ELENBERG 2910F, CAMERON STV-2937
SERVICE MANUAL
1. Caution.....................................................................2
2. Specification...............................................................6
3. BOM List ........................... .......................................9
4. Alignment Procedure....................................................35
5. Block Diagram............................................................39
6. Schematic Diagram......................................................40
7. PCB Layout................................................................41
8. Explode View Diagram...................................................43
This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product.
DISTAR
DT-2977
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Distar DT-2977
Summary of Contents for Distar DT-2977
-
Page 1: Service Manual
ELENBERG 2910F, CAMERON STV-2937 DISTAR SERVICE MANUAL DT-2977 1. Caution……………………………………………………………2 2. Specification………………………………………………………6 3. BOM List ……………………… …………………………………9 4. Alignment Procedure………………………………………….…35 5. Block Diagram……………………………………………………39 6. Schematic Diagram………………………………………………40 7. PCB Layout………….……………………………………………41 8. Explode View Diagram……………………………………………43 This manual is the latest at the time of printing, and does not include the modification which may be made after the printing, by the constant improvement of product. - Page 2 TCL M113A chassis alignment instruction Enter factory mode in production line Simply press the D-mode key on the factory remote handset. Enter service mode Press and hold the VOLUME DOWN key tightly on the unit until minimum level and don’t release the VOLUMN DOWN key, then press the DISPLAY key on the remote handset.
- Page 3 Vertical HITS(11) Input a NTSC Adjust HITS for vertical amplitude. geometry for VP60(02) cross hatch Adjust VP60 for vertical position. NTSC system VLIS(0A) pattern. Adjust VLINS for vertical linearity. (Key 1) VSS(08) Adjust VSS for vertical S-correction VBLK(00) (normally use default value) VCEN(1C) Adjust VCEN for vertical position.
- Page 4 Key 5 ST3 (20) ---------- (all use default value) (sharpness SV3 (20) adjustment) ST4 (20) SV4 (20) SVD(15) ASSH(04) SHPX (3F) SHPN (1A) Key 7 RFAGC (1A) Receive a 60dB Adjust RFAGC until the picture noises (Status SBY (08) grey scale + disappear exactly.
- Page 5 Key game OSD1(2B) ---------- (all use default value) (other OSDF1(63) adjustment) OSD2(1C) OSDF2(63) HAFC(09) NOIS(01) UCOM(00) Key 0 R CUT (80) Black and white 1. Measure the dark side of the picture with (White G CUT (80) pattern (PAL) a color analyzer and set RCUT to 80. balance B CUT (80) Then adjust BCUT and GCUT until the...
