Summary of Contents for HAGS FS001N
- Page 1 Installation Instructions Fitness Range FS001N, FS004N, FS007N, FS009N, FS010N, FS015N, FS016N, FS030, FS031, FS032, FS033 © Playpower Inc E-post:hags@hags.com www.hags.com Fitness Range Issue G 18/05/2015 1 / 25...
- Page 2 ITEM PART ITEM PART 940301 10261600 INCL 10291600 INKL 500 x 500 x 50mm Fitness Range Ground Anchor S2 (50mm) 120 Nm! ≥C20-25 700mm 7 x 24h 990mm 60° 60° Fitness Range Issue G 18/05/2015 2 / 25...
- Page 3 FS001N Ski Stepper EN 16630 EN 16630 2225 2086 4311 EN 16630 0.43m Fitness Range Issue G 18/05/2015 3 / 25...
- Page 4 FS004N Sit-up 4034 EN 16630 2017 EN 16630 EN 16630 0.46m Fitness Range Issue G 18/05/2015 4 / 25...
- Page 5 FS007N Leg Stretch EN 16630 EN 16630 1966 3932 EN 16630 Fitness Range Issue G 18/05/2015 5 / 25...
- Page 6 FS009N Parallel Rails 3542 EN 16630 1771 EN 16630 EN 16630 1.46m Fitness Range Issue G 18/05/2015 6 / 25...
- Page 7 FS010N Push Hands 3950 EN 16630 1975 EN 16630 EN 16630 Fitness Range Issue G 18/05/2015 7 / 25...
- Page 8 FS015N Pull-up EN 16630 EN 16630 2145 4291 EN 16630 0.87m Fitness Range Issue G 18/05/2015 8 / 25...
- Page 9 FS016N Trinity Cycle 3667 EN 16630 1834 EN 16630 EN 16630 0.94m Fitness Range Issue G 18/05/2015 9 / 25...
- Page 10 FS030 Air Skier EN 16630 EN 16630 2267 4533 EN 16630 0.48m Fitness Range Issue G 18/05/2015 10 / 25...
- Page 11 FS031 Air Walker EN 16630 EN 16630 2192 4384 EN 16630 0.55m Fitness Range Issue G 18/05/2015 11 / 25...
- Page 12 FS032 Rower 3932 EN 16630 1966 EN 16630 EN 16630 0.61m Fitness Range Issue G 18/05/2015 12 / 25...
- Page 13 FS033 Lat Pull Down and Chest Press Combo EN 16630 EN 16630 2035 4070 EN 16630 0.59m Fitness Range Issue G 18/05/2015 13 / 25...
- Page 14 Appendix A_Ski Stepper Part Identification 13 11 14 4.8 x 16 ALU BLIND RIVET 10360516 SKI-STEPPER USE LABEL FS70000001 8 X 7mm KEY - BS 080a47 GYM725 REAR CRANK GYM110 LINK ARM BEARING SPACER GYM706 REAR BEARING SPACER GYM114 REAR CENTRE SHAFT GYM108 REAR BEARING SPACER GYM704...
- Page 15 Appendix B_Sit-up Part Identification 4.8 X 16 ALU BLIND RIVET 10360516 SIT-UP LABEL FS70000004 28 SKRUV WN1451 SCREW 312244 16 M10 FORM B WASHER 10291000 16 M10 X 30 RESISTORX 10121030 CUSHION REAR PART 33-06605 CUSHION FRONT PART 33-06604 SIT-UP BUNK GYM402 SIT-UP POST GYM401...
- Page 16 Appendix C_Leg Stretch Part Identification 4.8 X 16 ALU BLIND RIVET 10360516 LEG STRETCH LABEL FS70000007 12 M10 FORM B WASHER 10291000 12 M10 X 30 RESISTORXT 10121030 LEG STRETCH FRAME GYM267 LEG STRETCH POST GYM268 Balloon Description Art No Fitness Range Issue G 18/05/2015 16 / 25...
- Page 17 Appendix D_Parallel Rails Part Identification 4.8 X 16 ALU BLIND RIVET 10360516 LEG STRETCH LABEL FS70000009 32 M10 FORM B WASHER 10291000 32 M10 X 30 RESISTORX 10121030 LEFT HAND RAIL GYM285 RIGHT HAND RAIL GYM284 PARALLEL RAILS POST GYM286 Balloon Description Art No...
- Page 18 Appendix E_Push Hands Part Identification 10360516 4.8 X 16 ALU BLIND RIVET PUSH HANDS LABEL FS70000010 END CAP - IF6055-57S GYM726 WN03 X M8 KNOB GYM727 M10 X 30 RESISTORX 10211030 WASHER GYM217 6006 2RS BEARING GYM450 BEARING SPACER GYM216 WHEEL GYM213 PUSH HANDS POST...
- Page 19 Appendix F_Pull-up Part Identification 4.8 X 16 ALU BLIND RIVET 10360516 PULL-UP LABEL FS70000015 REDUNDANT INSERT PLUG 19024501 16 M10 FORM B WASHER 10291000 16 M10 X 30 RESISTORX 10121030 PULL-UP FRAME GYM734 PULL-UP POST GYM733 Balloon Description Art No Fitness Range Issue G 18/05/2015 19 / 25...
- Page 20 Appendix G_Trintiy Cycle Part Identification 16 4.8 x 16 ALU BLIND RIVET 10360516 TRINITY USE LABEL_WHEELCHAIR FS70000016b TRINTIY USE LABEL_HANDWHEEL FS70000016c TRINITY USE LABEL_CYCLE FS70000016a CRANK BEARING BUSH GYM964 10 M8 NYLOC NUT 10260600 M8 X 20 RESISTORX 10120620 SLEEVE 8032683 SCREW 5/16 - 24 UNF 8005508...
- Page 21 Appendix H_Air Skier Part Identification 4.8 X 16 ALU BLIND RIVET 10360516 Raised-head screw (M10 x 30) 10121030 M10 Form 'B' Washer 10291000 MIN SKI FOOTPLATE GYM448 BUFFER STOP GYM1006 STEPPED WASHER GYM1007 6006-2RS BEARING GYM450 AIR SKIER PENDULUM LEG GYM1104 MS LABEL FS70000002...
- Page 22 Appendix I_Air Walker Part Identification 4.8 x 16 ALU BLIND RIVET 10360516 FS70000005 MS LABEL M10 x 30 RESISTORX 10121030 STEPPED WASHER GYM1007 WASHER GYM134 AIR WALKER SHAFT GYM1305 FOOTPLATE GYM447 BUFFER STOP GYM1006 6006-2RS BEARING GYM450 AIR WALKER PENDULUM GYM1302 AIR WALKER FRAME GYM1301...
- Page 23 Appendix J_Rower Part Identification 4.8 x 16 ALU BLIND RIVET 10360516 HB LABEL FS70000011 ROWER SEAT GYM1516 ROWER HANDLE LINKAGE GYM1509 ROWER UPPER FRAME GYM1502 M10 x 20 RESISTORX 10121020 M10 Form 'B' Washer 10291000 M10 T-Nut 10931000 M10 x 30 RESISTORX 10121030 M10 x 50 RESISTORX 10121050...
- Page 24 Appendix K_Combo Part Identification 4.8 X 16 ALU BLIND RIVET 10360516 M10 x 30 RESISTORX 10121030 FS70000008 PP LABEL PDC LABEL FS70000003 STEPPED WASHER GYM1007 CHEST PRESS UPPER LINKAGE GYM1206 LAT PULL HANDLE GYM1405 CHEST PRESS HANDLE GYM1210 LONG BEARING DISTANCE GYM442 LONG SPINDLE GYM441...
- Page 25 Appendix L_EN 16630 Zones Fitness Range Issue G 18/05/2015 25 / 25...
