8.0: TECHNICAL SPECIFICATIONS

SYSTEM
Frequency response
(1)
Maximum SPL
(2)
Distortion
Dispersion (@-6dB)
Drive unit LF/MID
Dual Concentric™ HF
SuperTweeter™
Shielded
ELECTRONIC SECTION
Input
Sensitivity
Crossover frequency
Amplifier output power
User Controls
Power supply
CABINET
Low frequency design
Cabinet construction
Cabinet finish
Cabinet dimensions (HxWxD)
Total Cabinet weight
NOTES
(1) +/- 3 dB, measured at 1m in an anechoic chamber. (2) Peak SPL at mix position for 1 pair driven.
Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications which Tannoy reserve the right to alter without
prior notice. Please verify the latest specifications when dealing with critical applications.
16
Downloaded from www.Manualslib.com
P6D P8D
59Hz – 51 kHz 43Hz-51kHz
116dB 119dB
<0.5% <0.4%
90 degrees 90 degrees
165mm (6") Dual Concentric™ constant directivity 200mm (8") Dual Concentric™ constant directivity
driver with multi fibre paper pulp cone driver with multi fibre paper pulp cone
25mm (1") titanium dome neodymium magnet 25mm (1") titanium dome neodymium magnet
system system
25mm (1") titanium dome neodymium magnet 25mm (1") titanium dome neodymium magnet
system system
Yes Yes
600Ω balanced on combined XLR/jack 600Ω balanced on combined XLR/jack
0.775 Vrms for Full Output 0.775 Vrms for Full Output
2.5kHz 2.2kHz
LF 75 W rms HF 35 W rms LF 120 W rms
Front panel mounted on/standby/mute LED Front panel mounted on/standby/mute LED
indicator indicator
Rear Trim +6/-12dB Rear Trim +6/-12dB
80Hz High-Pass switch (for AV use) 80Hz High-Pass switch (for AV use)
16-way DIP switch selection for response 16-way DIP switch selection for response
optimisation optimisation
Fixed mains voltage Fixed mains voltage
IEC inlet with detachable power cord IEC inlet with detachable power cord
Region Specific (to order) 110/220/230v Region Specific (to order) 110/220/230v
Optimised bass-reflex loaded Optimised bass-reflex loaded
MDF cabinet and front baffle, tongue and groove MDF cabinet and front baffle, tongue and groove
front and back front and back
Black cabinet Grey painted baffle with brushed Black cabinet Grey painted baffle with brushed
aluminium inlay aluminium inlay
356mm x 220mm x 378.5mm 440mm x 272mm x 370.5mm
14" x 8 5 / " x 17 7 / " 17 3 / " x 10 3 / " x 14
8 8 8 4
13kg (28.6lbs) 18kg (39.6lbs)
manuals search engine
9.0: DIMENSIONS
220.0mm
8 5 / "
5
P6D
HF 60 W rms
272.0mm
3
10 / "
4
5 / "
8
P8D
378.5mm
17 7 / "
8
337.0mm
13 1 / "
4
356.0mm
14"
370.5mm
14 5 / "
8
337.5mm
1
13 / "
4
440.0mm
17 3 / "
8
17
