- Page 1 Net-Net 4250 SD ® SSM Installation Guide Release Version 1.0 Acme Packet, Inc. 71 Third Avenue Burlington, MA 01803 USA t 781-328-4400 f 781-425-5077 http://www.acmepacket.com Last Updated: December 8, 2006 Document Number: 400-0081-10...
- Page 2 Acme Packet, Inc. shall not be liable for any loss of profits, loss of use, loss of data, interruption of business, nor for indirect, special, incidental, consequential, or exemplary damages of any kind, arising in any way in connection with the Acme Packet software or hardware, third party software or hardware, or the documentation.
-
Page 3: About This Guide
H.323, MGCP/NCS and H.248; and multiple border points-interconnect, access network and data center. Established in August, 2000 by networking industry veterans, Acme Packet is a public company traded on the NASDAQ and headquartered in Burlington, MA. - Page 4 ABOUT THIS GUIDE 4 Net-Net 4250 SD SSM Installation Guide Version 1.0...
-
Page 5: Ssm Installation
Physical System After logically removing the Net-Net system from your network, three procedures Removal must first be completed before you can install the SSM in your Net-Net 4250 SD. These are: Disconnection of all media network, management network, alarm and console •... - Page 6 Disconnect all data cables from the Net-Net 4250 SD. Power and Ground Take care in removing power from the Net-Net 4250 SD. Refer to the Safety chapter Cabling Removal in the Net-Net System Hardware Installation Guide for complete safety guidelines.
- Page 7 SSM INSTALLATION Hardware Removal The rack ears which are used to secure the Net-Net 4250 SD to the equipment rack must be removed before you can open the chassis. For center-mount configurations: Remove the left rack ear by unscrewing the three screws.
-
Page 8: Left Side
ESD wrist strap or other comparable grounding system. Failure to do so could damage the SSM the Net-Net 4250 SD chassis. Unscrew the two countersunk screws on each side of the Net-Net 4250 SD that hold the chassis cover to the chassis. LEFT SIDE RIGHT SIDE Set these screws aside. - Page 9 Set the lid aside. SSM Installation Once the Net-Net 4250 SD chassis is open, SSM installation is straightforward. The SSM attaches electrically to the Net-Net 4250 SD motherboard by three board-to- board connectors. In addition, it is secured to the motherboard by four screws.
- Page 10 SSM INSTALLATION Note the region on the Net-Net 4250 SD motherboard where the SSM attaches. In the photograph below, the three SSM connectors are circled. The SSM plugs into place here. REAR FRONT SSM CONNECTORS POWER GRAPHIC SUPPLY DISPLAY Note the three board-to-board connectors in the following photograph. This photograph shows the bottom of the SSM.
-
Page 11: Post Installation
SSM. Screw the SSM to the chassis at four points with the supplied screws. Postinstallation After the SSM has been installed in the Net-Net 4250 SD, you can close the chassis and reinstall it in the equipment rack. Version 1.0... -
Page 12: Attaching The Lid
Secure the lid in place by repeating the opposite motion used for removing it. Push the lid downward and toward the front of the chassis in one sweeping motion. FRONT REAR 12 Net-Net 4250 SD SSM Installation Guide Version 1.0... -
Page 13: Installing The Chassis In The Rack
SSM INSTALLATION Re-screw the two countersunk screws on each side of the Net-Net 4250 SD to secure the chassis cover to the chassis. LEFT SIDE RIGHT SIDE Installing the Perform the reverse of the operations in the following sections of this document:... - Page 14 SSM INSTALLATION 14 Net-Net 4250 SD SSM Installation Guide Version 1.0...
