Panasonic TH-50PZ85U Service Manual

50 inch class 1080p plasma hdtv
Hide thumbs
Table of Contents

Advertisement

Quick Links

50 inch Class 1080p Plasma HDTV
TH-50PZ85U
Model No.
GPF11DU Chassis
© 2008 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
ORDER NO. MTNC080205CE
B34 Canada: B07

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TH-50PZ85U

Summary of Contents for Panasonic TH-50PZ85U

  • Page 1 ORDER NO. MTNC080205CE B34 Canada: B07 50 inch Class 1080p Plasma HDTV TH-50PZ85U Model No. GPF11DU Chassis © 2008 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying and distribu- tion is a violation of law.

  • Page 2: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials. 2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires have been broken or disconnected, do not attempt to repair or re-wire the units.

  • Page 3: Prevention Of Electrostatic Discharge (Esd) To Electrostatically Sensitive (Es) Devices

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor [chip] components.

  • Page 4: About Lead Free Solder (Pbf)

    2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.

  • Page 5: Service Navigation

    3 Service Navigation 3.1. Service Hint Board Name Function Board Name Function Power Supply Data Driver (Lower Right) DC-DC Converter Data Driver (Lower Center) Speaker out, Sound Processor Data Driver (Lower Left) AV Terminal, AV Switch Scan Drive Digital Signal Processor, Micon, HDMI Interface Scan out (Upper) Peaks Lite 2p Scan out (Lower)

  • Page 6: Applicable Signals

    3.2. Applicable signals * Mark: Applicable input signal for Component (Y, PB, PR) and HDMI horizontal frequency (kHz) vertical frequency (Hz) COMPONENT HDMI 525 (480) / 60i 15.73 59.94 525 (480) /60p 31.47 59.94 750 (720) /60p 45.00 59.94 1,125 (1,080) /60i 33.75 59.94 1,125 (1,080) /60p...

  • Page 7: Specifications

    4 Specifications Power Source AC 120 V, 60 Hz Power Consumption Maximum 690 W Standby condition 0.2 W Plasma Display panel Drive method AC type Aspect Ratio 16:9 Visible screen size 50 inch class (49.9 inches measured diagonally) (W × H × Diagonal) 43.5 inch ×...

  • Page 8: How To Enter Into Service Mode

    5 Service Mode 5.1. How to enter into Service Mode While pressing [VOLUME ( - )] button of the main unit, press [INFO] button of the remote control three times within 2 seconds. 5.1.1. Key command [1] button...Main items Selection in forward direction [2] button...Main items Selection in reverse direction [3] button...Sub items Selection in forward direction [4] button...Sub items Selection in reverse direction...

  • Page 9: Contents Of Adjustment Mode

    Contents of adjustment mode 5.1.2. • Value is shown as a hexadecimal number. • Preset value differs depending on models. • After entering the adjustment mode, take note of the value in each item before starting adjustment. Main item Sub item Sample Data Remark ADJUST...

  • Page 10: Service Tool Mode

    5.2. Service tool mode 5.2.1. How to access 1. Select [SRV-TOOL] in Service Mode. 2. Press [OK] button on the remote control. 5.2.2. Display of SOS History SOS History (Number of LED blinking) indication. From left side; Last SOS, before Last, three occurrence before, 2nd occurrence after shipment, 1st occurrence after shipment. This indication except 2nd and 1st occurrence after shipment will be cleared by [Self-check indication and forced to factory ship- ment setting].

  • Page 11: Hotel Mode

    5.3. Hotel mode 1. Purpose Restrict a function for hotels. item Function 2. Access command to the Hotel mode setup menu Mode Select hotel mode ON/OFF In order to display the Hotel mode setup menu, please Input Select input signal modes. enter the following command (within 2 second).

  • Page 12: Troubleshooting Guide

    6 Troubleshooting Guide Use the self-check function to test the unit. 1. Checking the IIC bus lines 2. Power LED Blinking timing 6.1. Check of the IIC bus lines 6.1.1. How to access Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds.

  • Page 13: Power Led Blinking Timing Chart

    6.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit.
  • Page 14 6.3. No Power First check point There are following 2 states of No Power indication by power LED. 1. No lit 2. Red is lit then turns red blinking a few seconds later. (See 6.2.)
  • Page 15 6.4. No Picture...

  • Page 16: Local Screen Failure

    6.5. Local screen failure Plasma display may have local area failure on the screen. Fig-1 is the possible defect P.C.B. for each local area. Fig-1...

  • Page 17: Disassembly And Assembly Instructions

    7 Disassembly and Assembly Instructions 7.1. Remove the Rear cover 7.4. Remove the PB-Board 1. See Service Hint (Section 3) 1. Unlock the cable clampers to free the cable. 2. Remove the screws (×2 7.2. Remove the Rear cover bottom 3.

  • Page 18: Remove The P(Main)-Board

    7.6. Remove the P(MAIN)-Board 7. Remove the P(MAIN)-Board. Caution: To remove P.C.B. wait 1 minute after power was off for dis- charge from electrolysis capacitors. 1. Unlock the cable clampers to free the cable. 2. Disconnect the couplers (P2, P6, P7, P11, P12, P25, P52, P54 and P56).
  • Page 19 7.7. Remove Rear Terminal 7.10. Remove the Side control unit cover assy 1. Disconnect the connectors (A52). (See section 7.8.) , ×2 1. Remove the screws (×4 2. Remove the Rear Terminal cover. 2. Remove the screws (×4 ) and remove the Side control unit assy.
  • Page 20 7.12. Remove the Side terminal unit metal frame. assy 1. Unlock the cable clampers to free the cable. 2. Disconnect the connectors (GH11 and G51). 3. Remove the screws (×3 ) and remove the Side termi- nal unit assy. 6. Remove the screws (×2 ) and remove the Side control panel bottom and the Control button.

  • Page 21: Remove The Sd-Board

    7.15. Remove the SD-Board 6. Remove the G-Board and the GH-board. 1. Remove the flexible cables (SD1, SD2, SD3, SD4 and SD5) connected to the SD-Board. 2. Remove the flexible cable (SU11-SD11) and the bridge connectors (SC42-SD42 and SC46-SD46). 3. Remove the molding prop (×1 4.
  • Page 22 7.17. Remove the SS-Board 7.19. Remove the Stand brackets 1. Unlock the cable clampers to free the cable. 1. Remove the Plasma panel section from the servicing 2. Disconnect the connectors (SS11, SS12, SS24, SS33 stand and lay on a fiat surface such as a table (covered) and SS35).

  • Page 23: Remove The C3-Board

    7.23. Remove the C3-Board 6. Disconnect the flexible cables (CB1, CB2, CB3, CB4, CB5 and CB6). 1. Remove the Side terminal unit assy. (See section 7.12.) 7. Disconnect the flexible cables (C10 and C11). 2. Remove the DD-Heat-sink fastening screws (×8 8.

  • Page 24: Remove The Plasma Panel Sec- Tion From The Cabinet Assy (Glass)

    7.25. Remove the Plasma panel sec- bottom of the cabinet assy forward, lift, and remove. tion from the Cabinet assy (glass) 1. Remove the stand brackets (left, right) fastening screw (×1 each). 4. Remove the spacers and spacer rings (×6 2.
  • Page 25 7.26. Remove the K-Board and S- 7.27. Remove the plasma panel (fin- Board ished) 1. Remove the Cabinet assy. (See section 7.25.) 1. Place the new plasma panel (finished) on the flat surface of the table (covered by a soft cloth), with the plasma 2.

  • Page 26: Measurements And Adjustments

    8 Measurements and Adjustments 8.1. Adjustment Procedure 8.1.1.2. Adjustments Adjust driver section voltages referring the panel data on the 8.1.1. Driver Set-up panel data label. Check or adjust the following voltages with the multimeter. 8.1.1.1. Item / Preparation 1. Input a white signal to plasma video input. Name Test Point Voltage...

  • Page 27: Initialization Pulse Adjust

    8.1.2. Initialization Pulse Adjust 1. Input the White signal to plasma video input. 2. Set the picture controls as follows. Picture menu : Vivid Normal : Set Aspect : Full 3. Connect Oscilloscope to TPSC1 (SC). Check the voltage (T2) at 100μs period on the down slope. Test point Volume Level...
  • Page 28 8.1.4. Adjustment Volume Location 8.1.5. Test Point Location...

  • Page 29: White Balance Adjustment

    8.2. Adjustment 8.2.1. White balance adjustment Name of measuring instrument Connection Remarks • W/B pattern Component input • Color analyzer Panel surface (Minolta CA-100 or equivalent) Procedure Remarks • Ensure aging is adequate. • Make sure the front panel to be used on the final set is fitted. •...

  • Page 31: Block Diagram

    FAN POWER +5V(S) +30V(BT) BT+30V PB30 +9V(S) +9/7.2V PB31 L6FAYYYH0050 FAN(80MM) 2 DIGITAL SIGNAL PROCESSOR FAN SOS PB32 FAN SOS DET STB+3.3V +5V(STB) +3.3V(STB) CIRCUIT PB34 PB36 (LED:11TIMES) PB37 PB FAN CONTROL TNPA4243AHS TH-50PZ85U TH-50PZ85U Block (1/6) Diagram Block (1/6) Diagram...
  • Page 32 SCAN OUT (LOWER) TXNSD1RJTU DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DATA DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER DRIVER TH-50PZ85U TH-50PZ85U Block (2/6) Diagram Block (2/6) Diagram...
  • Page 33 SD DATA IC8004 KEYSCAN1 IIC0 CLOCK CLOCK GEN KEY SWITCH SD DATA SD CARD IC8502 IIC1 RESET NOR FLASH IIC2 SBI2 CPU BUS I/F SBO2 EEPROM IIC_IF IC8503 IC8001 Peaks Lite2p IIC3 TH-50PZ85U TH-50PZ85U Block (3/6) Diagram Block (3/6) Diagram...
  • Page 34 SW2500 PB31 D851 L6FAYYYH0050 FAN(80MM) 2 FAN CONT PB32 D852 (LED:11TIMES) POWER FAN CONT D853 PB34 SWITCH D861 +15V(FAN) PB36 PB37 IC850 D860 +9/7.2V FAN A-E POWER SWITCH TNPA4499S TH-50PZ85U TH-50PZ85U FAN CONTROL TNPA4243AHS Block (4/6) Diagram Block (4/6) Diagram...
  • Page 35 (LED:6TIMES) SOS6_SC1 SOS6_SC1 IIC_DATA2 RESET RESET (LED:7TIMES) SOS7_SC2 SOS7_SC2 COLD IIC2 IIC_CLK2 +15V(P) PANEL SOS PANEL SOS +15V(P) AC INLET PANEL STATUS PANEL STATUS AC100V P (AC) ETX2MM704MGA +15V(P) AC CORD 50/60Hz TH-50PZ85U TH-50PZ85U Block (5/6) Diagram Block (5/6) Diagram...
  • Page 36 VIDEO DATA +5V(P) BUFFER IC17204 BUFFER BUFFER IC17301 +5V(P)DET IC17101-03 BUFFER CLOCK IC17104-06 BUFFER CONTROL DATA VIDEO DATA SS35 BUFFER +5V(P) +5V(P) +5V(P)DET IC17302-04 MD50F11A1J PANEL DRIVER PANEL DRIVER PLASMA PANEL PANEL DRIVER TH-50PZ85U TH-50PZ85U Block (6/6) Diagram Block (6/6) Diagram...

  • Page 37: Wiring Connection Diagram

    10 Wiring Connection Diagram 10.1. Caution statement. Caution: Please confirm that all flexible cables are assembled correctly. Also make sure that they are locked in the connectors. Verify by giving the flexible cables a very slight pull. 10.2. Wiring (1)
  • Page 38 10.3. Wiring (2)
  • Page 39 10.4. Wiring (3)
  • Page 40 10.5. Wiring (4)

  • Page 41: Schematic Diagram

    11 Schematic Diagram 11.1. Schematic Diagram Note...

  • Page 42: P(Ac)-Board Schematic Diagram

    11.2. P(AC)-Board Schematic Diagram AC CORD P(MAIN)-BOARD (P52) COLD P(MAIN)-BOARD (P54) P(MAIN)-BOARD (P56) STB ERROR DET COLD P(AC)-BOARD ETX2MM704MGA COLD POWER CONTROL <Exchange board only> TH-50PZ85U TH-50PZ85U P(AC)-Board Schematic Diagram P(AC)-Board Schematic Diagram...

  • Page 43: P(Main)-Board Schematic Diagram

    <Exchange board only> PFC CONTROL <Exchange board only> RECTIFIER <Exchange board only> POWER CONTROL <Exchange board only> <Exchange board only> COLD COLD COLD COLD CONTROL SWITCH <Exchange board only> +5V(P) <Exchange board only> TH-50PZ85U TH-50PZ85U P(MAIN)-Board Schematic Diagram P(MAIN)-Board Schematic Diagram...

  • Page 44: Pb-Board Schematic Diagram

    TP850 C861 0.1u C869 TP852 470u D859 R859 R871 B0JCME000037 C862 C860 L852 R872 0.1u 470u G0C101KA0167 TP851 D860 MAZ81100ML R874 R861 4.7k TP853 C859 D862 MAZ80330LL 0.1u R867 PB30 A-BOARD (A30) TH-50PZ85U TH-50PZ85U PB-Board Schematic Diagram PB-Board Schematic Diagram...
  • Page 45 GS-BOARD TNPA4504S A-BOARD R7793 R7794 0 GS52 ZA7701 ZA7702 (A52) K4CZ01000027 K4CZ01000027 ZA3702 K4CZ01000027 ZA3701 K4CZ01000027 SW2500 K0F122A00172 POWER SW AV3_S_DET S-BOARD TNPA4499S A-BOARD (A51) TH-50PZ85U TH-50PZ85U G, GS, K and S-Board Schematic Diagram G, GS, K and S-Board Schematic Diagram...

  • Page 46: Gh-Board Schematic Diagram

    HDMI_5V_DET3 CLK+ 0.01u 0.01u HDMI IN 3 R3826 DDC5V R3827 R3828 IC3801 C1AB00002835 R3811 R3829 4.7k R3830 HDMI EQUALIZER C3816 C3812 R3831 HDMI_CE1 0.01u 0.1u A-BOARD (A11) GH11 ZA3802 K4AD01D00005 ZA3801 K4AD01D00005 TH-50PZ85U TH-50PZ85U GH-Board Schematic Diagram GH-Board Schematic Diagram...
  • Page 47 VDD33 IC8001 IC8001 J0JHC0000045 0.1u IC8001 AF20 VDDIO IC8001 LVVDD12 IC8001 AC10 VDD33 IC8001 IC8001 AF21 C8080 IC8001 AF26 VDDIO C8076 C8075 IC8001 AC11 VDD33 IC8001 IC8001 AF24 0.1u 0.1u TH-50PZ85U TH-50PZ85U A-Board (1/12) Schematic Diagram A-Board (1/12) Schematic Diagram...
  • Page 48 IC8003 MMDQ28 AB16 IC8001 CH0DQ16 VJUMP1005-S CH0DQ29 IC8003 R8020 MMDQ29 AA16 IC8001 CH0DQ23 R8021 VJUMP1005-S CH0DQ30 IC8003 MMDQ30 AD16 IC8001 CH0DQ20 R8022 VJUMP1005-S CH0DQ31 IC8003 MMDQ31 AF16 IC8001 CH0DQ19 IC8003 TH-50PZ85U TH-50PZ85U A-Board (2/12) Schematic Diagram A-Board (2/12) Schematic Diagram...
  • Page 49 TP8519 to other devices NOR FLASH TVRP753S C4780 0.1u TP8518 SUB3.3V GS-BOARD R8512 R8533 (GS52) TP8546 TP8548 R8528 TRST TP8544 R8529 TRST R8530 to (1/12) TP8547 R8532 R5058 R5069 R5137 TH-50PZ85U TH-50PZ85U A-Board (3/12) Schematic Diagram A-Board (3/12) Schematic Diagram...
  • Page 50 +INC PGND AG_KEY3 R5605 R5612 12.7k -INC PEAKS-LITE2 RESET IC3017 SUB3.3V C0EBM0000026 RESET IC F15V R5747 R5748 C5767 R5762 0.01u XRST to (1/12) AG_DTV_XRST C5766 to (3/12)(7/12) 0.01u C5765 0.047u TH-50PZ85U TH-50PZ85U A-Board (4/12) Schematic Diagram A-Board (4/12) Schematic Diagram...
  • Page 51 DTV_V R3077 R3068 *C3057 MAIN_R RF_V *R3316 *L3309 *R3307 J0JCC0000269 PC_G_IN MAIN_L 4.7k R3078 *R3301 *R3303 *R3313 AAM_R AAM_L *R3302 *R3305 *C3061 C3023 *R3311 PC_R_IN *R3310 PC_V_IN PC_H_IN RF_L RF_R TH-50PZ85U TH-50PZ85U A-Board (5/12) Schematic Diagram A-Board (5/12) Schematic Diagram...
  • Page 52 FL4000 K7AAAY000003 TUNER_SUB_ON DVDD1.8V AG_TV_SUB_ON J0HAAB000036 (7/12) TP3528 OPTICAL G-BOARD ECO_ON AG_ECO_ON (G51) AUDIO ALL_OFF C3157 VIH > 2.2V => PowerDown AC_GOOD/KEY VIL < 0.8V => active 0.1u >> RESETB TH-50PZ85U TH-50PZ85U A-Board (6/12) Schematic Diagram A-Board (6/12) Schematic Diagram...
  • Page 53 AG_AI_SENSOR C1112 To D pri 0.1u to (12/12) AG_PANEL_READY AG_PANEL_READY AG_PANEL_ARARM AG_PANEL_ARARM Power Supply AG_ODU_DET/KEY3 to (4/12) AG_ODU_DET/KEY3 AG_KEY1(CON-PANE) to (3/12) AG_KEY1(CON-PANE) AG_R_LED_ON AG_R_LED_ON to (6/12) AG_RMIN to (6/12) AG_RMIN TH-50PZ85U TH-50PZ85U A-Board (7/12) Schematic Diagram A-Board (7/12) Schematic Diagram...
  • Page 54 VOP11 C4224 LOSD13 VOP11 VOP20 6.3V RE_O- LOSD10 VOP20 VOP21 LOSD11 VOP21 RE_O+ C4213 C4214 C4215 ADIN 0.1u 0.1u 0.1u OSDYS ADIN R4294 EXB28V470JX GenX5 to (7/12) AG_BACK_VOUTENB AG_BACK_VOUTENB R4309 TH-50PZ85U TH-50PZ85U A-Board (8/12) Schematic Diagram A-Board (8/12) Schematic Diagram...
  • Page 55 L4500 D4513 J0JHC0000078 Q4530 MAZ30560ML SUB3.3V SUB5V 2SB0709A0L L4502 N.C. JK4500 J0JHC0000078 RXB_CN K1FY119D0003 CLK- RXB_CP CLKG HDMI2 R4568 Q4531 CLK+ RXB_0N 2SB0709A0L GH-BOARD RXB_0P (GH11) RXB_1N RXB_1P RXB_2N RXB_2P TH-50PZ85U TH-50PZ85U A-Board (9/12) Schematic Diagram A-Board (9/12) Schematic Diagram...
  • Page 56 SPDIF HDMI_LRCK AG_HPD3 DDCA_SCL EXB28V330JX HDMI_BCLK to (5/12) HDMI_BCLK AG_HDMI_REP_EN DDCA_SDA HDMI_SPDIF AG_HDMI_REP_EN C4614 0.1u HDMI_SPDIF C4613 C4634 C4612 0.01u AG_HDMI_5V_DET1 AG_HDMI_5V_DET1 AG_HDMI_5V_DET2 AG_HDMI_5V_DET2 AG_HDMI_CEC AG_HDMI_CEC AG_HDMI_MUX_SEL AG_HDMI_MUX_EN AG_HPD4 AG_HDMI_5V_DET4 TH-50PZ85U TH-50PZ85U A-Board (10/12) Schematic Diagram A-Board (10/12) Schematic Diagram...
  • Page 57 C8376 C8337 0.01u 0.1u 0.01u 0.1u 0.1u C8338 0.1u C8339 C8340 SUB5V BT30V 0.1u 0.1u C8374 C8377 C8378 C8379 C8370 C8371 C8380 0.1u 0.01u 0.1u 1000p 0.01u 0.1u C8346 0.01u TH-50PZ85U TH-50PZ85U A-Board (11/12) Schematic Diagram A-Board (11/12) Schematic Diagram...
  • Page 58 C4744 C4745 C4746 C4771 C4772 C4773 C4774 C4775 C4776 C4777 C4778 C4779 0.1u 1000p 1000p 1000p 0.1u 1000p 0.1u 0.1u 1000p 1000p 0.1u 1000p 0.1u 0.1u 1000p 0.1u 0.1u 0.1u TH-50PZ85U TH-50PZ85U A-Board (12/12) Schematic Diagram A-Board (12/12) Schematic Diagram...
  • Page 59 R9871 B0JCCE000008 SC_DRV_RST FP_CQR5 FP_SC3 R9869 +15V Q9806 2SD0601A0L D9807 +15V P15V_MOTO PA9900 R9870 B0JCCE000008 K5H5022A0031 +15V C9859 C9858 0.01u R9197 SC_CQR4 CQR4 C9168 R9120 SC_CQR5 0.1u EXB2HV103JV CQR5 R9202 TH-50PZ85U TH-50PZ85U D-Board (1/6) Schematic Diagram D-Board (1/6) Schematic Diagram...
  • Page 60 IC9013 P15V FPGANRST C0JBAZ002060 C9161 BUS SW STB3.3V 0.1u P3.3V C9055 R9186 0.1u C9136 STB_SCL01 R9187 0.1u R9201 P3V_SCL1 R9198 JTAG CHAIN STB_SDA01 R9200 P3V_SDA1 DATA_DRIVER SS_PULSE SC_PULSE to ucom/FPGA/PD2 TH-50PZ85U TH-50PZ85U D-Board (2/6) Schematic Diagram D-Board (2/6) Schematic Diagram...
  • Page 61 DRVCLKD1 IC9400 DOUTUC01 IOSW INPUT L8R_DRVCLKD2 RE_O- IC9400 DRVCLKD2 IC9400 IC9400 DOUTUB01 L8R_DRVCLKD3 RE-(LSB) R9246 RE_O+ IC9400 DRVCLKD3 IC9400 RE+(LSB) FULL0 IC9400 FULL0 FULL1 IC9400 FULL1 P3V_SDA02 IC9400 P3V_SCL02 IC9400 TH-50PZ85U TH-50PZ85U D-Board (3/6) Schematic Diagram D-Board (3/6) Schematic Diagram...
  • Page 62 AA23 IC9400 AE24 TCPOUT_D R9248 L8DR_DQ30 IC9401 DQ30 0.1u IC9400 AB24 L8DR_DQ31 IC9401 DQ31 IC9400 VREF1 L8DR_DQS0 C9131 IC9401 DQS0 L8DR_DQS1 0.1u IC9401 DQS1 L8DR_DQS2 IC9401 DQS2 L8DR_DQS3 IC9401 DQS3 TH-50PZ85U TH-50PZ85U D-Board (4/6) Schematic Diagram D-Board (4/6) Schematic Diagram...
  • Page 63 C9181 0.1u FULL0 IC9300 FULL0 P3V_SDA02 IC9300 FULL1 IC9300 FULL1 P3V_SCL02 IC9300 P3.3V R9163 D9025 B0JCCE000008 R9157 4.7k Q9059 C9068 R9162 2SD0601A0L 100k 0.01u R9168 D-BOARD TNPA4439AJS (5/6) C1-BOARD (C11) TH-50PZ85U TH-50PZ85U D-Board (5/6) Schematic Diagram D-Board (5/6) Schematic Diagram...
  • Page 64 R9190 R9125 4.7k 4.7k D9024 D9026 B0JCCE000008 R9214 B0JCCE000008 100k Q9060 C9069 C9067 Q9058 Q9061 R9191 R9130 2SD0601A0L 100k 100k 2SD0601A0L 0.01u 0.01u 2SD0601A0L R9124 R9118 C2-BOARD C2-BOARD TH-50PZ85U (C21) (C22) TH-50PZ85U D-Board (6/6) Schematic Diagram D-Board (6/6) Schematic Diagram...

  • Page 65: C1-Board (1/2) Schematic Diagram

    PANEL DATA PANEL DATA DRIVER DRIVER VDA_75V VDA_75V C17135 C17137 250V 250V 0.15u 0.15u C17141 C17143 250V C17147 250V C17149 0.15u 0.15u F1H1A1050032 C1_5V C1_5V PANEL DATA PANEL DATA DRIVER DRIVER TH-50PZ85U TH-50PZ85U C1-Board (1/2) Schematic Diagram C1-Board (1/2) Schematic Diagram...

  • Page 66: C1-Board (2/2) Schematic Diagram

    DRIVER R17151 EXB38V470JV AB_LED61 AA_LED6 AB_LED62 AB_ODED61 AB_ODED62 AA_ODED6 C17131 C1_5V R17153 0.1u EXB38V681JV VDA_75V R17131 R17132 EXB38V471JV EXB38V471JV C17139 250V 0.15u C17145 250V C17151 0.15u C1_5V PANEL DATA DRIVER TH-50PZ85U TH-50PZ85U C1-Board (2/2) Schematic Diagram C1-Board (2/2) Schematic Diagram...

  • Page 67: C2-Board (1/2) Schematic Diagram

    R17214 EXB38V471JV VDA_75V R17278 EXB38V471JV ZA17205 K4AD01Z00001 C17227 250V R17277 ZA17204 EXB38V471JV 0.15u K4AD01Z00001 C17232 R17216 C17208 250V EXB38V471JV 0.15u ZA17201 ZA17202 ZA17203 K4AD01Z00001 K4AD01Z00001 K4AD01Z00001 C2_5V PANEL DATA DRIVER TH-50PZ85U TH-50PZ85U C2-Board (1/2) Schematic Diagram C2-Board (1/2) Schematic Diagram...

  • Page 68: C2-Board (2/2) Schematic Diagram

    R17225 R17226 EXB38V471JV EXB38V471JV EXB38V471JV EXB38V471JV C17230 C17229 250V 250V 0.15u 0.15u C17234 C17235 250V C17207 250V C17213 0.15u 0.15u C2_5V C2_5V CB10 CB11 PANEL DATA PANEL DATA DRIVER DRIVER TH-50PZ85U TH-50PZ85U C2-Board (2/2) Schematic Diagram C2-Board (2/2) Schematic Diagram...

  • Page 69: C3-Board (1/2) Schematic Diagram

    C17316 0.1u AA_DDB4 AA_DDC4 AB_DDB4 AB_DDC4 AA_DDA7 AB_DDA7 AA_DDB7 AB_DDB7 AA_DDC7 R17350 EXB38V470JV AA_DDA6 AB_DDC7 AB_DDA6 AA_DDB6 AB_DDB6 AA_DDC6 AB_DDC6 C2-BOARD R17351 (C26) 10 GND EXB38V470JV R17352 R17353 EXB38V471JV EXB38V471JV TH-50PZ85U TH-50PZ85U C3-Board (1/2) Schematic Diagram C3-Board (1/2) Schematic Diagram...

  • Page 70: C3-Board (2/2) Schematic Diagram

    VDA_75V VDA_75V C17321 C17319 250V 250V 0.15u 0.15u R17341 4.7k C17324 C17326 250V C17328 0.15u 250V C17310 0.15u F1L2E154A009 F1H1A1050032 C3_5V C3_5V CB15 CB13 PANEL DATA PANEL DATA DRIVER DRIVER TH-50PZ85U TH-50PZ85U C3-Board (2/2) Schematic Diagram C3-Board (2/2) Schematic Diagram...

  • Page 71: Sc-Board (1/3) Schematic Diagram

    AND 44V OR LESS 1.4k CQR3 AA_CQR3 C16480 MAIN_STOP R16541 0.1u OC2B TP28 TP29 TP30 TP31 TP32 TP33 TP34 TP35 CQR4 AA_CQR4 R16543 IC16472 C0JBAA000377 10 GND TP13 AND GATE IC16563 C0JBAZ002811 BUFFER TH-50PZ85U TH-50PZ85U SC-Board (1/3) Schematic Diagram SC-Board (1/3) Schematic Diagram...

  • Page 72: Sc-Board (2/3) Schematic Diagram

    16V_F R16666 D16667 MA2J11100L COLD FLOATING GND D16668 MA3X152D0L D16659 C16806 B0HCMM000014 160V R16669 AA_SCSU 100u 4.7k R16657 Q16665 6.8k PC16710 B1ABCF000231 R16670 Q16664 B3PBA0000223 B1HFPFA00001 D16669 R16667 R16672 MA2J11100L TH-50PZ85U TH-50PZ85U SC-Board (2/3) Schematic Diagram SC-Board (2/3) Schematic Diagram...

  • Page 73: Sc-Board (3/3) Schematic Diagram

    16V_F C16797 D16872 IC16801 MA2J11100L R16878 R16791 0.1u F16V DET VSET2,6 C0DBEYY00078 R16573 OPERATES AT 21V OR MORE D16791 IC16564 R16797 VSET2,6 R16807 R16808 R16792 MAZ82000ML VSET2,6 4.7k 4.7k C0JBAB000715 TH-50PZ85U TH-50PZ85U SC-Board (3/3) Schematic Diagram SC-Board (3/3) Schematic Diagram...
  • Page 74 OUT63 OUT6 OUT63 OUT6 AB_1021 AB_1080 AC_1012 AC_953 AB_1020 AC_1013 AC_952 AB_1019 AC_1014 AC_951 AB_1018 AB_1017 AC_1015 AC_1016 R14380 R14901 C14939 C14940 C14941 C14942 VF5V 470p 1000p 470p 470p VF5V TH-50PZ85U TH-50PZ85U SU-Board (1/3) Schematic Diagram SU-Board (1/3) Schematic Diagram...
  • Page 75 C14921 C14930 C14922 R14921 250V 250V 250V 250V 250V 250V 250V 250V 220k 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u VF5V VF5V SU41 SC-BOARD (SC41) ZA14901 K4AD01Z00003 ZA14902 K4AD01Z00003 TH-50PZ85U TH-50PZ85U SU-Board (2/3) Schematic Diagram SU-Board (2/3) Schematic Diagram...
  • Page 76 AG_741 AG_680 AH_612 AH_673 AI_605 AI_544 AG_742 AG_679 AH_611 AH_674 AI_606 AI_543 AG_743 AH_610 AI_607 AG_744 AH_609 AI_608 R14392 R14398 VF5V C14938 C14931 C14936 C14937 470p 1000p 470p 470p VF5V TH-50PZ85U TH-50PZ85U SU-Board (3/3) Schematic Diagram SU-Board (3/3) Schematic Diagram...
  • Page 77 250V 250V C14360 C14361 VF5V 250V 250V 250V 250V 0.1u 0.1u 250V 250V 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u VSET2_O 5V_F1_B VSET6_O SD42 SC-BOARD (SC42) ZA14951 K4AD01Z00003 ZA14952 K4AD01Z00003 SCN_PRO TH-50PZ85U TH-50PZ85U SD-Board (1/3) Schematic Diagram SD-Board (1/3) Schematic Diagram...
  • Page 78 AG_204 AH_136 AH_197 AF_271 AF_334 AG_266 AG_203 AH_135 AH_198 AG_267 AH_134 AF_270 AG_268 AF_269 AH_133 R14365 VF5V VF5V C14976 C14981 C14989 C14971 1000p 470p 470p 470p VF5V VF5V SCN_PRO SCN_PRO TH-50PZ85U TH-50PZ85U SD-Board (2/3) Schematic Diagram SD-Board (2/3) Schematic Diagram...
  • Page 79 AB_OC2A C14944 C14945 R14937 1000p 100p C14990 0.1u AA_OC1U1 VF5V AA_OC1U2 VSET2_O R14943 VSET6_O R14931 R14971 AA_CLKU1 R14349 AA_CLKU2 AA_OC2U1 SCN_PRO AA_OC2U2 AA_LATU1 AA_LATU2 AA_SIU SIDE SD11 SU-BOARD (SU11) SCN_PRO TH-50PZ85U TH-50PZ85U SD-Board (3/3) Schematic Diagram SD-Board (3/3) Schematic Diagram...

  • Page 80: Ss-Board (1/2) Schematic Diagram

    2.2k MA2J11100L A_-INPUT R16252 B_OUTPUT R16255 Q16251 1.2k 2SD0601A0L TP37 A_+INPUT B_-INPUT R16253 AA_SOS8 B_+INPUT C16251 R16254 TPSOS8 6.8k IC16251 TP33 TP34 TP21 C0BBBA000024 R16256 1.5k ERROR DET R16251 1.4k TH-50PZ85U TH-50PZ85U SS-Board (1/2) Schematic Diagram SS-Board (1/2) Schematic Diagram...

  • Page 81: Ss-Board (2/2) And Ss2-Board Schematic Diagram

    250u C16311 R16312 R16314 120k 66.5k VOUT C16312 VR16000 SS2-BOARD 4700p TP24 TP25 TP26 TP27 TP28 TP29 TP30 TP31 D16311 TNPA4405S MAZ81500ML R16317 C16313 R16315 1.24k TH-50PZ85U TH-50PZ85U SS-Board (2/2) and SS2-Board Schematic Diagram SS-Board (2/2) and SS2-Board Schematic Diagram...

  • Page 82: Printed Circuit Board

    12 Printed Circuit Board 12.1. P(AC)-Board P(AC)-BOARD ETX2MM704MGA (FOIL SIDE) P(AC)-BOARD ETX2MM704MGA (COMPONET SIDE) P(AC) Parts Location P-BOARD (FOIL SIDE) TEST POINT IC501 IC555 MODULE MC501 Parts Location P-BOARD (COMPONENT SIDE) TEST POINT IC501 IC555 MODULE MC501 TH-50PZ85U TH-50PZ85U P(AC)-BOARD ETX2MM704MGA P(AC)-BOARD ETX2MM704MGA...
  • Page 83 12.2. P(MAIN)-Board P(MAIN)-BOARD ETX2MM704MGL (FOIL SIDE) TH-50PZ85U TH-50PZ85U P(MAIN)-BOARD ETX2MM704MGL P(MAIN)-BOARD ETX2MM704MGL...
  • Page 84 MC201 Q403 MC203 MC203 TEST POINT MC301 MC301 TEST POINT MC352 MC352 MC401 MC401 MC451 MC451 MC502 MC502 MC552 MC552 MC601 MC601 MC602 MC602 TP10 MC603 MC603 TP10 MC606 MC606 MC701 MC701 TH-50PZ85U TH-50PZ85U P(MAIN)-BOARD PARTS LOCATION P(MAIN)-BOARD PARTS LOCATION...
  • Page 85 P(MAIN)-BOARD ETX2MM704MGL (COMPONENT SIDE) TH-50PZ85U TH-50PZ85U P(MAIN)-BOARD ETX2MM704MGL P(MAIN)-BOARD ETX2MM704MGL...
  • Page 86 R 8 1 1 C 8 2 1 L 8 0 5 C 8 1 4 C 8 1 2 C 8 2 2 Z A 8 0 1 TH-50PZ85U TH-50PZ85U G-BOARD TNPA4503S GS-BOARD TNPA4504S GH-BOARD TNPA4506S G-BOARD TNPA4503S GS-BOARD TNPA4504S...
  • Page 87 PB32 Q 2 5 1 1 PB32 C852 TNPA4499 C860 D852 PB31 R851 PB30 PB30 PBMM1 CATS PBMM1 POWER LED C878 C877 TH-50PZ85U TH-50PZ85U K-BOARD TNPA4502S K-BOARD TNPA4502S S-BOARD TNPA4499S S-BOARD TNPA4499S PB-BOARD TNPA4243AHS SS2-BOARD TNPA4405S PB-BOARD TNPA4243AHS SS2-BOARD TNPA4405S...
  • Page 88 C 3 0 2 1 L 3 3 0 8 F L 3 0 0 1 R 3 3 0 1 R 8 7 0 5 I C 8 5 0 3 R 3 0 7 6 TH-50PZ85U TH-50PZ85U A-BOARD TNPH0721ACS A-BOARD TNPH0721ACS...
  • Page 89 TP8556 TP4001 TP5400 TP8557 TP4002 TP5600 TP8558 TP4003 TP5601 TP8559 TP4005 TP5602 TP8560 TP4006 TP8300 TP8561 TP4008 TP8301 TP8562 TP4105 TP8302 TP8563 TP4212 TP8303 TP8564 TP4213 TP8500 TP4214 TP8501 TPSOS TP4215 TP8502 TH-50PZ85U TH-50PZ85U A-BOARD PARTS LOCATION A-BOARD PARTS LOCATION...
  • Page 90 J S 3 0 5 3 J S 3 0 5 4 J S 3 0 5 5 F L 3 0 3 8 F L 3 0 3 9 A M M 4 TH-50PZ85U TH-50PZ85U A-BOARD TNPH0721ACS A-BOARD TNPH0721ACS...
  • Page 91 R 2 0 8 R 1 3 9 R 1 3 8 R 1 3 7 R 1 7 6 R 1 4 6 D 0 2 5 C 1 3 8 R 1 9 4 TH-50PZ85U TH-50PZ85U D-BOARD TNPA4439AJS D-BOARD TNPA4439AJS...
  • Page 92 R 1 9 0 C 1 3 7 C 0 6 9 O R D E R N O . F L 0 0 4 R 1 6 8 R 1 2 4 P b F TH-50PZ85U TH-50PZ85U D-BOARD TNPA4439AJS D-BOARD TNPA4439AJS...
  • Page 93 C 1 0 4 C 1 0 3 C 1 0 9 D 1 0 4 D 1 0 2 D 1 0 5 D 1 0 1 D 1 0 3 D 1 0 6 TH-50PZ85U TH-50PZ85U C1-BOARD TXNC11RJTU C1-BOARD TXNC11RJTU...
  • Page 94 C 2 0 5 R 2 1 1 R 2 2 3 R 2 3 0 D 2 0 3 D 2 0 5 D 2 0 1 D 2 0 2 D 2 0 4 CB10 TH-50PZ85U TH-50PZ85U C2-BOARD TXNC21RJTU C2-BOARD TXNC21RJTU...
  • Page 95 R 3 2 2 D 3 0 4 C 3 0 2 R 3 1 0 C 3 0 9 D 3 0 1 D 3 0 2 D 3 0 3 C 3 0 3 TH-50PZ85U TH-50PZ85U C3-BOARD TXNC31RJTU C3-BOARD TXNC31RJTU...
  • Page 96 T P 2 1 T P 5 2 T P 1 4 D 4 4 1 T P 3 6 T P 1 3 D 5 8 3 T P 3 3 T P 3 1 TH-50PZ85U TH-50PZ85U SC-BOARD TXNSC1RJTUS SC-BOARD TXNSC1RJTUS...
  • Page 97 PC16897 TP92 Q16873 TP35 Q16628 TP93 Q16874 TP36 Q16629 VOLUME TP94 Q16875 TP37 Q16634 TP95 Q16876 VR16600 TP38 Q16635 TP96 Q16879 VR16601 TP39 Q16641 Q16881 VR16602 Q16642 Q16882 VR16841 Q16643 Q16644 Q16645 TH-50PZ85U TH-50PZ85U SC-BOARD PARTS LOCATION SC-BOARD PARTS LOCATION...
  • Page 98 R 5 8 3 R 5 8 2 I C 5 2 1 R 5 8 6 D 5 8 3 C 5 2 7 T P 3 I C 5 8 1 R 5 2 1 TH-50PZ85U TH-50PZ85U SC-BOARD TXNSC1RJTUS SC-BOARD TXNSC1RJTUS...
  • Page 99 R 3 9 0 P b F CRNo.14 H.V.DANGER SU41 Z A 9 0 1 TNPA4406 T P S U 4 T P S U 5 O R D E R N O . H.V.DANGER TH-50PZ85U TH-50PZ85U SU-BOARD TXNSU1RJTU SU-BOARD TXNSU1RJTU...
  • Page 100 C 3 8 1 R 9 4 9 SD42 P b F H.V.DANGER H.V.DANGER D 9 5 2 C 9 6 9 SD46 1 SD TNPA4407 CRNo.14 O R D E R N O . TH-50PZ85U TH-50PZ85U SD-BOARD TXNSD1RJTU SD-BOARD TXNSD1RJTU...
  • Page 101 S S 1 1 S S 1 2 L 2 7 1 T P 9 T P 3 L 2 6 2 T P 5 T P 6 T P 4 T P 1 0 TH-50PZ85U TH-50PZ85U SS-BOARD TXNSS1RJTU SS-BOARD TXNSS1RJTU...
  • Page 102 D 3 1 4 L 2 6 2 R 3 1 4 R 3 1 3 Discharge R 3 1 5 T 3 0 1 R 1 5 9 D 1 5 1 Discharge TH-50PZ85U TH-50PZ85U SS-BOARD TXNSS1RJTU SS-BOARD TXNSS1RJTU...

  • Page 103: Exploded View And Replacement Parts List

    13 Exploded View and Replacement Parts List 13.1. Exploded View and Mechanical Replacement Parts List 13.1.1. Exploded View...
  • Page 104 13.1.2. Fan part location...
  • Page 105 13.1.3. Accessories...

  • Page 106: Mechanical Replacement Parts List

    13.1.4. Mechanical Replacement Parts List...
  • Page 107 Ref. Safety Part No. Part Name & Description Q'ty Remarks 10030-0035400 BATTERY COVER 1 PAVCA EAS16S10A SPEAKER 2 PAVCA K1RYYYA00016 F-TYPE (5C) K2CG3YY00029 AC CORD 1 PAVCA L6FAYYYH0050 FAN(80MM) MD50F11A1J PLASMA DISPLAY PANEL N2QAYB000220 REMOTE CONTROL 1 PAVCA STAND POLE LEF TBLA3615 STAND POLE RIGH TBLA3614...
  • Page 108 Ref. Safety Part No. Part Name & Description Q'ty Remarks TMXX041 AC CORD CLAMPER TMZ2AX0301 STAND BRACKET LEFT 1 PAVCA TMZ2AX0302 STAND BRACKET RIGHT 1 PAVCA TPD169487 JOINT TPEB331 BAG (PEDESTAL STAND) TPEH273 TOP PROTECT SHEET(TOP/BOT) TQB2AA0773 INSTRUCTION BOOK(ENG/FRE/SPA) 1 PAVCA TQZH983 SCREW USE HANDBILL TSXL519...

  • Page 109: Electrical Replacement Parts List

    13.2. Electrical Replacement Parts List 13.2.1. Replacement Parts List Notes...
  • Page 110 13.2.2. Electrical Replacement Parts List Safety Ref. No. Part No. Part Name & Pcs Remarks Description Safety Ref. No. Part No. Part Name & Pcs Remarks C2186 F1G1C104A116 C 0.10UF, K, 16V Description C2187 F1H0J2250008 C 2.2UF, K, 16V C2188 F1G1H471A731 E 470UF, 50V K1KA09A00220 9P CONNECTOR C2189...
  • Page 111 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C3023 F1J1A106A043 C 0.010UF, K, C4605 F1H1A1050032 E 10UF, 50V C4606,07 F1J1A106A043 C 0.010UF, K, C3024-35 F1H1A1050032 E 10UF, 50V C3042-47 F1J1A106A043 C 0.010UF, K, C4608...
  • Page 112 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C5608 F1G1C104A116 C 0.10UF, K, 16V C8301 F1G1H102A730 E 1000UF, 50V C5611,12 ECJ3YB1E106M C 10 UF, K, 25V C8302 F1G1C104A116 C 0.10UF, K, 16V C5615...
  • Page 113 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C9153-62 F1G1C104A119 C 0.10UF, K, 16V 10 C14901 F1J1H102A834 C 1000UF, 50V PAVCA C9163 F1J0J475A035 C 4.7UF, K, 16V C14902 F1J1C1050030 C 1UF, Z, 16V C9164,65...
  • Page 114 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C16327 F0C2E225A230 E 0.022UF, 250V C17146,47 F1H1A1050032 E 10UF, 50V C16328,29 F2A2D221A022 E 220UF, 200V C17149 F1H1A1050032 E 10UF, 50V C16336 F1H1H102A970 C 1000PF, K, 50V C17151...
  • Page 115 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description D5601,02 MA22D3900L DIODE D16585 MA2J11100L DIODE D5603,04 B0JCDD000002 DIODE D16602 MAZ81500ML ZENER DIODE D5605 MA22D3900L DIODE D16604 MA2J11100L DIODE D5606 B0JCDD000002 DIODE...
  • Page 116 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description K1KA10BA0062 10P CONNECTOR IC16581 NJM2903V IC16724,2 C0CBADC00072 IC GH10 K1FA119E0013 CONNECTOR IC16752 C0ZBZ0001324 IC GH11 K1KA30AA0009 30P CONNECTOR IC16772 C0ZBZ0001325 IC IC16784...
  • Page 117 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description L4510,11 J0JHC0000078 CHIP INDUCTOR TXNC21RJTU CIRCUIT BOARD C2 PAVCA L4512,13 J0JCC0000241 CHIP INDUCTOR TXNC31RJTU CIRCUIT BOARD C3 PAVCA L4514-19 J0JYC0000068 CHIP INDUCTOR TNPA4439AJS...
  • Page 118 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description Q16531 B1ABRD000003 TRANSISTOR R1170 ERJ2GEJ333 M 33KOHM, J,0.063W Q16532 B1ADRD000001 TRANSISTOR R1171 ERJ2GEJ683 M 68KOHM, Q16551 B1ABRD000003 TRANSISTOR J,0.063W Q16552 B1ADRD000001 TRANSISTOR...
  • Page 119 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R2315 ERJ8GEYJ3R3V M 3.3 OHM, J,1/ R3305 ERJ2GEJ101 M 100 OHM, J,0.063W R2325 ERJ2GEJ101 M 100 OHM, R3306,07 ERJ6GEYF472 M 4.7KOHM,F,1/ J,0.063W...
  • Page 120 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R4162 ERJ2GEJ104 M 100KOHM, R4645,46 ERJ2GEJ680 M 68 OHM, J,0.063W J,0.063W R4166 ERJ2GEJ103 M 10KOHM, R4648 EXB28V330J RESISTOR ARRAY J,0.063W R4649 EXB28V680JX...
  • Page 121 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R5634 D1BB2802A055 M 28KOHM, 1/10W R8090 ERJ2GEJ103 M 10KOHM, J,0.063W R5635 ERJ2GEJ223 M 22KOHM, J,0.063W R8091 ERJ2GEJ470 M 47 OHM, J,0.063W R5636 ERJ2GEJ683...
  • Page 122 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R8561 ERJ2RKD330 M 33 OHM, R9144 D0YAR0000007 M 0 OHM 1/4W J,0.063W R9145 ERJ2GEJ472 M 4.7KOHM, R8562-65 ERJ2GEJ103 M 10KOHM, J,0.063W J,0.063W...
  • Page 123 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R9214 ERJ2GEJ104 M 100KOHM, R9325 ERJ2GEJ103 M 10KOHM, J,0.063W J,0.063W R9215 ERJ2GEJ470 M 47 OHM, R9326 ERJ2GEJ470 M 47 OHM, J,0.063W J,0.063W R9216...
  • Page 124 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R9940 ERJ2RKD330 M 33 OHM, R14951-55 D0GDR00Z0002 M 0 OHM, 1/10W J,0.063W R14956-60 ERJ3GEYJ220 M 22 OHM,J,1/16W R9944-51 EXB38V470J RESISTOR ARRAY R14961-63 ERJ6GEYG331...
  • Page 125 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R16231 ERJ6GEYF472 M 4.7KOHM,F,1/ R16401 ERJT08J7R5V M 7.5OHM,J, 0.33W R16241 EXB38V470J RESISTOR ARRAY R16403,04 ERJT08J7R5V M 7.5OHM,J, 0.33W R16242 EXB38V472JV RESISTOR ARRAY...
  • Page 126 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R16606 D0GD103JA036 M 10KOHM,J,0.25W R16735,36 ERJ6ENF2213 M 221KOHM, 1/10W R16607 ERJ6ENF7151 M7.15KOHM, 1/10W R16737 ERJ6ENF2103 M 210KOHM, 1/10W R16608,09 ERJT08J102V M 1KOHM,J, 0.33W R16738...
  • Page 127 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R16827 D0GDR00Z0002 M 0 OHM, 1/10W R17254 EXB38V470J RESISTOR ARRAY R16828 ERJ6GEYF472 M 4.7KOHM,F,1/ R17255,56 ERJ3GEYJ681 M 680 OHM,J,1/ R16831,32 ERJ6GEYG104 M 100KOHM,J,1/ R17257...
  • Page 128 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description SW3751 EVQPC105K SWITCH IC501 MIP3E30MPSCF IC SW3753-58 EVQPC105K SWITCH IC555 AN1431TBTA INTEGRATED CIR- CUIT T16301A ETS19AB249AC SWITCHING TRANS L501 EXCELSA35 BEAD CHOKE...
  • Page 129 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C301 ACKZE1H220T ELECTROLYTIC L401 AYLH8TB681K CHOKE CAPACITOR L402 AYH221012HY CHOKE C302,03 ACRR3DD101K7 CERAMIC CAPACI- L603 ETB50CZ14GAD CHOKE C304 ACMPEF12473H PLASTIC FILM MC201 MDPPNB331...
  • Page 130 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R309 ERG12SJ680J METAL OXIDE FILM R630,31 ARRCR1F2493T METAL GLAZE RESISTOR FIXED RESISTOR R310 ERG12SJ220J METAL OXIDE FILM R632 ARRCR1F2213T METAL GLAZE RESISTOR FIXED RESISTOR...
  • Page 131 Model No. TH-42PZ80U ORDER NO. MTNC080211CE, Model No. TH-46PZ80U ORDER NO. MTNC080209CE Model No. TH-46PZ85U ORDER NO. MTNC080204CE, Model No. TH-50PZ80U ORDER NO. MTNC080210CE Model No. TH-50PZ85U ORDER NO. MTNC080205CE, Model No. TH-46PZ85X ORDER NO. MTNC080431AE Model No. TH-50PZ85X ORDER NO. MTNC080432AE, Model No. TH-42PZ800U ORDER NO. MTNC080412CE Model No.
