www.tbsdtv.com
MOI DVB-S2 Streaming Box Quick Start Guide
V1.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOI DVB-S2 and is the answer not in the manual?

Questions and answers

Summary of Contents for TBS technologies MOI DVB-S2

  • Page 1 MOI DVB-S2 Streaming Box Quick Start Guide V1.0...

  • Page 2: Table Of Contents

    www.tbsdtv.com Contents 1. Overview 1.1. At A Glance 1.2. Specifications 1.3. System Requirements 1.4. Package 2. Hardware Connection 3. Software Installation and Configuration ( for Windows/ Linuxs/ Android/ iOS) 4. How To 4.1. Change IP Address on MOI 4.2. Upgrade The System 5.

  • Page 3: Overview

    1. Overview TBS MOI DVB-S2 Streaming TV box is a dual DVB-S2 TV tuner and dual CI slot Linux server for streaming satellite TV channels to the following client end devices within your wired or wireless network:  HDTV ...

  • Page 4: At A Glance

    www.tbsdtv.com 1.1. At A Glance Front:  Power: the red LED light is on when MOI is powered on.  Tuner A/B: the blue LED light indicates tuner A/B lock status.  CAM: two CI slots A/B for CAM modules insertion Back: ...

  • Page 5: Specifications

    www.tbsdtv.com  USB: USB connector for card reader, can be expended by USB Hub  MicroSD: for micro SD card insertion  LAN: for local network connection  RS232: for communication and debug print 1.2. Specifications Processor: Cortex TM-A8 1GHz RAM : 512MB DDR2 Storage: 256MB SLC NAND Flash, 1 SD card slot Ethernet: 10/100M Ethernet...

  • Page 6: System Requirements

    DLNA certificated TV, PC with Windows or Linux system, Android tablet PC, Android smartphone, iPhone, iPad, iPod and Sony Playstation 3 etc. 1.4. Package Includes  TBS MOI DVB-S2 Streaming Box  RJ45 Network Cable  RS232 to USB Cable (Optional) ...

  • Page 7: How To

    www.tbsdtv.com 4. How To: 4.1. change IP address of MOI The default IP address of MOI is 192.168.1.188, if this IP is not in your network IP range, you need to either change MOI IP to your network IP range or change your network IP range to 192.168.1.XXX to make MOI accessible.
  • Page 8 www.tbsdtv.com Click “IP Setting”, Here you can enable or disable “DHCP”: Enable DHCP (It’s not recommended unless you know exactly how to find your MOI IP later). After you select “Enable”, you can click “save” directly, then MOI will receive a random IP address from the Ethernet server, since it is dynamic, the realtime IP can’t be displayed, if you want to check the new IP address, you will need to access the DHCP of your router settings, there you can find MOI by looking for it’s Mac address.
  • Page 9 www.tbsdtv.com Disable DHCP(it’s strongly recommended you check disable DHCP) You can change the IP manually, simply change the”192.168.1.188” to any IP address which is included in your Ethernet IP range. For example, if your previous network router IP range is 192. 168.15.xxx and you want to keep using that IP range for your router and computers in the network, you can simply change MOI IP to the IP range of 192.168.15.xxx ,set subnet Mask to what you’re currently using(normally 255.255.255.0) and set Gat Way to your router IP address.
  • Page 10 www.tbsdtv.com MOI Settings , you may click “EnterTVheadend” and you can make TVHeadend To set up TVHeadend automatically start when MOI is powered on by checking the “Auto Start TVheadend When Power On MOI” checkbox. You can also set up MOI box date & time here. Please note: your browser need to allow pop-ups to enter TVHeadend setting page.

  • Page 11: Upgrade The System

    www.tbsdtv.com 4.2. Upgrade The System To upgrade the system, you need a formatted FAT32 file system micro SD card. Download the latest upgrade package from the download section of tbsdtv.com and copy to the micro SD card, insert the micro SD card into MOI, power on and then wait about 5 minutes until the upgrade is completed.
  • Page 12 www.tbsdtv.com 4.3. Set up RS232 connection Connect MOI with a serial port cable to your PC. Run Tera Term software to configure, as it is shown in the picture below:...

  • Page 13: Declaration

    www.tbsdtv.com 5. Declaration  The user manual includes all the information of safe and correct operation instruction. To avoid accident and product damaged, please make sure read it carefully before using the product.  Please keep the product away from high temperature, humid and dusty environment. ...
