- Page 1 Conrad-Johnson Owner’s Manual CA200 Control Amplifier conrad-johnson It just sounds right.
- Page 2 Please take a few minutes to read the manual to better understand the features and capabilities of your CA200. Note that this unit is phase inverting. See the section enti- tled “Getting The Most From Your CA200" for details on correct hookup in your system.
- Page 3 Warranty For Conrad-Johnson Components Conrad-Johnson Design, Inc. will provide service under warranty to the original owner on products sold new in the United States for the lesser period of three years from the date of purchase by the origi- nal purchaser, or five years from the date of shipment to the au- thorized conrad-johnson dealer.
- Page 4 Service Department conrad-johnson design, inc. 2733 Merrilee Drive Fairfax, VA 22031 The conrad-johnson service department can also be reached by e- mail at service@conradjohnson.com, by phone at 703-698-8581, or by fax at 703-560-5360. Service If your conrad-johnson audio component requires service, repack it using the original box and packing material and ship to the Service Department address above.
-
Page 5: Electromagnetic Interference (Emi)
+ 5/- 10% of the nominal rated voltage. Electromagnetic Interference (EMI) Considerable care has been taken in the design of the CA200 to minimize its susceptibility to radio frequency interference and other forms of EMI. Choice of materials, physical layout, grounding prac-... - Page 6 Physical location and cable “dress” can be an important factor in minimizing hum pickup. The installation should situate the CA200 well away from sources (CD player, tuner, etc.) and power (ac mains) cords should be dressed to remain at least 4" (100mm) away from input/output cables.
- Page 7 We recommend the use of an amplifier with an in- put impedance of 20k ohms or higher. The Pre Out is phase cor- rect. See the section on “Getting the most out of your CA200" for an explanation.
- Page 8 With the speakers connected out of phase, the voice will be diffuse, with no identifi- able source. Relative phase may be reversed by switching the “+” and “-“ connections at one speaker only. CA200 Owner’s Manual...
- Page 9 <mute>: The mute button performs two functions – to mute the output when listening, and also to switch the CA200 on and off. To turn the CA200 on or off, press and hold the mute button for two seconds. When on, pressing the mute button will silence the preamplifier main outputs, and set the level display to zero on both channels.
-
Page 10: Remote Control
Remote Control All operations of the CA200 can be controlled by the wireless re- mote unit. MUTE: Pressing the mute button will cause the main outputs to mute and the level display to be zero. Pressing it again will restore the last level setting. -
Page 11: Absolute Phase
This will be the case if the number of phase inver- sions is even (or zero). The CA200 is phase inverting. If your system has an odd number of inversions, (for example, if the CA200 is the only phase inverting unit in the chain) then you must add one phase inversion. - Page 12 The warm up period can be expected to last about half an hour. Questions: If you have questions about the installation or function of your CA200 do not hesitate to call Customer Service at (703) 698-8581. CA200 Owner’s Manual...
- Page 13 Net Weight: 38 lb net Fuses There are 8 fuses in the CA200. One is the ac power line (mains) fuse. It is located in a fuse holder built into the IEC main power cord receptacle on the back of the amplifier. There are four fuses for the main DC power supplies (two for each channel).
