Nikkei NMP4 Instruction Manual

Mp4 player
Hide thumbs Also See for NMP4:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NMP4 and is the answer not in the manual?

Questions and answers

Related Manuals for Nikkei NMP4

Summary of Contents for Nikkei NMP4

  • Page 2 NIKKEI NMP4 MP4 PLAYER INSTRUCTION MANUAL DRAWINGS AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE...

  • Page 3: Table Of Contents

    Table of Contents Features……………………………………………………………………………………………………………3 Precautions ……………………………………………………………………………………………………..3 Warning……………………………………………………………………………………………………………3 Button & function…………………………………………………………………………………………….4 Main Menu………………………………………………………………………………………………………5 Music Mode …………………………………………………………………………………………………….5 Movie Mode ……………………………………………………………………………………………………7 Record Mode …………………………………………………………………………………………………..8 Voice Mode ……………………………………………………………………………………………………..8 FM Radio Mode ……………………………………………………………………………………………….9 Picture Mode …………………………………………………………………………………………………..10 System Setting …………………………………………………………………………………………………11 Text Mode …………..…………………………………………………………………………………………..12 Video Conversion Tool ……………………………………………………………………………………..12 Trouble Shooting ………………………………………………………………………………………..……14...

  • Page 4: Features

    Features ● 1.8-inch TFT display ● 128 x 160 pixels display resolution ● Earphone included ● Plays AVI (128x160), AMV video format files ● Plays MP3, WMA, WAV audio format files ● Picture browsing of JPEG format files ● Built in Micro-SD card slot, supports up to 16GB ●...

  • Page 5: Button & Function

    Button & Controls 1. Micro SD Card slot 2. ON/OFF power switch 3. VOL+ 4. VOL- 5. Enter menu and exit from sub-menu, confirm selection (under any status, hold [MENU] will enter main menu) 6. Last/ Backward 7. Next/Forward 8. Play/Pause、Power ON/ OFF the player 9.

  • Page 6: Main Menu

    Basic Operation Power on & Power off: Power On: Hold (play/stop) button for 3 seconds, the player will go to working condition. Power off: Hold (play/stop) button for 3 seconds, the player will be turned off. Note: when battery power is low, it will automatically power off. Adjust volume: With MP3 mode, AMV/AVI mode, Voice mode, press [VOL-] or [VOL+] to decrease / increase the volume one step, while hold [VOL-] or [VOL+] button will decrease/increase continuously.
  • Page 7 Press [MENU] to confirm selection and then press PLAY/STOP [>II] button to play selection and then press PLAY/STOP [>II] button to play selection and then press PLAY/STOP [>II] button to play the song. While music playing, press [MENU] button to enter sub the song.

  • Page 8: Movie Mode

    to A-B replay mode by swing [PRE] button in such status) Set how many times the A-B point replay Replay times Maximum is 10 times (1-10) Replay gap set replay time gap between every replay Exit Exit from sub-menu This device support Lyrics display. To fully display the contents of the song, you must make sure the name of the song under the music folder should be exactly the same one under LRC file.e.g You put a “song.mp3”...

  • Page 9: Record Mode

    Record Mode Press [MENU] button to select Record mode in main menu, then press [MENU] again enter into recording sub-menu. Local folder Indicate the folder of present recording file REC type: 32K BPS、64K BPS、128K BPS、256K BPS Exit Exit form sub-menu After setting, press [>II] to start recording.

  • Page 10: Fm Radio Mode

    Sub-menu while playing status: Repeat Refers to “repeat” in music mode Replay mode Refers to “replay” in music mode Exit Exit from sub-menu Sub-menu while stop status: Local folder Indicate the folder of present recording file Delete Delete recording song Delete All Delete all recording files exit...

  • Page 11: Picture Mode

    Delete All delete all saved channels; Auto Search Auto search FM channel Normal Band Frequencies from 87.5MHz---108MHz; Japan Band frequencies from76.5MHz---90MHz; Exit exit from FM sub-menu Auto search: Holding [PRE] button or [NEXT] button for two seconds will tune frequency upward or downward until a radio station is located then it stop automatically.

  • Page 12: System Setting

    SYS Setup Select [PRE] or [NEXT] button to select SYS Setup, then press [MENU] to confirm, Press [MENU] button again to enter sub-menu: Press [MENU] to edit recording time. Swing [NEXT] button and the digit of year will increase; swing [VOL+] button to edit next Record time digit, push [PRE] or [NEXT] button to adjust the digit.

  • Page 13: Text Mode

    TEXT Select [PRE] or [NEXT] button to select Text, then press [MENU] to confirm, Enter TEXT mode by pressing Mode button, then you can read and edit the article in the device. The device only can recognize the article in “txt.” Format. Press [MENU] button again to enter sub-menu: local folder choose the folder where picture is saved...
  • Page 14 4) Click to the Input file and choose the video which you need to convert. 5) Click to for settings. Choose the AMV and the resolution 160x120. 6) Click to for conversion.

  • Page 15: Trouble Shooting

    Trouble Shooting Check battery level. No power Recharge as per directions in User Manual Check that the file is in a compatible format Unable to locate or play files Check to see if the file is stored in a different directory. Check the volume level No music is heard Check the connection (earphone to the earphone jack)
