removed. (Read § 15.1 if necessary) • Because this chain drive runs in one direction only it has been fitted with a single operating chain tensioner with permanent tension con- trol. A spring pulls the sprocket against the chain and automatically adjusts to the chain’s elasticity. - Page 47 Removal of the blade axle • Remove both protective covers. (Read § 15.1 if necessary) • Remove the collector unit. • Tilt the scarifier by pushing the handlebar to the ground. This provides easy access of the blade shaft. • Remove the belts from the pulley. Before the belts can be removed, the belt catchers must be moved to the front or fully disassembled by loosening all M6 bolts (spanner size 10). • Now remove the chain from the blade shaft at the other side of the machine. M6-bolts (key belt catcher • Remove the two M6 bolts, nuts and washers and then lift the plate. Use a 10 mm ring spanner. M8 bolts and nuts (key 13) tightening nut fixing screw...
- Page 48 Removing old blades and installing new blades • The blade shaft itself is constructed as a pike with a string of blades and intermediate rings on • Remove the clamping nut (M22) (spanner size 32 mm). • Now all the blades and intermediate bushings can be slid from the shaft. • Check that the hexagonal shaft does not show signs of wear (worn down by the blades). • Sand down the blade shaft somewhat (fine sanding paper P100) to remove rust, dirt etc. and to ensure that new elements can slide on Tensioning bolt smoothly. • A new blade set can be ordered from ELIET under item code BU 402 300 105. • Follow the assembly diagram below.
- Page 49 c. Placement of the blade shaft: • in the reverse order of removal. Performing checks and finishing • Check the correct placement of the blade shaft. • Check belt tension and chain tension (see above) • Replace the protective covers. • Place the machine back on all wheels.
-
Page 50: Storing The Machine
• Detach the spark plug (see § 11.5.2). Spray a little amount of penetrating oil with MoS2 into the cylinder. Pull the starter cord until the piston is in its uppermost position. Replace the spark plug. • To avoid rust on the machine touch up all chipped areas or treat them with anti-rust grease. Original paints/enamels in the appropriate colours are available from your ELIET dealer. • Store the machine in a cool, dry storage area, away from possible rain. If necessary, cover it with canvas. • Always allow the machine to cool down before storage. • If the machine is stored outdoors, it must be properly covered with canvas. Avoid direct pre-... -
Page 51: Equipment Specifications
13. Equipment specifications Engine ............. . . 9 PK Subaru EX27 Working width: . -
Page 52: Ec Declaration Of Conformity
• PrEN 13684 Garden equipment - Pedestrian controlled lawn aerators and scarifiers - Safety • DIN 33402 : Body measures The ELIET machine factory hereby declares that after performing a hazard analysis, it is fully aware of the potential hazards and risks associated with the machine. Based upon this knowl- edge, the necessary steps have been taken in line with Machine Directive 89/392/EEC in order to ensure full operator safety at correct use of the machine. -
Page 53: Annexes
15. Annexes 15.1 Removing the protective covers Caution: Removing protective covers is considered to be a maintenance operation. Always turn off the engine, remove the spark plug cover and wear appropriate clothing. Caution: Protective covers are intended to shield off dangerous areas to avoid accidents. It is therefore strictly prohibited to operate the machine or to switch on the engine or any drive with any protective cover removed. -
Page 54: Warranty Conditions
At ELIET, we have strict quality rules on designing and manufacturing products. The purpose of these rules is to guarantee a long service life and permanent safety. That is why ELIET is happy to repair any hidden defects or faults during the whole run-in period (i.e. the warranty period) free of charge, provided the prescribed procedure is followed. - Page 55 • Step 4 : The dealer orders the parts needed to perform the repairs. Next, the dealer faxes the order form together with the completed warranty form and a copy of the registration card. • Step 5 : The warranty form must be stapled to the purchase invoice and sent to ELIET or an importer/agent of ELIET.
