Summary of Contents for Danish Interpretation Systems CCS 7800
- Page 1 CCS 7800 Installation Manual Camera Control System CP 7801 Camera Control Package Version 1.5 User Manual Danish Interpretation Systems...
- Page 2 Danish Interpretation Systems Installation Manual Copyright © 2007/2010 DIS CP 7801 USER MANUAL - REV H.DOC 14-08-2013 No part of this publication may be reproduced or utilised in any form or by any means without permission in writing from the...
-
Page 3: Table Of Contents
Danish Interpretation Systems Installation Manual List of Contents Extron MSW Mini Switcher Series ....19 List of Contents ............3 Multiple cameras ........... 19 Extron ISS 506 Seamless Switcher ....20 Introduction .............. 4 CP 7801 Package ..........4 Changing of Wireless Channel of WR ..... 21 Product Description .......... -
Page 4: Extron Msw Mini Switcher Series
SW 7810 Camera Control Software • Camera System Control Unit with preloaded SW 7820 Camera Control Software The CP 7801 Camera Control Package is part of the CCS 7800 Camera Control System. Further products • Wireless Router... -
Page 5: Part List
Danish Interpretation Systems Installation Manual Part List iPod control (IPC) iPod Touch 16GB Product Description Product USB cable for iPod touch SW 7810 Software (Preloaded) Wireless Router (WR) Linksys wireless E2500 Cable, LAN, 2 m Power Supply, 12V, 1A System Control Unit (SCU) -
Page 6: Use With Sw 6000, Eca Application
Danish Interpretation Systems Installation Manual Use with SW 6000, ECA application Schematic Setting up the system 1. Connect the system as shown in above schematic ‘Single # Description Comment or picture Camera, ECA connection’, using the cables supplied. The RS 232 connector on the PC running the ECA shall be connected to COM1 on the SCU using the RS 232 cable plus the RS232 adapter. - Page 7 Danish Interpretation Systems Installation Manual 3. Insert command line parameter in the SW 6000 -CUI shortcut: -ALLMICOFF 4. Start the SW 6000 applications (CUA, CUI and ECA) 5. Turn on power to the Wireless Router, the Camera Controller and the Camera(s)
-
Page 8: Using The Ipod Control
Danish Interpretation Systems Installation Manual Using the iPod Control Turn on power to the iPod and select Wi-Fi Choose the: The Linksys has to be powered up and connected to the Camera Control Unit network ‘DIS CP 7801-xxx’ Start “CF iViewer” on the iPod. -
Page 9: Main Menu
Danish Interpretation Systems Installation Manual The Main Menu window will be shown and consist of the Main Menu following menus: Instant Camera Control Camera Presets Setup Setup System Save/Recall Layouts The “Instant Camera Control” is used for operating the Instant Camera Control cameras manual if desired. - Page 10 Danish Interpretation Systems Installation Manual ‘Select Seat’ sub page The screen is used to save the preset for each microphone. Camera Presets Setup How to save presets: 1. Turn on one microphone (the number will be shown in the “seat no.” field).
-
Page 11: After The System Is Setup
Danish Interpretation Systems Installation Manual No. of Cameras Setup System Select the number of cameras connected (1 to 4) Max. NOM to Overview Select the number of microphones which can be opened before the system switches to the overview picture (1 to 8) -
Page 12: Use With Cu 60Xx, Direct Connection
Danish Interpretation Systems Installation Manual If for any reason controlling of the camera(s) is needed during the meeting, the IPC and the WR shall not be switched Off. Use with CU 60xx, direct connection Schematic Setting up the system 15 Connect the system as shown in above schematic ‘Single... -
Page 13: Using The Ipod Control
Danish Interpretation Systems Installation Manual Using the iPod Control Turn on power to the iPod and select Wi-Fi Choose the: The Linksys has to be powered up and connected to the Camera Control Unit network ‘DIS CP 7801-xxx’ Start “CF iViewer” on the iPod. - Page 14 Danish Interpretation Systems Installation Manual The “Instant Camera Control” is used for operating the Instant Camera Control cameras manual if desired. Select which camera to operate using the four camera buttons. The camera can now be operated using the arrow buttons for UP/Down and Left/Right movement.
- Page 15 Danish Interpretation Systems Installation Manual ‘Select Seat’ sub page The screen is used to save the preset for each microphone. Camera Presets Setup How to save presets: 1. Assign seats. Please refer to the menu ‘Assign Seats’ later in this chapter 2.
- Page 16 Danish Interpretation Systems Installation Manual No. of Cameras Setup System Select the number of cameras connected (1 to 4) Max. NOM to Overview Select the number of microphones which can be opened before the system switches to the overview picture (1 to 8)
- Page 17 Danish Interpretation Systems Installation Manual This page is used to assign a seat number to each Assign Seats microphone unit. When connected to the CU, the icon in the top right corner shall shown connection (no red color and no warning sign).
-
Page 18: After The System Is Setup
Danish Interpretation Systems Installation Manual For changing or replacing a seat: Changing/Replacing a seat 1. Select “Seat Setup is OFF. Push to turn ON” 2. Select “no” to “Clear existing Seat data and reassign all seats?” 3. Activate a microphone. The number of the microphone is shown. - Page 19 Danish Interpretation Systems Installation Manual Multiple cameras If more than one camera is used a video switcher is needed. The CP 7801 supports control of the Extron ISS 506 Seamless Switcher and Extron MSW Mini Switcher Series. Any video switcher using ‘contact closure’...
- Page 20 Danish Interpretation Systems Installation Manual Extron ISS 506 Seamless Switcher This switcher is connected using LAN connection. The Switcher has to be set to use IP 192.168.10.111 Manual 01 19 78010...
- Page 21 Danish Interpretation Systems Installation Manual Changing of Wireless Channel of WR 28. Connect a PC to the Wireless Description Comment or picture Router using one of the four LAN ports and turn on power to the Linksys 29. Open Internet Explorer and...
- Page 22 Danish Interpretation Systems Installation Manual VISCA Control Cables configuration with Sony cameras Below is VISCA cables configuration for both RS-422 and RS-232 for Sony cameras. Manual 01 19 78010...
- Page 23 Danish Interpretation Systems Installation Manual Trouble shooting ‘Touch Screen to begin’ on iPod does not open the 1. Check ‘Settings/WI-FI’. The ‘DIS CP 7801- ‘Main Menu’ xxx. Shall be connected The camera does not move when controlling from 1. Check that the Visca cable from the camera the ‘Instant Camera Control’...
