Page 1: Copyright Statement
All the photos and product specifications mentioned in this guide are for references only. As the upgrade of software and hardware, there will be changes. And if there are changes, Tenda is not responsible for informing in advance. If you want to know more about our product... -
Page 2: Switch Features
Gigabit terminals such as PC, as well as Uplink ports to connect backbone network. You can replace the 10/100Mbps switch with the TEG1016G/TEG1024G to resolve the bottleneck issues of server and terminal connectivity. Meanwhile, it can be used as main switch to connect the Gigabit LAN of enterprises or Internet Cafés, and greatly... -
Page 3: Package Contents
Supports IEEE802.3x flow control full-duplex, backpressure flow control for half-duplex. Provides 16/24 Gigabit self-adaptive RJ-45 ports, supports 802.3 NWay Auto-negotiation. Each RJ-45 port supports Auto-MDI/MDIX function. Supports MAC address auto-learning and aging function. Adopts store- and- forward switching method. ... -
Page 4: Front Panel And Rear Panel Specifications
1.3 Front Panel and Rear Panel Specifications On the front panel, there are 16/24 1000Mbps RJ45 ports and LED indicators as well as 1 power indicator. Front panel view of the TEG1024G Switch On the rear panel there are 1 AC power port and the matched power supply mark. -
Page 5: Installation Instructions
LED indicators of the TEG1024G Switch Please refer to the list below for the LED indicator definition. LED Indicator Status Description Always ON Indicates the Switch is powerd on POWER Indicates the Switch is powerd off 1000Mbps The Switch connects to the other devices at 1000Mbps speed. -
Page 6: Installation Methods
The power supply used should match the required power specification of the switch. 2.2 Installation methods TEG1016G/TEG1024G switch can be installed to desktop or standard 19-inch rack 1. Install the switch to the desktop. Install the 4 included foot pads to the corresponding position at the... - Page 7 Install the foot pads to the bottom of the Switch 2. Install the Switch to the standard 19-inch rack. Please follow the steps below: Make sure the rack is stable. Fix the 2 delivery-attached mounting ears on both sides of the Switch with the matched screws.
-
Page 8: Application Example
2.3 Application example With 16/24 RJ-45 ports, TEG1016G/TEG1024G switch can be connected to devices such as PCs and notebook computers. The common method to access the internet... -
Page 9: Product Specification
3. Product Specification Features Standard IEEE802.3 IEEE802.3u IEEE802.3ab IEEE802.3x Protocol CSMA/CD Ethernet Data Transmission Gigabit Ethernet: 2000Mbps (Full-duplex) Rate Fast Ethernet: 100Mbps (Half-duplex) 200Mbps (Full-duplex) Topological Structure Star Network Cables 10Base-T:Cat.3 UTP or above(100m) 100Base-TX: Cat.5 UTP /STP(100m) 1000Base-T: Cat.5e UTP/STP or above(100m) Port Quantity 16/24 10/100/1000Mbps RJ-45 ports... -
Page 10: Fcc Statement
Operating Temperature 0℃-40℃ Storage Temperature -40℃-70℃ Storage Humidity 10%～90%RH (non- condensing) Operating Humidity 5%～90%RH (non- condensing) Dissipation method FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 11 Tel: +86 (755) 2344 2820 Skype: tendasz MSN: tendasz@hotmail.com Email: support@tenda.com.cn Headquarter Shenzhen: Add: Tenda Industrial Zone,No.34-1 Shilong Road, ShiyanTown, Baoan District, Shenzhen, China. 518108 Tel:(86)755-27657180 Fax: (86)755-27657178 Email: sales@tenda.com.cn Technical Support: support@tenda.com.cn...
