Summary of Contents for Digital Intelligence MultiDrive Adapter
- Page 1 Important! Important! Read Me Read Me First First MultiDrive Adapter Digital Intelligence...
- Page 2 • UltraBlock™ is a trademark and Digital Intelligence® is a registered trademark of Digital Intelligence, Inc. •...
-
Page 3: Limited Warranty
LIMITED WARRANTY Digital Intelligence, Inc. (“DI”) warrants to the original end-user that the product (excluding accessories) will be free from defects in materials and/or workmanship for a period of one (1) year from the date of shipment. This limited warranty is non-transferable, and is issued only to you, the fi... -
Page 4: Table Of Contents
Connecting a 2.5 inch hard drive............Connecting a 1.8 inch hard drive with pin connector......Connecting a 1.8 inch hard drive with ZIF connector......Connecting the MultiDrive adapter to a host........Troubleshooting................MultiDrive Adapter Technical Specifi cations........MultiDrive Adapter Manual 1... -
Page 5: Package Contents
User Guide (1) What is the MultiDrive Adapter? The MultiDrive Adapter allows 2.5 inch, 1.8 inch pin connector and 1.8 inch ZIF connector IDE hard drives to be connected to a standard 40 pin IDE connector. The MultiDrive Adapter is designed to be used with various write blockers includ- ing the UltraBlock IDE, UltraBlock IDE/SATA, FireFly IDE and the UltraBay. - Page 6 Finish installing the drive into the housing and secured using the back bracket and screws. The assembly can be plugged directly into the adapter and connected to a write blocker or other standard IDE 40 pin connector. ©2008 Digital Intelligence, Inc.
-
Page 7: Connecting A 2.5 Inch Hard Drive
IDE 40 pin connector. Connecting a 1.8 inch hard drive with ZIF connector: In order to use the MultiDrive adapter with a 1.8 inch hard drive with a ZIF con- nector, the drive must be installed using the ZIF drive housing. The MultiDrive adapter comes with two sets of brackets, one for Toshiba drives (labeled “T”) and... -
Page 8: Connecting The Multidrive Adapter To A Host
Connecting the MultiDrive adapter to a host: The MultiDrive adapter connects to a write blocker or standard 40 pin IDE con- nector. Be sure to also connect the 4 pin molex power connector to provide power to the drive. Troubleshooting: Please try the following troubleshooting steps if experiencing diffi... -
Page 9: Multidrive Adapter Technical Specifi Cations
MultiDrive Adapter Technical Specifi cations Product MultiDrive Adapter Connectors Host side: 40 pin male IDP connector 4 pin molex power connector Drive side: 44 pin female IDP connector 50 pin male connector ZIF to 50 pin female adapter card LEDs... - Page 10 Digital Intelligence, Inc. 17165 W. Glendale Dr. New Berlin, WI 53151 P: 262.782.3332 F: 262.782.3331 ©2008 Digital Intelligence, Inc. All rights reserved.
