- Page 1 USER MANUAL Airbridge WiFi HD Adapter Model No：HDCN0026M1 Enjoy the vivid world! REMARK Manufacturer does not make any commitment to update the information contained herein. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
-
Page 2: Dear Customer
Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. The products are designed to make your A/V device use more convenient, comfortable, productive and cost-efficient. -
Page 3: Package Contents
PACKAGE CONTENTS: 1. Main unit 1pcs 4. User manual 1pcs 2. 5V DC power adapter 1pcs 5. User manual 1pcs 3. Remote controller 1pcs FEATURES OF THE INTERFACE: SELECT FIG.1.0 Front Panel View OUT: HDMI output port indicator : WiFi input mode indicator IN1: HDMI IN1 input port indicator SELECT: Source selection and standby IN2: HDMI IN1 input port indicator... - Page 4 HDMI IN1 HDMI IN2 HDMI OUT FIG.1.2 Rear Panel View HDMI IN1: HDMI input port1 HDMI OUT: HDMI output port HDMI IN2: HDMI input port2 : Power on/standby INPUT: Source selection key IN1: Select the HDMI IN1 input IN2: Select the HDMI IN2 input WiFi: Select WiFi input mode (Note: Use after the battery separator film is pulled out) FIG.1.3 Remote Panel View...
- Page 5 CPU Dual Core 2 EZCast_Win. Windows /Vista SP2 GHz / 64MB VRAM www.iezvu.com/download /7 SP1/8 or above search the App name “EZCast” in Windows Windows CPU 1GHz/DDR Phone 8.1 EZCast .xap Windows Phone Store or download Phone 1GB or above above app from www.windowsphone.com...
-
Page 6: Setting Menu
SSID and password will be displayed on the TV screen. Each adapter will have only SSID name and password. When you execute the app, click “Find device” to discover EZCast receiver and start to cast. In the device list click search to the SSID connection. After the connection is ok, the display will show the interface below 3. - Page 7 In setting function, you can setup EZCast Receiver’s configurations including output resolution, change SSID password, setup router connection for internet surfing, ect. Then client device into a virtual remote interface. To change the option through the virtual remote controller, click the "Key" icon will display the virtual keyboard.
-
Page 8: Specifications
EZMirror(EZAir of iOS) EZMirror is fully compatible with Miracast (EZAir compatible with AirPlay). you can click the EZMirror button in EZCast app, and the receiver will be switched to Miracast mode. Miracast standard mirrors the screen onto the display. Note: not all Android devices support the Miracast function, the details please consult your to devices manufacturers. - Page 9 HDMI output resolution………………...4Kx2K/30Hz,1080p/1080i/720p/576p/576i/480p/24/30/50/60Hz Support video color format …………………………..…………….……………24bit/deep color 30bit/36bit HDMI audio format………………..……………..DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD Wireless Frequency range………………………………………………………………….2.4～2.4835GHz Wireless transmission rate…………………………………………………………………………. 150Mbps Wireless transmit power……………………………………………………………………15dBm (MAX TX) Wireless transmission distance…………………………………………..…10m (Indoor and no obstacle) Transmission delay…………..≤200ms（Related to PC performance, may be greater than this value） HDMI max bandwidth…………………………………………………………….…….….………….250MHz HDMI max baud rate……………….…….………………….……………………….…….…………7.5Gbps Input/Output TMDS signal ………….…………………………….…..…….………0.5~1.5Volts p-p（TTL）...
- Page 10 Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3.
