Page 2: Table Of Contents
Contents 1. Important Safety Information Important Safety Instruction......................2 Warnings............................3 Safety Precautions Instruction......................4 2. Accessories ..........................6 3. Installing the LED TV Installing the Stand.........................7 4. Overview of the TV set Front View............................8 Rear View ............................9 5. Connect External Devices Connect the Power Cord .......................10 Conect to Antenna or Cable ......................11 Connect Device Via HDMI interface....................11 Connect Device Via Component(Y/Pb/Pr) + Audio L/R Interface ..........12... -
Page 3: Important Safety Information 1
Important Safety Information 1... -
Page 4: Warnings
Important Safety Information Warnings 1.Read these instructions. 2.Keep these instructions. 3.Heed all warnings. 4.Follow all instructions. 5.Do not use this apparatus near water. 6.Clean only with dry cloth. 7.Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi... -
Page 5: Safety Precautions Instruction
Important Safety Information Safety Precautions Instruction Observing the simple precautions discussed in this booklet will provide you with many years of enjoy- ment and safe operation. This product complies with all applicable India safety requirements. 1. Read & Follow Instructions All safety and operating instructions should be read and followed before the TV is operated. - Page 6 Important Safety Information 10. Power-Cord Protection Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs,convenience receptacles, and the point where they exit from the TV.
- Page 7 Important Safety Information 15. Object and Liquid Entry Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or short-out parts that could result in a fi re or electric shock. Never spill liquid of any kind on or inside the 16.
-
Page 8: Accessories
Accessories Please make sure the following items are included with your LED TV. If any items are missing, please contact your dealer. Stands and Screws LED TV P.MODE S.MODE FREEZE CH.LIST AUTO ASPECT SOURCE DISPLAY SLEEP -/-- Instruction Manual Remote Control and batteries... -
Page 9: Installing The Led Tv
Installing the LED TV Installing the Stand Figure 1 Figure 2 Figure 3 1. Place the TV set on soft cloth or cushion with face down.Place the base in position as shown. (see Figure 1). 2. Insert and tighten 2screws into the pedestal holes as show (see Figure 2) 3. -
Page 10: Overview Of The Tv Set
Overview of the TV set Front View Item Description Power Switch the TV on/standby. SOURCE Select input source. MENU Switch OSD menu ON/OFF. Channel down when source is TV, or select a control while in OSD menu. Channel up when source is TV, or select a control while in OSD menu. VoL- Decrease sound volume or adjust a highlighted control while in OSD menu. -
Page 11: Rear View
Overview of the TV set Rear View EARPHONE AV IN YPbPr IN HDMI VGA IN PC AUDIO IN Item Description Connect to your earphones. By connecting the earphones, you can listen to EARPHONE the sound from the TV on headphones. *If you connect the earphones, the TV speakers will be muted. -
Page 12: Connect External Devices
Connect External Devices Connect the Power Cord How to connect with power cord Plug the power cord into the power outlet. Ensuring that the cord is tightly connected at both ends. It is strongly recommended for best broadcast reception, to use digital cable, satellite, or a high quality roof top antenna. -
Page 13: Connect Device Via Component(Y/Pb/Pr) + Audio L/R Interface
Connect External Devices Connect Device Via Component(Y/Pb/Pr) + Audio L/R Interface TV REAR PANEL YPbPr AV IN Optional Component cables (not included) Digital set top box, gaming console or DVD Connect Device Via Video + Audio L/R Interface TV REAR PANEL AV IN Audio Video Cable (not included) Digital set top box, gaming console or DVD... -
Page 14: Connect Pc Via Vga/Hdmi Interface
Connect External Devices Connect PC Via VGA/HDMI Interface Use the LED TV as the monitor of your computer. The picture below shows the connection for PC. The LED TV can also be connected to PC with VGA or HDMI output. YPbPr IN HDMI VGA IN... -
Page 15: Using The Remote Control
Using the Remote Control Inserting Remote Control Batteries 1. Remove the battery cover by pulling then lifting the knob on the cover. 2. Insert the batteries, corresponding to the (+) and (-) markings on the battery compartment. 3. Reattach the battery cover. CAUTION •... -
Page 16: Remote Control
Using the Remote Control Remote Control... -
Page 17: Remote Control Function Buttons
Using the Remote Control Remote Control function buttons Press to enter or exit standby mode. POWER Press to turn on or off the Audio Sound. MUTE To play the previous chapter, title or track. Press to scan in reverse. Press to scan in forward. To play the next chapter, title or track. -
Page 18: Basic Operation Of The Tv
Basic Operation of the TV Turning the TV On and Off Press the POWER button on the remote control. You can also use the Power button on the side of the panel. *If there is no input signal within 15 minutes, TV will be P.MODE S.MODE turned off automatically. -
Page 19: Adjusting The Volume
Basic Operation of the TV Adjusting the Volume Press VOL +/- to adjust volume. To turn off the volume, press MUTE. To restore volume, press MUTE again. SLEEP Selecting the Input Source Input Source To select the TV or other external input sources connected to the TV. -
Page 20: Channel Setting
Channel setting Channel menu Press MENU on the remote control to display the main Menu. 1. Press◄ or ►to select CHANNEL. 2. Press▲ or ▼to highlight an item, press OK button to enter submenu. Auto Tuning Manual Tuning CHANNEL Programme Edit Swap Menu Enter... -
Page 21: Picture Setting 9
Picture Setting 9 Picture menu Press MENU on the remote control to display the main Menu. 1. Press◄ or ►to select PICTURE. 2. Press▲ or ▼to highlight an item, press OK button to enter submenu. Picture Mode Standard Contrast Brightness Color PICTURE PICTURE... -
Page 22: Sound Setting Sound Menu
Sound Setting Sound menu Press MENU on the remote control to display the main Menu. 1. Press◄ or ►to select SOUND. 2. Press▲ or ▼to highlight an item, press OK button to enter submenu. Sound Mode Standard Treble SOUND Bass Balance Auto Volume Swap... -
Page 23: Time Setting
Time setting Time menu Press MENU on the remote control to display the main Menu. 1. Press◄ or ►to select TIME. 2. Press▲ or ▼to highlight an item, press OK button to enter submenu. Sleep Timer Auto Sleep TIME OSD Timer Swap Enter Menu... -
Page 24: Setting Setting Menu
Setting Setting menu Press MENU on the remote control to display the main Menu. 1. Press◄ or ►to select SETTING. 2. Press▲ or ▼to highlight an item, press OK button to enter submenu. OSD Language English Aspect Ratio 16:9 Blue Screen SETTING Key Lock Reset... -
Page 25: Multimedia
Multimedia Media Play - USB Device First press SOURCE into multimedia channel, plug in USB storage device, the following picture mark color, if blue say television has to recognize the USB, gray has said no to recognize. After confi rmed television to recognize USB storage devices, press ◄ or ►button to select photo/music/ movie/text, and press OK button to enter photo/music/movie/text operation basic same. - Page 26 Multimedia Set A to Set B. Start or stop the background music. Browse photo/music/moive/text list. Displays the current photo/music/moive/text information. Slow Forward. Step Forward. Counter clockwise turn pictures. Clockwise turn pictures. Zoom in Zoom out Zoom photo/moive fi rst, and then select the press OK key to enter mobile model, and then press▲/▼&◄...
- Page 27 Multimedia Precautions when using a USB device • MTP (Media Transfer Protocol) is not supported. • Max HDD capacity:500G. • This unit supports only USB Flash Drive with FAT32 format. This TV is not guaranteed the USB Flash Drive with other formats (such as FAT16 or NTFS). •...
- Page 28 Multimedia Video Codec support list O refer to support, X refer to NOT support TSUMV59XU/XE-Z1 File Extension Container Video Codec TSUMV59XUS/XES-Z1 Divx * .avi * .wmv, * .asf VC-1 Divx * .mp4 *.mov Motion JPEG (* .mov) * .mkv * .mpg,* .mpeg MPG,MPEG *.ts,*.trp,*.tp,*.m2ts MPEG2-TS...
- Page 29 VC1 format, need to get MPEG LA copyright if support for audio files with AAC format, need to get AAC copyright if support for video files with MPEG format, need to get MPEG LA copyright * Subject to change due to Lloyd's continuous improvement policy.
-
Page 30: Troubleshooting
Troubleshooting Problem Possible Solution No power • Make sure the power cord is properly connected to the LED TV AC power socket. • Make sure the AC power cord is properly connected to the wall outlet. • Make sure the DC power button is ON (Blue LED). •... - Page 31 Troubleshooting Problem Possible Solution Unit cannot be operated • External infl uences such as lightning or static electricity may cause improper operation. In this case, operate the unit after fi rst turning on the power of the LED TV and the AVC System, or unplug the AC cord for 1 to 2 minutes, then replug again.
-
Page 32: Specifi Cation
Altitude: 0 meter to 2,000 meters above sea level Temperature: -20°C ~ +60°C (at sea level) Humidity: 10% ~90% non-condensing Storage temperature Altitude: 0 meter to 3,790.3 meters above sea level Video systems PAL,SECAM * Subject to change due to Lloyd's continuous improvement policy.
