Rail-PC-5101
Box PC with Intel® Haswell i5-4300U
Table of contents
Introduction ..................................................................................................................................... 2
Symbols used in this Manual ........................................................................................................................ 2
Important Instructions ................................................................................................................................... 2
Note on the Warranty ..................................................................................................................................... 2
Technical Short Information .......................................................................................................... 2
Order Information ........................................................................................................................... 2
Dimensions ..................................................................................................................................... 3
Mounting options ............................................................................................................................ 5
Open the housing ........................................................................................................................... 7
CPU inside ....................................................................................................................................................... 8
Internal Connector List: .................................................................................................................................... 9
Panel Connector List: ..................................................................................................................................... 10
Jumper List: .................................................................................................................................................... 10
Jumper Settings ............................................................................................................................................. 11
BIOS Power Setting ..................................................................................................................................... 12
Panel Connector Pin Assignments ................................................................................................................ 14
Internal Connector Pin Assignment ............................................................................................................... 17
24V-to-12VDC - Converter ............................................................................................................................ 23
s&t embedded GmbH - Gutenbergstr. 2 - 85737 Ismaning - Germany
Phone: +49 89 370058 - 0
Mail to: info@snt-embedded.de
www.snt-embedded.de
Fax: +49 89 37000 689
V1.1
Advertisement
Table of Contents
Summary of Contents for S&T embedded Rail-PC-5101
-
Page 1: Table Of Contents
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Table of contents Introduction ............................. 2 Symbols used in this Manual ........................2 Important Instructions ........................... 2 Note on the Warranty ............................. 2 Technical Short Information ......................2 Order Information ........................... 2 Dimensions ............................. 3 Mounting options .......................... -
Page 2: Introduction
Test Setup: Windows 7 pro. 64bit; 4GB RAM ; 60GB mSATA Order Information Order# Description EN00-004001-01 RAIL-PC-5101; Intel Haswell i5-4300U, 4GB RAM, 64GB mSATA EN00-004002-01 RAIL-PC-5101; Intel Haswell i5-4300U, 8GB RAM, 128GB mSATA EN00-004003-01 RAIL-PC-5101; Intel Haswell i5-4300U, 8GB RAM, 256GB mSATA EN00-004004-01 RAIL-PC-5101;... -
Page 3: Dimensions
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Dimensions s&t embedded GmbH – Gutenbergstr. 2 – 85737 Ismaning - Germany Phone: +49 89 370058 – 0 Fax: +49 89 37000 689 Mail to: info@snt-embedded.de www.snt-embedded.de V1.1... - Page 4 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U s&t embedded GmbH – Gutenbergstr. 2 – 85737 Ismaning - Germany Phone: +49 89 370058 – 0 Fax: +49 89 37000 689 Mail to: info@snt-embedded.de www.snt-embedded.de V1.1...
-
Page 5: Mounting Options
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Mounting options s&t embedded GmbH – Gutenbergstr. 2 – 85737 Ismaning - Germany Phone: +49 89 370058 – 0 Fax: +49 89 37000 689 Mail to: info@snt-embedded.de www.snt-embedded.de V1.1... - Page 6 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Always make sure to mount the DIN rail retaining clamp in upper position mounted with two M4x8 (max. length) counter sunk bolds The heatsink is flippable according to the Rail PC mounting. Make sure that the airflow always works in upright direction.
-
Page 7: Open The Housing
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Open the housing To open the housing just remove five screws: s&t embedded GmbH – Gutenbergstr. 2 – 85737 Ismaning - Germany Phone: +49 89 370058 – 0 Fax: +49 89 37000 689 Mail to: info@snt-embedded.de... -
Page 8: Cpu Inside
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U CPU inside Block Diagram LVDS DDR3L 1 X LVDS CHRONTEL 1 X DDR3 SO-DIMM Connector CH7511B Sockets SATA 2 X Display Port 2 X SATA Connectors Connector DI/DO USB2.0 4-DI/4-DO 1 X USB2.0... -
Page 9: Internal Connector List
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Top View: / mSATA Internal Connector List: Label Function BAT1 Battery Power Input Wafer Onboard Buzzer SATA HDD Power Output Wafer USB2.0 Port 4, 5 Pin Header Right Channel 3W Audio AMP Output Wafer... -
Page 10: Panel Connector List
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Panel Connector List: Label Function USB3.0 Port 0,1 Connector USB3.0 Port 2,3 Connector CN11 GbE LAN1 RJ-45 Connector CN12 GbE LAN2 RJ-45 Connector CN13 GbE LAN3 RJ-45 Connector DP Connector DP Connector (Dual Mode) -
Page 11: Jumper Settings
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Jumper Settings JP1: Panel & Backlight Power Selection for LVDS1 (Pitch 2.54mm) (not used for Rail-PC-System !!) Jumper Setting Status Backlight Power = +12V Backlight Power = +5V Panel Power = +3.3V Panel Power = +5V JP2: AT_ATX Mode / MPCIE1 mSATA / mPCIE Selection (Pitch 2.54mm) -
Page 12: Bios Power Setting
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Importent note: There is no „power-on-button“ on the device available: Therefore the jumper JP2 (AT/ATX Mode) has always set to „AT-Mode“! According to this the BIOS setting for Power Mode is „Power Off“! - Page 13 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U JP6: Flash Description Security Over-ride (Pitch 2.54mm) Jumper Status 1-2 Open Disabled 1-2 Short Enabled JP7: RTC Reset Selection (Pitch 2.54mm) Jumper Status 1-2 Open Normal Operation 1-2 Short Clear RTC CMOS JP8: SRTC Reset Selection (Pitch 2.54mm)
-
Page 14: Panel Connector Pin Assignments
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Panel Connector Pin Assignments PWR: Input Power Connector Signal Mating connector Phoenix Contact PSC 1,5/ 3-F Order# 1841909 Shield X1: COM1 RS-232/422/485 (via internal cable connection to CN15) X2: COM2 RS-232/422/485 (via internal cable connection to CN16) - Page 15 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U CN3: USB3.0 Port-2,3 Type-A Connector Signal Name Signal Name +USBA_VCC +USBB_VCC USBA_D- USBB_D- USBA_D- USBB_D- USBA_RX- USBB_RX- USBA_RX+ USBB_RX+ USBA_TX- USBB_TX- USBA_TX+ USBB_TX+ *：The power source of +USBVCC can be selected by JP5.
- Page 16 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U DP1: DisplayPort Port-1 Connector Signal Signal TX0+ TX3- TX0- TX1+ AUX+ TX1- TX2+ AUX- TX2- TX3+ DP2: Dual Mode DisplayPort Port-2 Connector * Signal Signal TX0+ TX3- TX0- TX1+ AUX+ TX1- TX2+ AUX-...
-
Page 17: Internal Connector Pin Assignment
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U Internal Connector Pin Assignment BAT1: Battery Power Input Wafer Signal Name +VBAT CN1: SATA HDD Power Output Wafer Signal Name +12V CN4: Power Input Wafer (internal cable connection to DC-DC-Converter) Signal +Vin +Vin CN5: USB2.0 Port 10, 11 Pin Header... - Page 18 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U CN9: Audio Pin Header (not used for Rail-PC-System !!) Signal Name Signal Name MIC_IN_L MIC_IN_R MIC_IN_JD LINE_IN_L LINE_IN_R LINE_IN_JD LINE_OUT_L LINE_OUT_R LINE_OUT_JD CN10: Digital Input / Output Wafer (not used for Rail-PC-System !!)
- Page 19 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U CN18: Backlight Power Output Wafer for LVDS1 (not used for Rail-PC-System !!) Signal Name BL_ADJ_PWM * BL_ADJ_VOL * +5V / +12V ** +5V / +12V ** BL_EN*** *：BL_ADJ can be setting in BIOS setup.
- Page 20 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U LVDS1: Primary 24-bit, 2-channel LVDS Panel Connector (not used for Rail-PC-System !!) Signal Name Signal Name LVDS_A0- LVDS_B1+ LVDS_A0+ LVDS_A1- LVDS_B2- LVDS_A1+ LVDS_B2+ LVDS_A2- LVDSBCLK- LVDS_A2+ LVDS_BCLK+ LVDS_B3-/NC LVDS_ACLK- LVDS_B3+/NC LVDS_ACLK+ LVDS_A3-/NC DDC_DATA...
- Page 21 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U mPCIE1: Mini-PCIE Express v1.2 Socket / mSATA Signal Signal WAKE# +3.3VSB Reserved Ground Reserved +1.5V CLKREQ# Ground REFCLK- REFCLK+ Ground Reserved Ground Reserved W_Disable# Ground PERST# PERn0 +3.3VSB PERp0 Ground Ground +1.5V Ground...
- Page 22 Rail-PC-5101 Box PC with Intel® Haswell i5-4300U mPCIE2: Mini-PCIE Express v1.2 Socket Signal Signal WAKE# +3.3VSB Reserved Ground Reserved +1.5V CLKREQ# UIM_PWR* Ground UIM_DATA* REFCLK- UIM_CLK* REFCLK+ UIM_RESET* Ground UIM_VPP* Reserved Ground Reserved W_Disable# Ground PERST# PERn0 +3.3VSB PERp0 Ground Ground +1.5V...
-
Page 23: 24V-To-12Vdc - Converter
Rail-PC-5101 Box PC with Intel® Haswell i5-4300U 24V-to-12VDC – Converter (Internal usage only) Input Output Signal SHLD Phoenix Contact PSC 1,5/ 3-M Signal +12V Molex 43650-0403 +12V s&t embedded GmbH – Gutenbergstr. 2 – 85737 Ismaning - Germany Phone: +49 89 370058 – 0 Fax: +49 89 37000 689 Mail to: info@snt-embedded.de...
