- Page 1 Qcam QSD-722 User Manual Version 1.1.2 Revised December 23th, 2015...
-
Page 2: Table Of Contents
Welcome ..................................4 Important Safeguards and Warnings ..........................4 1 Features and Specifications ............................5 1.1 Overview ................................5 1.2 Features ................................5 1.3 Minimum System Requirements ......................... 6 1.4 Package Contents ..............................6 2 Device Overview ................................. 7 2.1 Device Overview ..............................7 2.2 Charging ................................ - Page 3 4 PC Software Widget ..............................18 5 Firmware upgrades ..............................18 6 Environmental Requirements ........................... 18 7 FCC Regulation ................................18...
-
Page 4: Welcome
Thank you for purchasing our Qcam QSD-722 Camera! This user manual is designed to be a reference tool for the installation and operation of your Qcam Camera. Here you can find information about the camera’s features and functions, as well as information to aid in troubleshooting. -
Page 5: Features And Specifications
External trigger-in – The Amcrest QSD-722 can be triggered by an external device such as a smoke detector, vibration detector, door/window sensor, etc. Optionally, the Amcrest QSD-722 can supply power to an external device. -
Page 6: Minimum System Requirements
Windows Media Player 9 Intel Pentium class computer USB 2.0 port for hi-speed transfers and charging 1.4 Package Contents Please unpack your Amcrest QSD-722 Infrared HD Security Camera and check that the following are included: QSD-722 Infrared HD Security Camera 5V DC Adapter USB 2.0 Cable... -
Page 7: Device Overview
8 hours and to sync the time in the QSD-722 again by using the widget (see section "PC Software Widget") if needed. -
Page 8: Status Led Indicator
To use the custom mode settings, while powered off please set the mode switch to the "custom mode" position, Launch the QSD-722 Widget installed on your computer and connect the camera via the included USB cable. (The LED indicator should turn orange to indicate that the camera is on and the widget will... - Page 9 Note: If a recording has started, you cannot switch between modes. When the QSD-722 is connected to a car through the 5V car adapter and the auto on /off mode is selected: Car-activated Recording: Auto-starts recording once the car is started, auto-stops recording when car is stopped.
-
Page 10: Frame Rate
2.5.2 Day/Night Mode Night mode: For recording in dark environments. Infrared night vision will be automatically turned on. Auto switching: QSD-722 will switch to "Day mode" or "Night mode" depending on the brightness level of the environment. Note: This device is not considered harmful, but the following precautions are recommended: 1. -
Page 11: Voice-Trigger Sensitivity
Low: Only substantial vibrations can trigger recording 2.5.6 Vibration Trigger Standby Mode Fast Wakeup: Start to record immediately once vibration is detected Power Saving: QSD-722 is completely off until it detects vibration. The standby time can last up to six months. 2.5.7 Motion-Trigger Sensitivity... -
Page 12: Trigger Input /Output Configurations
3 Trigger Input /Output Configurations 3.1 Input/Output Location & schematic Application for use of this feature: The QSD-722 can connect to external devices such as smoke detectors, pressure detectors, vibration detectors, and door/window sensors to trigger recording, or GSM alarm and buzzer function of the alarm. -
Page 13: External Trigger In Contact Type - Normal Open
2. Disconnect the USB cable from the QSD-722. 3. Put the QSD-722 mode switch in the custom mode position 3. Connect the QSD-722 to the external device (We suggest using AWG26 wire). The connection screws are on the top of the QSD-722. -
Page 14: External Trigger In Contact Type - Normal Close
2. Disconnect the USB cable from the QSD-722. 3. Put the QSD-722 mode switch in the custom mode position 3. Connect the QSD-722 to the external device (We suggest using AWG26 wire). The connection screws are on the top of the QSD-722. -
Page 15: Aux-Trigger Out Contact Type - Normal Open
QSD-722 Trigger out - (Pin6) should connect to external device Trigger in -. Note: 1. Please make sure the voltage input connected to the QSD-722 trigger out + (Pin5) is under 24V and the current is less than 1 amp. - Page 16 The recorder stays in the standby state if there are no triggers*. As depicted above, the trigger output is open. Triggered Whenever the QSD-722 is recording or detects any triggers*, the trigger outputs will be closed thus triggering the action of recording. * Triggers include voice trigger, motion trigger, vibration trigger, PIR trigger and external trigger-in.
-
Page 17: Aux-Trigger Out Contact Type - Normal Close
QSD-722 Trigger out - (Pin6) should connect to external device Trigger in -. Note: 1. Please make sure the voltage input to the QSD-722 trigger out + (Pin5) is under 24V and the current is less than 1A. 2. Please make sure the current direction is correct. Otherwise, the QSD-722 may be damaged. -
Page 18: Pc Software Widget
Please use the widget to sync the time to DVR again and remove files created in 2026 or beyond! 2. When using the QSD-722 Widget for the first time, express mode is set as the default. It has several typical scenarios to choose from. - Page 19 To contact Amcrest support, please do one of the following: Visit http://amcrest.com/contacts and use the email form Call Amcrest Support using one of the following numbers Toll Free US: (888) 212-7538 International Callers (Outside of US): +1-713-893-8956 USA: 713-893-8956 Canada: 437-888-0177 UK: 203-769-2757 ...
