Summary of Contents for Newton MC300IW

  • Page 1 ™ MC300IW In-Wall LCR Loudspeaker Installation and User Manual ®...
  • Page 3 INTRODUCTION Thanks for choosing a Newton Series loudspeaker. The MC300IW features the finest drivers and a precision crossover network in a space-saving in-wall format. The Product Development Team at Cambridge SoundWorks believes there is no better combination of audiophile-level attention to detail and reasonable cost.
  • Page 4 If you do not posess the necessary skills or are other- wise not comfortable with performing a speaker sys- tem installation, we strongly recommend you rely on a qualified home entertainment system installer. Contact your dealer, or Cambridge SoundWorks for assistance in selecting a suitable installer.
  • Page 5 CRT based video monitor. Because the MC300IW has very wide and uniform dis- persion there is a great deal of flexibility in placement.
  • Page 6 The terminals used on the MC300IW loudspeakers will accept up to AWG #12 speaker cable. We recommend using the largest wire that is practical to run in your installation.
  • Page 7: Installation

    INSTALLATION 1. Decide where you want the MC300IW speakers to be placed. Using a stud-finder (or other means), locate the nearest wall stud adjacent to this loca- tion. Adjust your loudspeaker placement so that the necessary wall cutout will not intersect the stud.
  • Page 8 Be careful to not over-tighten, only moder- ate force is necessary to secure the MC300IW in- wall speaker to the mounting surface. Note: A smooth, flat surface is desired for the most secure installation and best air seal.
  • Page 9: About Amplifier Power

    The MC300IW in-wall loudspeakers can safely be used with the most powerful amplifiers and receivers designed for home listening, as long as these compo- nents are used within reasonable limits.
  • Page 10: In Case Of Difficulty

    Cambridge SoundWorks store you may call us at 1-800-FOR-HIFI for a factory Return Authorization. Do not return the MC300IW in wall loudspeakers, or any parts without first obtaining a Return Authorization.
  • Page 11: Specifications

    SPECIFICATIONS MC300IW Speaker Type: 2-way, infinite baffle Woofer: 2" x 4" Tweeter: 25mm silk dome Frequency range: 65-20,000Hz Recommended Amplifier Power Range: 25W – 150W RMS 6 1/2" 5 3/4" (Cut out) Sensitivity (2.83V @ 1meter): 89dB Nominal Impedance: 8-Ohms Overall dimensions (HxWxD): 14"...
  • Page 12 CAMBRIDGE SOUNDWORKS, INC. 26 Dartmouth Street, Westwood MA, 02090 Telephone: 1-800-367-4434 Fax: 1-617-527-3194 Company P81-1940...
