Chariot Multi-Functional Handlebar Console Instruction

Congratulations on purchasing Chariot's Handlebar Console accessory – a multifunction console used for
extra storage while on the carrier, or just clip off to be used as a shoulder bag!
The Handlebar Console is compatible with 2005 and newer Chariots. These Chariots can be
identified by the presence of a plastic buckle sewn on the upper rear center of the carrier's weather
cover.
A. Preparing the Handlebar Console for Mounting to the Carrier
1. The Handlebar Console is shipped ready to mount onto the carrier. If the shoulder strap has been
extended, follow the steps below to prepare the Handlebar Console for mounting on the carrier.
2. Pull the top and bottom strap keepers to the shortest adjustment as shown in Figure 1a.
3. Pull the upper tri-glide on the side release buckles to the top of the strap on the bag side of the strap
as shown in Figure 1b.
B. Attaching the Handlebar Console to the Carrier
1. Wrap the two web straps on the top of the console around the carrier's handlebar and secure them using
the two buckles. Tighten the web straps by pulling on the free end of the straps as shown in Figure 2a.
2. Secure the front of the Handlebar Console to the buckle on the back of the carrier's cover as shown in
Figure 2b.
3. To release, simply push down the button and pull the buckles apart on the top and bottom of the bag as
shown in Figure 2c.
Figure 2a
07/28/10
Multi Functional Handlebar Console
Figure 1a
www.ChariotCarriers.com
Figure 2b
Figure 1b
Figure 2c
51100930
