Summary of Contents for Azure Sport Boat
- Page 2 U.S. Coast Guard. Our goal at Azure is not only to build the best boats possible, but to build the safest. We hope that you feel we have achieved that goal once you have had the chance to use and enjoy your new boat.
-
Page 3: Table Of Contents
Drugs & Alcohol .......................10 Fuel system safety......................11 Lanyard stop switch ......................11 Hazardous conditions......................12 Water - swimming safety ....................12 Water - skiing safety ......................12 Caring for your Azure ....................13 Engine ...........................13 Cleaning-finish/waxing .....................14 Electrical system care .......................14 Repairing gel coat ......................14 Floor coverings .........................14... - Page 4 Hitch..........................21 Chains ..........................21 Backing a trailer........................ 21 Launching recommendations .................... 22 Loading your boat back on the trailer ................22 Azure Components & Systems ..................22 Electrical wiring system....................22 Batteries ..........................22 Electrical switches ......................23 Instruments........................23 Tachometer gauge ......................
-
Page 5: Introduction
You have made an excellent choice by selecting an Azure boat to enjoy during your leisure time! Azure “Is in the business of creating a dream come true for you and your family. Just like we say, “we build the boats that dreams are made of.” Your dream includes something more than just a well built boat. -
Page 6: Ownerʼs Packet
Always obey all applicable federal, state, and local laws! Insure your boat with a reputable insurance company. Azure has a permanent record of your boat, which is retained under its “Hull Identification Number” (HIN). Data regarding equipment and accessories, as well as dealer/shipping information is docu- mented. -
Page 7: State Registration
Coast Guard, local marina, or your dealer for information concerning these laws. SAFETY At Azure we are very concerned about the safety of all Azure boat owners and their families. That is why Azure is committed to building the safest boats in the marine industry. -
Page 8: Safety Gear & Equipment
NEVER OPERATE A BOAT WHILE UNDER THE INFLUENCE OF DRUGS OR ALCOHOL. Doing this is a Federal offense. Make sure only qualified drivers operate your boat. Keep your boat and equipment in safe condition. Inspect the boat, engine, safety equipment, and all boating gear regularly. -
Page 9: Safe Boating Practices
SAFE BOATING PRACTICES YOU are responsible for your own safety, the safety of your passengers, and the safety of fellow boaters. You are asked to follow (but are not limited to) the following safe boating practices: Drugs and alcohol Alcohol consumption and boating do not mix! Operating under the influence endangers the lives of your passengers and other water users. -
Page 10: Dangers, Warnings And Cautions
*This Basic Safe Boating Figure is intended be a used as a general guideline only. It does not exclude any other safety recommendations, laws, or procedures required by you as the owner of your boat. While your boatʼs floor plan maybe different from the model shown, the same safety precau- tions apply. -
Page 11: Fuel System Safety
The use of alcohol and/or drugs affects everyone in at least four possible ways that affect safe boat driving skills: Judgment, Coordination, Reaction Time, and Vision. Also, the influence of drugs and alcohol by passengers can be dangerous. Under the influence, passengers can fall overboard and risk injury and death. -
Page 12: Hazardous Conditions
If you are uncertain of water depths move slowly through the water! Azure can not be responsible for damage or personal injury that occurs while using your boat during hazardous boating conditions. Azure can not be responsible for damage resulting from tree stumps, sand bars, shallow waters, wave swells and the like. -
Page 13: Caring For Your Azure
If any information conflicts with informa- tion stated in the manufacturersʼ manuals, those manuals must take precedence. Also, some informa- tion in this section may not pertain to all Azure products and some items may be optional equipment. ENGINE Refer to the engine ownerʼs manual for recommended information about engine care and mainte-... -
Page 14: Cleaning-Finish/Waxing
Gelcoat will age or dull naturally. As the gelcoat begins to lose gloss from constant exposure to the natural environment and pollutants it will require some special attention to restore the original gloss and color. Please check with your Azure dealer for advice on a suitable wax for the region you use your boat in. -
Page 15: Furniture
Remember to remove any contaminants and clean vinyl immediately. Protect your vinyl from being ripped or torn. Mildew, mold, pinking, yellowing or other types of staining can occur if vinyl is not cared for. This type of damage is not covered under Azureʼs Lim- ited Warranty. -
Page 16: Canvas
Fantastic and Mr. Clean CANVAS Azureʼs canvas is made using high quality vinyl and the latest sewing techniques. The canvas is not completely leak proof. The seam holes in your canvas may stretch and leak over time. Products are available to seal seamed areas to help prevent leaks from occurring. -
Page 17: Storage
If you store your boat on a trailer, block the trailer wheels off the ground to avoid tire deterioration. To prepare engine for storage refer to your engine manual. Your Azure dealer will be able to offer “storage” recommendations. UNDERWAY WITH YOUR AZURE This section of the manual provides basic information for typical boating excursions. -
Page 18: Launching Your Boat
➢ EMERGENCY GEAR (Fire Extinguisher, bailer, paddle, anchor & line, signaling device, tool kit, etc..?) LAUNCHING YOUR BOAT Launch ramps are usually busy places. You should make all preparations for launching before ap- proaching the ramp. It is a good idea to watch others before you make your move. This way you can observe any specific wind and water changes on the ramp itself. -
Page 19: Loading Passengers & Gear
Please read, understand and follow the capacity plate information on your model of Azure boat. The maximum capacities plate is located near your console. -
Page 20: Boat Speed
The bow follows a smaller turning radius than the stern. Your Azure boat may be equipped with one of two steering systems: 1. Mechanical system: With this system the steering wheel connects to a cable which transfers movement to the engine. -
Page 21: Trailering Your Azure
IF TIDES ARE A CONSIDERATION BE SURE TO LEAVE SLACK IN THE LINES TO MAKE UP FOR THE RISE AND FALL OF THE WATER WHILE YOUR BOAT IS DOCKED. TRAILERING YOUR AZURE BOAT TRAILER LAWS Boat trailer laws vary from state to state. -
Page 22: Loading Your Boat Back On The Trailer
Please note that some equipment described in this section may be standard on some Azure models and optional or not available on other models. Check with your Azure dealer for the latest optional product information or if you have questions about your boatʼs equipment. -
Page 23: Electrical Switches
Azure dash. Your dash may be different depending on the model of Azure you own. However, the gauge descriptions to follow provide you with the basic use of all gauges used by Azure. Note that not all gauges listed are available for all Azure boat models. -
Page 24: Tachometer Gauge
Azure boats are equipped with a trim gauge, not all engines have a sending unit for this gauge. Please contact your Azure dealer for additional information. Most Azure boats are equipped with a trim gauge and in all cases this is a 2” diameter gauge. HOURMETER The hourmeter measures cumulative hours of engine operation. -
Page 25: Oil Pressure Gauge
Check oil level if pressure drops signifi- cantly and consult with your dealer as needed. Most Azure boats are NOT equipped with an oil pressure gauge. This gauge is usually only used with inboard/outboard applications and is gauge is a 2”... -
Page 26: Digital Depth/Fish Finder Graph
12 VOLT PLUG This plug is available on most, but not all Azure boat models. It can be used to operate accessories such as a cell phone, air pump, flashlight, ect. Please read your accessories ownerʼs manual before plugging anything into this plug. You can locate this plug on the dash of your Azure by gently lift- ing up the rubber tab used to cover and protect the plug. -
Page 27: Navigation Lights
STEERING SYSTEMS Azure boats are equipped with various steering systems. Some models have non-tilt mechanical steering, tilt mechanical steering, or tilt hydraulic steering. Note below a listing and brief description of each. Please read your steering systems ownerʼs manual for additional information concerning maintenance, use and safety. -
Page 28: Shift &Throttle Control System
2. Hydraulic system: With this steering system, the steering wheel movement pumps hydraulic fluid through lines to a cylinder which transfers movement to the engine rudder. Azure uses Sea Star for itʼs Hydraulic Steering System. This steering system makes it easier to control the boat because the steering wheel is easier to turn. -
Page 29: Livewell System
As you push UP or DOWN on the switch the gauge will move to reflect this change. Note that not every Azure is equipped with a “Trim Gauge”. Please contact your dealer before installing this feature to your boat. -
Page 30: Boarding Ladders
Properly dispose of rags used to wipe off fuel spillage. BOARDING LADDERS Azure has two basic types of boarding ladders, please note pictures and descriptions below: Stern Entry Boarding Ladder: This ladder is located on the starboard stern corner of the boat and comes as a standard feature on all stern entry Azure models. -
Page 31: Privacy Enclosures
This cupholder can be relocated on the boat to your desired location. It slips between the sofa bench bottom and backrest cushion as shown. This cupholder is standard on select Azure models. If your Azure does not come standard with this type of cupholder, it can be purchased through your Azure Marine dealer. -
Page 32: Fresh Water System
FRESH WATER SYSTEM Azure provides an optional fresh water system for select models. This manual and/or pressurized system provides fresh water from a tank that is located below the sink or at the stern of the boat. To operate this system, push the manual pump mounted by the sink for manual systems or utilize spray nozzles for pressurized systems. - Page 33 Service Notes...
- Page 34 Bennington Marine LLC Azure Boats 52936 Marina Drive Elkhart, Indiana 46514 574-970-2480...
