Push MIN MAX key to cycle through the MAX, MIN and AVG readings. If
an overload is recorded, the averaging function is stopped. In this mode,
press the HOLD key to stop the recording of readings, all values are held,
press again to restart recording.
To prevent accidental loss of MIN, MAX and AVG data, this mode can
only be cancelled by pressing and holding the MIN MAX key for 2 seconds.
All recorded readings are erased.
7. REL Relative mode (only Main display)
Press the REL key to enter the Relative mode, zero the display, and store
the displayed Reading as a reference value. REL is shown on the display.
Press REL key again to exit the relative mode. The relative reference value
can also be entered by the user. (See "SET mode" later in this manual.)
When the desired Relative value has been entered, press REL key to enter
the Relative mode and then press SET key use the entered Relative value as
a reference value. Press REL key again to exit the relative mode. In the
Relative mode, the value (can not >±3000.0 counts) shown on the LCD is
always the difference between the stored reference and the present reading.
8. Sec. Minu. Selecting the Elapsed Time scale
Press this key to display the elapsed time on the third display in either hours
and minutes or minutes and seconds. When the thermometer is turned on, it
is set to seconds. To change the time scale, press sec. Minus. key. Maxi-
mum elapsed time reading is 100 hours. If 100 hours is exceeded, the
elapsed time resets to zero.
Press the SET key to enter Relative value SET mode (Press ENTER key
to skip setting relative value). = = = =.= is displayed on the main display.
The Relative value is entered via overlay numbers, press overlay ENTER
key to store the relative value, and advance to elapsed time set mode.
Elapsed Time set mode, (Press ENTER key to skip Elapsed Time set
mode) =.= = = : = = is displayed in second and third display. Time
(hours, minutes, seconds) value is entered via overlay numbers, press
overlay
ENTER key to store Time value. Elapsed Time starts from set time
value.
Hi Limit value set mode,
is displayed (Press ENTER key to skip
Hi Limit value set mode), = = = =.= is displayed in main display, Hi
Limit value is entered via overlay numbers, then press ENTER key to
store the Hi Limit value. = = = =.= is displayed in main display, Lo Limit
value is entered via overlay numbers, then press overlay ENTER key to
store the Lo Limit value and exit SET mode.
When the thermometer is turned on it uses the Relative value and Hi/Lo
Limits values that were entered when thermometer was last in use.
10.T1/T2 T1-T2 second display Input Selection
The input selection indicates which input is selected for second display; T1
thermocouple, T2 thermocouple or the difference between the two thermo-
couples (T1-T2). When the thermometer is turned on, it is set to T2 input.
To select a different type of thermocouple use the K/J button.
11.K/J T2 Thermocouple type select (second display)
The K/J button for T2 input selects K-type or J-type thermocouple as input,
when the second display has T2 shown. When the thermometer is turned on,
it is set to the type selected when the thermometer was last turned off.
12.Hi/Lo Limits mode (only Main display)
Press Hi/Lo Limits key to enter the Hi/Lo Limits comparative mode.
displayed. When the input temperature value exceeds the Hi or Lo Limit
value, the beeper emits a continuous or pulse tone. Press Hi/Lo Limits key
again to exit the Hi/Lo Limits mode.
It is the policy of OMEGA Engineering, Inc. to comply with all worldwide safety and EMC/EMI
regulations that apply. OMEGA is constantly pursuing certification of its products to the
European New Approach Directives. OMEGA will add the CE mark to every appropriate device
upon certification.
The information contained in this document is believed to be correct, but OMEGA accepts no
liability for any errors it contains, and reserves the right to alter specifications without notice.
WARNING: These products are not designed for use in, and should not be used for, human
applications.
OPERATOR MAINTENANCE
WARNING
To avoid possible electrical shock, disconnect the thermocouple connectors
from the thermometer before removing the cover.
Battery Replacement
1. Power is supplied by 4pcs 1.5V (SIZE AAA) R03P.
2. The "
" appears on the LCD display when replacement is needed. To
replace battery remove screw from back of meter and lift off the battery
cover.
3. Remove the battery from battery contacts and replace.
4. When not in use for long periods the batteries should be removed.
5. Do not ations with high temperatures, or high humidity.
Cleaning
Periodically wipe the case with a damp cloth and detergent, do not use abra -
sives or solvents.
®
