Loose Parts
Note:
Use the chart below to identify parts for assembly.
DESCRIPTION
Rear Wheel
Wheel Bolt
R.H. Wheel Spindle
L.H. Wheel Spindle
Unplated Thrust Washer – 1.56" O.D x .06"
Thick
Plated Wheel Washer –1.50" O.D x .05" Thick
Bolt – 5/16"-18 x 2.25" Long
Hex Nut – 5/16"-18
Spindle Cap
Front Wheel
Hubcap Washer – 2.50" O.D x .05" Thick
Cotter Pin –.156" x 1.50" Long
Shim Washer – 1.50" O.D x .015" Thick
Hubcap
Steering Wheel
Boot Washer
Nut
Lock Washer
Trim Cover
Seat Assembly
Shoulder Bolt – 5/16"
Locknut – 5/16"
Printed in USA
523Dxi GARDEN TRACTOR
MODEL NO. 73551–8900001 & UP
QTY.
2
10
1
1
2
4
2
2
2
2
2
2
2
2
1
1
1
1
1
1
2
2
The Toro Company – 1997
All Rights Reserved
FORM NO. 3319–230 A
INSTRUCTIONS
USE
Installing the rear wheels
Installing the front wheels
Installing the steering wheel
Installing the seat
SET UP
Advertisement
Table of Contents
Related Manuals for Toro 73551
Summary of Contents for Toro 73551
-
Page 1: Loose Parts
FORM NO. 3319–230 A 523Dxi GARDEN TRACTOR SET UP MODEL NO. 73551–8900001 & UP INSTRUCTIONS Loose Parts Note: Use the chart below to identify parts for assembly. DESCRIPTION QTY. Rear Wheel Installing the rear wheels Wheel Bolt R.H. Wheel Spindle L.H. -
