Acer H6500 SERIES User Manual

Hide thumbs Also See for H6500 SERIES:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Acer Projector
H6500/E-140/HE-802 Series
User's Guide
Downloaded from ProjectorsManual.com Manuals

Advertisement

Table of Contents
loading

Related Manuals for Acer H6500 SERIES

Summary of Contents for Acer H6500 SERIES

  • Page 1 Acer Projector H6500/E-140/HE-802 Series User's Guide Downloaded from ProjectorsManual.com Manuals...
  • Page 2 Serial number: ___________________________________ Date of purchase: ________________________________ Place of purchase: ________________________________ Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies' product names or trademarks are used herein for identification purposes only and belong to their respective companies.
  • Page 3 Information for your safety and comfort Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product. Turning the product off before cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
  • Page 4 • To avoid damage of internal components and to prevent battery leakage, do not place the product on a vibrating surface. • Never use it under sporting, exercising, or any vibrating environment which will probably cause unexpected short current or damage rotor devices, lamp.
  • Page 5 Product servicing Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage points or other risks. Refer all servicing to qualified service personnel. Unplug this product from the wall outlet and refer servicing to qualified service personnel when: •...
  • Page 6 Do not stand the projector on end vertically. It may cause the projector to fall over, causing injury or damage. • This product is capable of displaying inverted images for ceiling mount installation. Only use acer ceiling mount kit for mounting the projector and ensure it is securely installed. Downloaded from ProjectorsManual.com Manuals...
  • Page 7 Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit http://www.acer-group.com/public/ Sustainability/sustainability01.htm Mercury advisory For projectors or electronic products containing an LCD/CRT monitor or display: “Lamp(s) contain Mercury,...

  • Page 8: Precautions

    viii First things first Usage Notes • Turn off the product before cleaning. • Use a soft cloth moistened with mild detergent to clean the display housing. • Disconnect the power plug from AC outlet if the product is not being used for a long period of time.

  • Page 9: Table Of Contents

    Adjusting the Height of Projected Image How to optimize image size and distance How to get a preferred image size by adjusting distance and zoom User Controls Installation menu Acer Empowering Technology Onscreen Display (OSD) Menus Color Image Management Setting...
  • Page 10 LED & Alarm Definition Listing Replacing and cleaning the dust filters Replacing the Lamp Ceiling Mount Installation Specifications Compatibility modes Regulations and safety notices Downloaded from ProjectorsManual.com Manuals...

  • Page 11: Introduction

    • Native 1920 x 1080 1080p resolution 4:3 / 16:9 / L.Box aspect ratio supported • Acer ColorBoost technology delivers nature’s true colors for vivid, life-like images • Acer ColorSafe II technology ensures consistent color rendition over time. •...

  • Page 12: Package Overview

    Contact your dealer immediately if any thing is missing. Projector with lens cap Power cord VGA cable POWER FREEZE HIDE ASPECT RESYNC SOURCE RATIO Acer Projector ZOOM Security Card H6500/E-140/HE-802 Series P/N:MU.JD500.001 BRIGHTNESS COLOR CONTRAST PgUp PgDn COMPONENT...

  • Page 13: Projector Overview

    Projector Overview Projector Outlook Front / upper side Description Description Control panel Zoom lever Ventilation (inlet) Remote control receivers Ventilation (outlet) Focus ring Elevator button Zoom lens Elevator foot 10 Lens cap Rear side Description Description Power socket HDMI 1 connector USB connector HDMI 2 connector PC analog signal/HDTV/component...

  • Page 14: Control Panel

    Temp Indicator LED Four directional select to select items or make keys adjustments to your selection. SOURCE Changes the active source. Empowering key Unique Acer functions: eView, eTimer, ePower Management. Remote control Receives signals from remote control. receiver Downloaded from ProjectorsManual.com Manuals...

  • Page 15: Remote Control Layout

    To choose the desired aspect ratio (Auto/4:3/16:9/L.Box) ZOOM Zooms the projector display in or out. Empowering key Unique Acer functions: eView, eTimer, ePower Management. KEYSTONE Adjusts the image to compensate for distortion caused by tilting the projector (± 15 degrees).
  • Page 16 Icon Function Description COLOR Press "COLOR" to adjust the color temperature of image. Press "VGA" to change source to the VGA connector. This connector supports analog RGB, YPbPr (480p/576p/720p/ 1080i), YCbCr (480i/576i) and RGBsync. COMPONENT Press "COMPONENT" to change source to Component video. This connection supports YPbPr (480p/576p/720p/1080p) and YCbCr (480i/576i/1080i).

  • Page 17: Getting Started

    Getting Started Connecting the Projector DVD player, Set-top Box, HDTV receiver D-Sub Video Output HDTV adapter D-Sub HDMI HDMI DVD player, Set-top Box, HDTV receiver Description Description Power cord 3 RCA component cable USB cable Composite video cable VGA cable HDMI cable VGA to component/HDTV adapter 12V DC Cable...

  • Page 18: Turning The Projector On/Off

    Turning the Projector On/Off Turning on the Projector Remove the lens cap.(Illustration #1) Ensure that the power cord and signal cable are securely connected. The Power indicator LED will flash red. Turn on the projector by pressing "Power" button on the control panel, and the Power indicator LED will turn blue.(Illustration #2) Turn on your source (computer, notebook, video player ,etc.).

  • Page 19: Turning The Projector Off

    Turning the projector off To turn the projector off, press the power button. This message appears: "Please press the power button again to complete the shutdown process." Press the power button again. The LED power indicator will turn RED and blink rapidly after the projector is turned off, and the fan(s) will continue to operate for about 2 minutes to ensure that the system cools properly.

  • Page 20: Adjusting The Projected Image

    Adjusting the Projected Image Adjusting the Height of Projected Image The projector is equipped with elevator feet for adjusting the height of image. To raise the image: Press the elevator foot release. (Illustration #1) Raise the image to the desired height angle (Illustration #2), then release the button to lock the elevator foot into position.

  • Page 21: How To Optimize Image Size And Distance

    How to optimize image size and distance Consult the table below to find the optimal image sizes achievable when the projector is positioned at a desired distance from the screen. Example: If the projector is 3 m from the screen, good image quality is possible for image sizes between 75"...
  • Page 22 Screen size Screen size Desired (Min zoom) (Max zoom) Distance From base From base to Diagonal Diagonal to top of top of image <A> (inch) W (cm) x H (cm) (inch) W (cm) x H (cm) image (cm) (cm) <B> <B>...

  • Page 23: How To Get A Preferred Image Size By Adjusting Distance And Zoom

    How to get a preferred image size by adjusting distance and zoom 60" Desired image size Height: 87cm Form base to top of image 2.4 m Desired Distance The table below shows how to achieve a desired image size by adjusting either the position or the zoom ring.
  • Page 24 Desired Image Size Distance (m) Top (cm) From base to top of Diagonal (inch) Max zoom Min zoom W (cm) x H (cm) image <A> <B> <C> <D> 66 x 37 89 x 50 111 x 62 133 x 75 155 x 87 177 x 100 199 x 112...

  • Page 25: User Controls

    The new settings will be saved automatically upon exiting the menu. Push the menu button anytime to exit the menu and return to the Acer welcome screen. Downloaded from ProjectorsManual.com Manuals...

  • Page 26: Acer Empowering Technology

    Acer Empowering Technology Acer Empowering Key provide three Empowering Acer unique functions, they are "Acer eView Management", "Acer eTimer Management" and "Acer ePower Management" respectively. Press " " key for more than one second to launch the Onscreen display main menu to modify its function.

  • Page 27: Onscreen Display (Osd) Menus

    Onscreen Display (OSD) Menus The projector has multilingual OSD that allow you to make image adjustments and change a variety of settings. Using the OSD menus • To open the OSD menu, press "MENU" on the remote control or control panel.

  • Page 28: Color

    Color Display Mode There are many factory presets optimized for various types of images. • Bright: For brightness optimization. • Presentation: For meeting presentation with higher brightness. • Standard: For common environment. • Movie: For brighter and general movie/video/photo playing. •...

  • Page 29: Color Management

    Advanced Noise Reduction Adjusts signal noise reduction."0" means the noise reduction is off, ">0" increase noise reduction. Sharpeness Adjusts the sharpness of the image. • Press to decrease the sharpness. • Press to increase the sharpness. Brilliant Color Produces an expanded on-screen color spectrum that delivers enhanced color saturation for bright, true-to-life images.

  • Page 30: Image

    Image Projection Front • The factory default setting. Ceiling • When you select this function, the projector inverts the image for ceiling-mounted projection. Rear • When you select this function, the projector reverses the image so you can project from behind a translucent screen. Rear-Ceiling •...

  • Page 31: Management

    H. Position • Press to move the image left. (Horizontal • position) Press to to move the image right. V. Position • Press to move the image down. (Vertical position) • Press to move the image up. Frequency "Frequency" changes the projector's refresh rate to match the frequency of your computer’s graphics card.
  • Page 32 Lamp Hour Elapse Displays the lamp’s elapsed operating time (in hours). Lamp Reminding Activate this function to display a reminder to change the lamp 30 hours before its expected end-of-life. Lamp Hour Reset Press the button and choose "Yes" to turn the lamp hour counter to 0 hours.

  • Page 33: Setting

    Setting Menu Location Choose the menu location on the display screen. Closed Caption Selects a preferred closed captioning mode from CC1, CC2, CC3, CC4, (CC1 displays captions in the primary language in your area). Select "Off" to turn off the captioning feature. This function is only available when a composite video or S-Video input signal is selected and its system format is NTSC.
  • Page 34 Administrator Password is. • If losing this security card and number, please contact with an Acer service center. Auto Screen Default is "On", the down/up move of electronic screen will be related with power on/off of Projector.

  • Page 35: Timer

    Timer • Timer Location Choose the location of the timer on the screen. Timer Start • Press to start or stop the timer. Timer Period • Press to adjust the timer period. Timer Display • Press to which timer mode to display on the screen.

  • Page 36: Appendices

    Appendices Troubleshooting If you experience a problem with your Acer projector, refer to the following troubleshooting guide. If the problem persists, please contact your local reseller or service center. Image Problems and Solutions Problem Solution No image appears • Connected as described in the "Getting Started"...
  • Page 37 Partial, scrolling • Press "RESYNC" on the remote control or control or incorrectly panel. displayed image • For an incorrectly displayed image: (For notebooks) • Follow the steps for item 2 (above) to adjust the resolution of your computer. • Press the toggle output settings.

  • Page 38: Problems With The Projector

    Image is too small • Adjust the zoom ring on the top of the projector. or too large • Move the projector closer to or further from the screen. • Press "MENU" on the remote control or on the control panel. Go to "Image --> Aspect Ratio" and try different settings.

  • Page 39: Osd Messages

    OSD Messages Condition Message Reminder Message Fan Fail - the system fan is not working. Projector Overheated - the projector has exceeded its recommended operating temperature and must be allowed to cool down before it may be used. Replace the lamp - the lamp is about to reach its maximum lifetime.

  • Page 40: Led & Alarm Definition Listing

    LED & Alarm Definition Listing LED Messages Lamp LED Temp LED Power LED Message Blue Power Plug Flash ON to Flash ON to OFF Flash ON to OFF 100ms 100ms OFF 100ms Standby Power button ON Lamp retry 0.5 second H(On), 0.5 second L(Off)

  • Page 41: Replacing And Cleaning The Dust Filters

    Replacing and cleaning the dust filters Replacing the dust filters Turn the projector off then unplug the power cord. Pull the both sides dust filters out. (Illustration #1) Clean or replace the dust filter. To put the dust filters back, reverse the previous step. When dust filters are implemented, please set the system to be high altitude mode.

  • Page 42: Replacing The Lamp

    Replacing the Lamp Use a screwdriver to remove the screw(s) from the cover, and then pull out the lamp. The projector will detect the lamp life. You will be shown a warning message "Lamp is approaching the end of its useful life in full power operation. Replacement Suggested!"...

  • Page 43: Ceiling Mount Installation

    Ceiling Mount Installation If you wish to install the projector using a ceiling mount, please refer to the steps below: Drill four holes into a solid, structurally sound part of the ceiling, and secure the mount base. Note: Screws are not included. Please obtain the appropriate screws for your type of ceiling.
  • Page 44 Use the appropriate number of screws for the projector size to attach the projector to the ceiling mount bracket. Note: It is recommended that you keep a reasonable space between the bracket and the projector to allow for proper heat distribution.
  • Page 45 Adjust the angle and positioning as necessary. 30° Note: The appropriate type of screw and washer for each model is listed in the table below. 3 mm diameter screws are enclosed in the screw pack. Models Screw Type B Washer Type Diameter (mm) Length (mm) Large...

  • Page 46: Specifications

    Specifications The specifications listed below are subject to change without notice. For final specs, please refer to Acer's published marketing specifications. Projection system ® Resolution Native: 1080P (1920 x 1080), Maximum: UXGA (1600 x 1200), WSXGA+ (1680x1050) Computer compatibility IBM PC and compatibles, Apple Macintosh, iMac and...
  • Page 47 Standard package contents • AC power cord x1 • VGA cable x1 • Remote control x1 • Batteries x2 (for remote control) • User's Guide (CD-ROM) x1 • Quick start guide x1 • Security card x1 • Carrying case x1 * Design and specifications are subject to change without notice.

  • Page 48: Compatibility Modes

    Compatibility modes A. VGA Analog VGA Analog - PC Signal Modes Resolution V.Frequency [Hz] H.Frequency [KHz] 640x480 31.5 640x480 37.9 640x480 37.5 640x480 43.3 SVGA 800x600 35.1 800x600 37.9 800x600 48.1 800x600 46.9 800x600 53.7 1024x768 48.4 1024x768 56.5 1024x768 60.0 1024x768 68.7...
  • Page 49 VGA Analog - Extended Wide timing Modes Resolution V.Frequency [Hz] H.Frequency [KHz] WXGA 1280x768 47.8 1280x768 60.3 1280x768 68.6 1280x720 44.8 1280x800 49.6 1440x900 55.9 WSXGA+ 1680x1050 65.3 1366x768 47.7 1920x1080 67.50 VGA Analog -Component Signal Modes Resolution V.Frequency [Hz] H.Frequency [KHz] 480i 720x480...
  • Page 50 1024x768 56.5 1024x768 60.0 1024x768 68.7 SXGA 1152x864 63.8 1152x864 67.5 1152x864 77.1 1280x1024 64.0 1280x1024 77.0 1280x1024 80.0 1280x1024 91.1 QuadVGA 1280x960 60.0 1280x960 75.2 SXGA+ 1400x1050 65.3 UXGA 1600x1200 75.00 PowerBook G4 640x480 31.5 PowerBook G4 640x480 66.6(67) 34.9 PowerBook G4 800x600...
  • Page 51 HDMI - Video Signal Modes Resolution V.Frequency [Hz] H.Frequency [KHz] 480i 720x480(1440x480) 59.94(29.97) 15.7 480p 720x480 59.94 31.5 576i 720x576(1440x576) 50(25) 15.6 576p 720x576 31.3 720p 1280x720 45.0 720p 1280x720 37.5 1080i 1920x1080 60(30) 33.8 1080i 1920x1080 50(25) 28.1 1080p 1920x1080 23.97/24 1080p...

  • Page 52: Regulations And Safety Notices

    Regulations and safety notices FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 53: Declaration Of Conformity For Eu Countries

    Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada. Declaration of Conformity for EU countries Acer hereby declares that this projector series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Compliant with Russian regulatory certification...

  • Page 54: Declaration Of Conformity

    New Taipei City 221,Taiwan, R.O.C. Declaration of Conformity Acer Incorporated 8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221,Taiwan, R.O.C. Contact Person: Mr. Easy Lai, e-mail:easy_lai@acer.com.tw And, Acer Italy s.r.l Via Lepetit, 40, 20020 Lainate (MI) Italy Tel: +39-02-939-921, Fax: +39-02 9399-2913, www.acer.it...
  • Page 55 Article 3.2 Spectrum Usages -. EN300 328 -. EN301 893 (Applicable to 5GHz high performance RLAN). Year to begin affixing CE marking 2011. _______________________________ Aug. 24, 2011 Easy Lai /Manager Date Regulation Center, Acer Inc. Downloaded from ProjectorsManual.com Manuals...
  • Page 56 Acer America Corporation 333 West San Carlos St., San Jose CA 95110, U. S. A. Tel : 254-298-4000 Fax : 254-298-4147 www.acer.com Federal Communications Commission Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the...
