Summary of Contents for Aim MXS STRADA
- Page 1 MXS Strada USER GUIDE AiM TECH Srl. Via Cavalcanti, 8 20063 Cernusco S/N (MI) Italia Tel. (+39) 02.9290571 www.aim-sportline.com Made in Italy...
- Page 2 MXS dash as the tool to 9. DIGITAL OUTPUT monitor your on-track performance. 10. RACESTUDIO3 SOFTWARE The MXS Strada, with its compact 5” TFT 10.1 CONFIGURATION display, gives you the flexibility for 10.1.1 CHANNELS CONFIGURATION viewing your data in your preferred 10.1.2 ECU STREAM...
- Page 3 Data come from a wide range of You can define up to eight different MXS Strada is available with two different layouts: race (top) and street (bottom) sources, including your vehicle ECU, fully customizable pages. the analog/digital inputs, the optional GPS and external expansions as well as predefined math channels.
- Page 4 CHAPTER 2 WHAT IS IN THE KIT MXS STRADA 2. What is in the kit The MXS Strada kit includes: MXS Strada dash Software Main Harness...
- Page 5 CHAPTER 3 LAYOUT AND PUSHBUTTONS MXS STRADA MXS Strada Dash Configurable Alarm LEDs 1-3 Shift Lights Configurable Alarm LEDs 4-6 AMP Connectors Aluminum Body Multifunctional Pushbuttons...
- Page 6 For each LED, you can define the RPM value MXS Strada features 10 RGB gear flash MXS Strada can sample data from the ECU 3. Using Race Studio 3, configure MXS at which to turn it on and the colour.
- Page 7 6.2 RPM via a 5-50 V Square Wave Signal or coil (150-400 V) In case your engine is not managed by any ECU, MXS Strada can read the signal from the low voltage of the coil (whose peak can be from 150 to 400 V) or from a possible square wave (the peak can be from 5 to 50V).
- Page 8 MXS Strada can receive the speed signal up to 1000 times per second each. explained in section 10.1: from three different sources: MXS Strada has one speed input in the 23 You can connect: n From the ECU pins AMP connector.
- Page 9 Race Studio3 to manage the examples. LED, a message and a digital output. digital output Connecting examples INSIDE EVO4s INSIDE EVO4s INSIDE EVO4s Load up to 1 Amp directly managed by MXS Strada digital output. Load higher than 1 Amp requires an automotive relay...
- Page 10 Tracks by MXS Strada) n Analysis n Movies After having entered the MXS Strada configuration page, you can see different tabs useful to Download web ubdates n Devices set one of the following configuration features: It automatically detects which new...
- Page 11 Here you can select the proper ECU to With this feature, you can enable or which your MXS Strada is connected. At disable the data coming from your ECU, The channel configuration page will appear. With this page you can define all the parameters...
- Page 12 Alarms and digital output configuration 3) Describe what to do when an alarm arises. MXS Strada can: n Turn a LED on: you have to select Here you can define the event the system has to check and the effect of that event.
- Page 13 CHAPTER 10 RACESTUDIO3 SOFTWARE MXS STRADA Shift Lights Configuration Once alarms and shift lights are set summaries appear: on top is shift lights summary while bottom is alarm led and digital output summary. Pushing the shift lights setting icon top...
- Page 14 “SAVE” or “CLOSE” to save the configuration. n Channel Press "Display"tab to configure MXS Strada display. If you have connected your MXS Strada n Label The page is divided in two different sections. On the right you can select one among different to the PC, “TRANSMIT”pushbutton over...
- Page 15 It is your responsibility to fully understand your vehicle’s CAN-bus. AiM cannot be held responsible for any damage or injury caused by misuse of this function.
- Page 16 To scroll among tests, just push PREV or NEXT. Push “LIVE MEASURES” to see the live From the Online View, you can calibrate data coming from your MXS Strada. the channels that require calibration. You can change the measure unit double clicking on the measure.
- Page 17 CHAPTER 12 EXPANSIONS MXS STRADA 12. Expansions Lambda Controller GPS08 Module TC HUB SmartyCam HD cameras Channel Expansion Add expansion modules via our built in the items that can be added to our MXS CAN bus eg. channel expansions, lambda Strada range for incrementing the controllers and GPS.
- Page 18 CHAPTER 13 MXS STRADA PINOUT MXS STRADA 13. MXS Strada Pinout AMP 23 pin. AMP 14 pin. Analog Input 1 9-15 V Power input Analog GND Battery GND +Vb Output CAN+ Exp +Vreference Analog Input 2 +Vb output CAN Analog Input 3...
- Page 19 - Expansion CAN connection GPS, Channel Expansions, TC Hub, Lambda Controllers, SmartyCam - ECU connections CAN, RS232 or K Line Our web site aim-sportline.com is constantly - Digital outputs 1 (1Amp max) updated. - Analog inputs 4 fully configurable, max 1,000 Hz each...
