INTRODUCTION Thank you for purchasing your new HMS 1100 home management system. You are about to enjoy a new feeling of security, comfort, convenience, and control. HMS 1100 coordinates lighting, heating and air, security, scenes, and messages based on your lifestyle and schedule.
The console is designed with everything that is necessary for you to program and operate your HMS 1100 control and security system. Because we feel that it is very important for you to feel comfortable with the operation of your HMS 1100, we recommend that you start by becoming familiar with your console.
4:00 PM SYSTEM OK If one of the doors, windows, motion, or other detector connected to the HMS 1100 is open, or has detected motion, the bottom line of the display will say, "ZONE NAME NOT RDY". For example, the display will show, "FRONT DOOR NOT RDY".
Trouble Beeps The HMS 1100 constantly checks the entire system for proper operation. If trouble is found, the trouble is displayed on the bottom line and the console will beep at the rate of two beeps per second to alert you to the trouble. This feature can be turned off if desired - See Set Up Arming, Beep On Trouble.
Areas If there is an area or a separate building that needs to be protected, your installer can divide your HMS 1100 system into two independent security systems: Area 1 through Area 8 (up to 8 Areas). Each area has complete access to all of the capabilities of the HMS 1100, yet the HMS 1100 can protect each area individually.
SECURITY SYSTEM OPERATION Disarming the Security System and Silencing Alarms Before going any further, you should know how to disarm your security system in the event that the alarm sounds. Turning the system OFF disarms the burglar alarm, resets the fire and emergency alarms, and silences all sirens and sounders. Press the OFF key.
2 = NIGHT The NIGHT mode is used when you are asleep and everyone in your household is at home. In the Night mode, your doors, windows, and non-sleeping area (i.e. downstairs) motion detectors are armed. In the Night mode, there is no entry delay. The alarm system sounder will be activated immediately if any door, window, or non-sleeping area (motion detector) is tripped.
If a fire zone is bypassed, the console will continue to beep until that zone is restored - See Restoring Zones. Auto-Bypass In order to prevent the alarm from sounding unexpectedly if a window or door is open when the system is armed, the HMS 1100 will automatically bypass the zone if it is opened when the system is armed.
The system waits the Dial Out Delay (0 - 60 seconds), then if programmed, the in-house phones are seized (disconnected) and the HMS 1100 begins to dial out. If you are having your system monitored by a central station, the central station will be sent a code representing the type of alarm (burglary) and zone involved.
For more information on the digital and voice dialer - See Digital Dialer and Voice Dialer. • The system continues to sound all alarms and flash the flashing light for 1-30 minutes after the alarm is activated. • After a 1-30 minute period, the sounder is turned off, and the alarm system resets itself. The console beeper stays on. If a zone is tripped after a reset, the sounder will again be activated, and the dialer will again dial out.
Police Emergency When the 1 key and the 3 keys are pressed simultaneously, the Police Emergency alarm is activated. This alarm operates exactly the same as described for Burglar Alarm Activated except: • The console display indicates: "BURGLARY! - POLICE EMERG TRIPPED". •...
Codes There are 99 user codes that you may assign to users of the system. All HMS 1100 codes are 4 digits in length. A code can be any number from 0001 to 9999. Each user should be assigned a security code with an authority level, areas that can be accessed (if area arming is used), and times and days in which the code will be valid.
If you have a code that is only valid in Area 1, you will not be able to disarm or arm Area 2. If you are in Area 1 and wish to disarm the security system in Area 2, HMS 1100 will allow you to disarm Area 2 from the console in Area 1 if you have a Master code or a code that is valid for both areas.
If the ' 0 ' (ALL) key had been selected, the display will show: DISARM ALL AREAS ENTER CODE: As the four-digit code is entered, "X" characters are echoed after the "ENTER CODE:" prompt. If the Master code or a valid code is entered, the console will beep one time and Area 2 will be disarmed. Even if Auto Bypass is enabled, the system will not arm another area if any zones in that area are not ready.
The Battery reading should be over 200 - See Status \ Test. Pick up an inside phone and press the # key. When the menu is spoken, press 8, Then 3. The HMS 1100 should say "ADDRESS IS: "and play your name and address. If it does, the telephone dialer, telephone access and telephone control systems are all working correctly.
Control Commands The control features of the HMS 1100 make it easy and convenient to control almost any light or appliance from the console or over the telephone. You may also have your heating and air conditioning (HVAC) under control of the system, which will allow you to save energy dollars by setting the temperature appropriately when you are home, asleep, or away.
House Codes All of your X-10 modules, controlled by your HMS 1100, must be set to a House Code. A House Code can have 16 unit numbers. The House Code is set on each module using a dial. House codes are letters A through P.
Scrolling Through Names The HMS 1100 stores names for Units, Zones, Buttons, Codes, Temperatures, and Messages so that you don't have to remember that "UNIT 5" is the "DEN LIGHT" and "ZONE 1" is the "FRONT DOOR". In general, any time you enter a unit, zone, button, code, temperature, or message number, you can press the down arrow key to display its name, then use the up and down arrow keys to scroll through the list of other names.
The control menu is used when controlling lights and appliances. To enter the control menu, from the top-level display or from the main menu, press the 1 (CTRL) key on the console keypad. HMS 1100 will automatically display the first named item in that list.
The console will beep and the lighting level will be adjusted. The top line of the console display will read: Entry Lights LVL 65 Ramp Command When ALC Switch Modules are being used, it is possible to ramp the lighting level of an ALC Dimmer Switch to a new level at a selectable ramp rate.
At this point, one of the menu choices may be entered or the ' * ' or ' # ' key may be pressed to redisplay the menu. Note: When an X-10 signal is received over the powerline, HMS 1100 will automatically update the status of the unit number.
Leviton Scene Control HMS 1100 supports Leviton Scene Control (a feature found in certain Leviton Switches). There are 256 Scenes that can be set and executed. The Leviton Switches are divided into "lighting groups" of four units each. Each of these lighting groups can be set to four different Scenes.
Buttons A powerful feature of the HMS 1100 is the ability to program Buttons. A Button (also known as macro) is a number on the keypad that is programmed to execute a series of commands when it is pressed. Buttons are used to program functions that are specific to your home and lifestyle.
Temperature Control Your HMS 1100 can control temperatures of your heating and cooling system, monitor the outside temperature, and detect high and low temperatures in special situations. Other appliances can be controlled by temperature as well - such as a bathroom heater or a ceiling fan.
Page 33
Upstairs 4=FAN To change the system mode on a thermostat, press 1 (MODE). A menu presenting options appropriate for that type of thermostat is then displayed. For heat/cool thermostats with auto changeover: Upstairs MODE 0=OFF Upstairs MODE 3=AUTO To change a temperature setting, press 2 (HEAT), 3 (COOL), or 2 (TEMP) as appropriate: Upstairs HEAT ENTER TEMPERATURE: Upstairs COOL...
You can control appliances connected to X-10 and ALC modules (such as a ceiling fan) using Advanced Control Programming (ACP) of the HMS 1100. For example, the ceiling fan can be programmed to come on if the temperature goes above the High temperature.
The humidity level (0-100%), the low humidity setting, and high humidity setting can be viewed and modified using the temperature menu. To enter the temperature menu, from the top-level display or from the main menu, press the 5 (TEMP) key. The humidity zone can be specified by entering the zone number followed by the ' # ' key, or by pressing the arrow keys to scroll through the list of temperature and humidity zones.
Page 36
4 = TEST (SYSTEM DIAGNOSTIC TEST) The diagnostic test performed by the HMS 1100 allows you to check the status of the battery, telephone, bell circuit, auxiliary fuse, and security zone loop readings. The display is updated 3 times per second, although the actual readings are taken 10 times per second.
You may enter a unit number to start displaying the status with that unit, or simply press the down arrow key to scroll through the list of temperature zones. The status display is as shown under Temperature Control, except that now the arrow keys may be used to continue scrolling.
An event is logged after three unsuccessful attempts are made to log into the system from a remote phone, the HMS 1100 will lock out remote telephone access for 1 hour to discourage any further attempts to access the system - See Telephone Control.
Message To show, log, clear, and send text messages, and to say and phone (dial out) your voice messages, press the 8 (MESSAGE) key: MESSAGE 1=SHOW 4=SAY Show Message The 1 (SHOW) key allows you to display the selected text message(s) on the console's top-level display. This can be a helpful reminder of special events and occasions.
128 messages for a matching message. If one is found, the Program Command (macro) corresponding to the matching message is activated. When receiving an ASCII message that is over 15 characters, HMS 1100 only processes the last 15 characters of the message. Pro-Link determines that a message has been received when: •...
In-House Phones Each time you pick up your telephone at home, the HMS 1100 will also pick up the line and listen for a # (pound) key. If HMS 1100 does not hear the # key within 5 seconds, it hangs up and does not listen in again until the next time you pick up your phone.
So that the HMS 1100 does not tie up your phone, there is a 10 to 15 second time-out that starts after the HMS 1100 stops talking. If it does not hear any numbers from your phone in 10 to 15 seconds after it stops talking, the HMS 1100 will hang up. If you are on a remote phone and the HMS 1100 hangs up, you must call the HMS 1100 again.
When bypassing and restoring a zone, if voice descriptions have been programmed, after a three-second delay, the system will begin reading from the list of zones. If the ' # ' key is pressed, HMS 1100 will read the next three descriptions (if programmed).
Press 7 from the MAIN MENU to get to the EVENT menu. The HMS 1100 will read the 3 latest events. Press the ' 7 ' key for HMS 1100 to read 3 more events, or ' * ' to cancel.
When you can't find a word you need to complete a voice description or voice message, you have to ability to record a custom phrase in HMS 1100. This phrase can then be used as part of your voice description and spoken over the telephone along with the item number that is normally spoken.
The HMS 1100 will say, "GOOD-BYE" and hang up. From an in-house phone, the dial tone will return. From a remote phone, you will hear a click as the HMS 1100 hangs up. It is recommended that you press 9 to terminate a remote call. If you don't, the HMS 1100 will hang up anyway after about 15 seconds.
What the HMS 1100 Voice Dialer Does When an alarm is activated, the HMS 1100 will wait the Dial Out Delay. If your system is monitored by a central station, it will be notified first. Then the voice dialer will dial out to the numbers as described above.
Then, press * to exit the event log. Now press 9 (good-bye) to make the HMS 1100 hang up. Hang up your phone and call your premises to be sure that it wasn't someone who has forgotten their code. If not, call the police.
Built-In Ethernet Port The built-in Ethernet port (J6) allows a device to connect to the HMS 1100 controller via a network (i.e. Ethernet, Internet) using a secure, encrypted communication link. The Ethernet port transports HMS application-level packets containing HMS-Link serial protocol messages over IP.
(the router/switch) in the local network. This allows you to locate and connect to the HMS 1100 controller without having a computer on the local network powered up and running.
To connect to an HMS 1100 controller on a local network using HMS PC Access, under Configure >> Network enter the controller’s IP address: (i.e. 10.0.0.230) Local / Wide Area Network Page 43 To connect to an HMS 1100 controller from the Internet using HMS PC Access, under Configure >>...
Set Up Codes HMS 1100 has 99 user codes that you may assign to users of the system. All HMS 1100 security codes are 4 digits in length (0001 to 9999). Each user should be assigned a security code with an authority level, areas that can be accessed (if area arming is being used), and times in which the code will be valid.
This item is used to correctly calculate the times for sunrise and sunset. You are only asked this question when you set the time. Once the time is set, HMS 1100 will automatically adjust the "time of day" each time daylight savings time begins and ends.
Advanced Control Programming (ACP) Your HMS 1100 can be programmed to do automated control and security functions on a time schedule or in response to an event occurring in the system. You may program the following items: • Unit Numbers: On, Off, On for time, Off for time, Dim, Brighten, Dim for time, Brighten for time, Level, and Scene •...
Page 55
Menu 1 - Programs for a particular control unit number Menu 2 - All Security related programs Menu 3 - Programs for a particular macro button Menu 4 - Programs for All On/Off functions Menu 5 - Programs for a particular Temperature zone Menu # - Displays every program Selecting the 1 (CTRL) or 5 (TEMP) key will prompt you to specify the desired unit or temperature zone.
The arrow keys are used to scroll through the programs. Pressing the ' # ' key while a particular program is displayed will allow that program to be edited or deleted. The display shows: SHOW PROGRAM 1=EDIT Press the 1 (EDIT) key to edit the selected program. The Edit Program menu is displayed which allows the various parts of the program to be changed - See Edit Program.
Edit Programs When Selecting the 1 (WHEN) key, from the Edit Program menu, allows the time or button/event that activates the program to be changed. The display shows: EDIT WHEN 1=TIMED 2=BUTTON Times Programs Selecting 1 (TIMED) sets the program to be activated at a specific time of day. You are prompted to enter the time and date or days of week.
Button and Event Programs Selecting 2 (BUTTON), from the "Edit When" menu, sets up a program to be activated when a macro button is executed or an event occurs. The user is prompted to specify the button/event that activates the program: BUTTON: ENTER BUTTON A specific macro button may be activated by entering the button number followed by the ' # ' key, or by using the arrow keys to...
After the security mode is selected, an additional menu appears which allows you to further specify the event button. For example, you would like to activate an event button when you arm the system into the 3 (AWAY) mode: WHEN AWAY: 1=DELAY 2=CODE Any of these may be selected alone or in combination.
HMS 1100. The HMS 1100 can also respond to scene changes initiated at Compose keypads and dimmers. When a scene change is initiated, HMS 1100 can activate an event button program. You are first prompted to enter the X-10 house code:...
After specifying the X-10 House Code and X-10 Unit Code, select 0 for Off, 1 for On, or 2 for Scene. "Off" events will be activated whenever the selected device is turned off. "On" events will be activated whenever the selected device is turned on.
Edit Program Command Selecting 2 (CMD), from the Edit Program menu, allows the commanded action for the program to be specified. The following menu is displayed: 1=CONTROL 3=BUTTON 5=TEMP 8=MESSAGE After the command is specified, the display returns to the Edit Program menu: Program Control Commands Press the 1 (CONTROL) key to command lights and appliances.
Program Button Commands Select the 3 (BUTTON) key to program a macro button. Specify the macro button to be executed - See Button Programs. BUTTON: ENTER BUTTON Program All On / All Off Commands Select the 4 (ALL) key to program All Lights On (X-10), All Units On (ALC), and All Units Off (X-10 & ALC) commands. It is also used to program Scenes, issue the Scene On command, and issue the Scene Off command to switches that support Leviton Scene Control.
Edit Program Condition Selecting the 3 (&COND) key, from the Edit Program menu, allows the condition for the program to be specified. The condition is optional in all program lines. This condition must be true when the program time or event occurs for the program to executed. Note: Two (2) conditions can be specified in each program line;...
The zone will be displayed and you will be prompted for the state of the zone: IF Front Door: 0=SECURE Program Time Clock Conditions Select the 9 (TIME) key to specify that the program should only execute if a specified Time Clock is either On or Off. The display prompts you for the Time Clock number: ENTER TIME CLOCK: Enter the Time Clock number followed by the ' # ' key.
Set Up Dial The Set Up Dial menu is used to configure all of the telephone related items for the HMS 1100. To enter the Set Up Dial menu, from the Setup menu, press the 4 (DIAL) key. Use the arrows to scroll through the items. For each item, the top line displays a description of the item and its current setting.
DIAL OUT 1 OFF Dial Out Number 1 has two times associated with it, an On and Off time. The HMS 1100 will only call this number if the time and days are between the Dial Out 1 On and Dial Out 1 Off times and dates.
Set Up Arming To configure different arming and disarming options, from the Setup menu, press the 5 (ARM) key. Entry Delay The Entry Delay is the time, in seconds, that you have to turn off the alarm after entering your home. The Entry Delay only applies to the entry/exit zone (i.e.
Beep On Trouble If the HMS 1100 detects any troubles with itself or one of the zones connected to it, it will display a message on the screen and beep the console twice per second, continuously (i.e. beep beep...beep beep...). You can silence this sound by pressing the ' * ' key.
Enable Freeze Alarm If there are one or more Thermostat in a system, they can also be used to detect a freeze condition - See Freeze Alarm. The default for Enabled Freeze Alarm is No. Flash For Alarm You may enter one unit number that will flash on and off continuously when the alarm is activated. This should be an outside light to alert neighbors and police to your property if the alarm is activated.
To turn HC 1 All On feature On, press 1 then ' # '. To turn HC 1 All On feature Off, press the 0 key, then ' # '. The default setting for HC 1 X-10 All On is Yes. House Codes 2-16 X-10 All Off This feature allows you to choose if House Codes 2-16 will respond to the X-10 All Off commands.
Prime Meridian, and time zone. These items should be set to the proper values for the location where the HMS 1100 is installed. The latitude and longitude for a particular location may be obtained from an almanac or map of the area. These values should be entered to the nearest degree.
Controller IP Address The controller’s local network IP address is used to identify the HMS 1100 controller on the network. To view and assign the controller’s local network IP address, from the Set Up menu, press the 6 (MISC) key. Using the down arrow key (...
Encryption Key Encryption and decryption of data between the HMS 1100 controller and the connected device is based on the Advanced Encryption Standard (AES) using a 128-bit cryptographic key. A unique encryption key is randomly assigned to each HMS 1100 controller at the factory (no records of these keys are kept at the factory).
Pick up an inside phone and press the ' # ' key on the telephone within 5 seconds of picking up the phone. The HMS 1100 will respond with a menu. Press 8 on the telephone keypad, then 8. The unit will say "ADDRESS IS:" then the HMS 1100 will play back the message stored in the Address memory if one has been entered by your installer.
UNDERWRITER'S LABORATORIES REQUIREMENTS For a complete list of requirements and restrictions when installing the HMS 1100 panel in a UL Listed system, refer to the Underwriter's Laboratories Requirements section of the Installation Manual (1307593). When used in UL Listed Installations, the following items apply: The "High Security Mode"...
FEDERAL COMMUNICATION COMMISSION NOTICE: This equipment complies with Part 68 of FCC Rules. On the door, inside of the HMS 1100 enclosure, is a label that contains, among other information, the FCC registration number and Ringer Equivalence Number (REN) for this equipment.
IF YOU HAVE TROUBLE WITH YOUR PHONES ...and you suspect that your HMS 1100 is causing the trouble, disconnect the Controller from the phone lines by removing the PHONE LINE cable from BOTH THE PROCESSOR BOARD AND THE RJ31X JACK INSIDE THE CONTROLLER ENCLOSURE.
APPENDIX A - DIAL OUT PLANNER Use the following dial-out planner to help you set-up the voice dial-out numbers: HMS 1100 Voice Dial-Out Planner DIAL OUT NUMBER 1: __________________________________ AREA: _____________ DIAL OUT 1 ON: TIME: _______________ DAYS: _______________ DIAL OUT 1 OFF:...
Dear ___________________________________________________________________ I have programmed my HMS 1100 home management system to call you if my alarm is activated. If it is activated, it will call and say: "Emergency... Emergency... The (burglar or fire) alarm has been activated at the following address:...
APPENDIX C - VOICE DESCRIPTION CODES CODE DESCRIPTION (ADDRESS MSG) (BEEP) (MEMO MESSAGE) (PAUSE) (SHORT PAUSE) A. M. ABOVE AC POWER ACCESS ACTIVE ADDRESS AFTERNOON ALARM ALERT ALLEY AMPLIFIER ANNIVERSARY ANTIQUE APARTMENT APPLIANCE APPROACHING APRIL AREA ARMED ASLEEP ASSISTANCE ATRIUM ATTIC AUDIO AUGUST...
Page 83
CODE DESCRIPTION FALL FAMILY FATHER’S FAULT FEBRUARY FENCE FIFTEEN FIFTY FILE FILTER FIRE FIRST FIVE FLAG FLOOD FLOOR FLOW FORCE FORTY FOUNDATION FOUNTAIN FOUR FOURTEEN FOYER FREEZE FREEZER FRIDAY FROM FRONT FULL FUNCTION FURNACE FUSE GALLERY GAME GARAGE GARDEN GATE GIRL'S GLASS GO TO...
Page 84
CODE DESCRIPTION ONLINE ONLY OPEN OPTION OTHER OUTDOOR OUTLET OUTSIDE OVER OVERFLOW OVERHEAD P. M. PANIC PANTRY PARKING PARLOR PARTY PATIO PAUSE PERIMETER PERSONNEL PHONE PHRASE PIER PLACE PLANTS PLAY PLEASE CHOOSE PLUS POINT POLICE POOL PORCH POSITION POUND PRECIOUS PRESS PRESSURE PROGRAM...
When you can't find a word that you need to complete a voice description or voice message, you have to ability to record a custom phrase in HMS 1100. This phrase can then be used as part of your voice description and spoken over the telephone along with the item number that is normally spoken.
