GPS Navigator

User Manual

R01
May 2016
Trademarks
All brand and product names are trademarks or registered trademarks of Maka GPS Technologies Group. In association
with Maka GPS Technologies Private Limited (Singapore), Maka GPS Technologies Sdn. Bhd. (Malaysia), Maka
Technologies Group (H.K.) Limited.
Page 1
© 2016 Maka Technologies Group. All Rights Reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pilot S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marbella Pilot S

Summary of Contents for Marbella Pilot S

  • Page 1: User Manual

    GPS Navigator User Manual May 2016 Trademarks All brand and product names are trademarks or registered trademarks of Maka GPS Technologies Group. In association with Maka GPS Technologies Private Limited (Singapore), Maka GPS Technologies Sdn. Bhd. (Malaysia), Maka Technologies Group (H.K.) Limited. Page 1 ©...
  • Page 2 lease read this manual before you start using this device Thanks for purchasing our product. Please read this instruction manual carefully and completely before using the product. The information in this manual has been verified for its accuracy. But no liability will be applied for the correctness of mapping data of navigation, technical and/or editorial interpretation or illustration, or the printing and translation of this manual, nor liable for any consequence or incidental damages caused by using this manual.
  • Page 3 General tips for GPS application The following content are the instructions for GPS device application and operation. Please read this instruction manual carefully and completely before using the product. Each GPS device requires stable satellite signals for GPS positioning. Hence, it is important to acquired satellite signals before the use of the GPS device.
  • Page 4 Features:  5.0inch LCD TFT display with touch screen for control and input  Professional portable navigation system, UI design for mobile application  Most popular Windows OS CE 6.0, World class CPU  MicroSD card (Not included in the package) of extensible capacity for mapping data, MP4 video, MP3 music, Photo, and Personal files ...
  • Page 5  Please install the device in a right (appropriate position) way to avoid driver's sight and airbag to be hindered. Marbella GPS will not be liable or hold any responsibility if any property or loss caused by mistakes of mounting or installing of the device.
  • Page 6 Illustrations on screen display: System UI In this interface, touch the screen or the small icon eg. to enter the specific function. Secondary UI In this interface, click the displayed icons on the screen to enter the relevant functions. To return back to previous page, click on the icon to return.
  • Page 7 Note: A new battery will reach its best performance after number cycles of charging and discharging. If the device is not used for long time, it is better to charge it to full capacity every 2 or 3 months during storage. Charger Application: AC Charger (Not included in the package): Take out the AC charger, plug it into the wall outlet with AC 220V(100V~240V), then plug in the AC jack into the...
  • Page 8 Waking -up from the sleeping When in sleeping mode, a short press on the power-on button of the device will wake up the system. Note: When in sleeping mode, all the procedure in operation will pause but will back to normal status after waking up. GPS Info Signal check through UI for reset GPS Signal and recapture of Data On this UI, click...
  • Page 9 Music – click on the icon to select the file to play Next – Selected the file you wish to play and click on it Next – Music player start playing the file you selected 1. Play file list 2. Current file played Volume 3.
  • Page 10 1. Select the file of the movie play to enter into the video player and auto start play as interface below Photo – click on the icon to select the file to view Next – File view on the selected one 1.
  • Page 11 Next – Select file to be open for read through internal memory or Sd card. Only icon will be readable. 1. Ebook List Change color text/background 2. Scroll Up Click on icon when text you wish to add to bookmark list 3.
  • Page 12 Note: Only empty station frequency pair (device and vehicle radio device) will trigger the sound to be send out from the stereo speaker. Icon will turn to white when activate. Bluetooth The Bluetooth function is used for communication purpose. After the device is connected to a mobile phone with Bluetooth capability, you can operate the mobile phone functions on this system.
  • Page 13 Next – You can modify your device name, Pin, set Auto-connect and Auto-answer within your convenience and preference  Modify the name – Click on to enter into next screen. Set the name of your preference and click OK to save and exit ...
  • Page 14 **** Note : Once synchronize is press, phone will be prompt to allow or cancel synchronize. All contact after synchronize is in number sequence once allowed. 2. Press to toggle to next or previous page 3. Selection of number and dialing can be done from here. Call history - Click on to enter to another screen as mention below interface 1.
  • Page 15 This is for system setting to change default setting of the system to your personal preference. In this UI, press to enter and screen shown on the interface as below Volume – This function is to control your GPS device tapping volume when pressing on and icon. 1.
  • Page 16 1. Press on icon to enter into volume control as interface shown below 2. Press to control brightness of the device to comfortable viewing 3. Press either to select the time of the screen Auto OFF mode (screen dimmer) Selection of (10s, 30s, 1min, 2min, 3min, Always ON) provided for selection. Note : If time is set to dim off the screen, tap on the screen once to brighten back.
  • Page 17 1. Click on the Navi Path icon to enter next interface for path setting 2. Click on to enter next path setting (Navigation Software List) as interface 3. Click on the file (internal memory usage) or (Sd card usage) to enter to next interface 4.
  • Page 18 7. Click on if software is require to be auto start instead of pressing in the main interface. Uncheck will go to the UI every time the device is boot up USB - You may select whether to use the device for “Mass Storage” (works like an external memory stick), or to “ACTIVESYNC”...
  • Page 19 3. Select the GMT accordingly to your region by pressing to search and set Calibration – This function help you to calibrate your screen alignment when the screen touch alignment is 1. Press icon to enter into next interface of the calibration to start. Before entering, you are prompt to accept YES / NO to start calibrate 2.
  • Page 20 TPMS function is there is a device purchase and installed 2. For TPMS function refer to the quick guide for more information on usage AV-IN (Need to be equipped with camera or any AV output device such as Marbella Reverse Camera) Car-backing Rear View Function (Optional Reverse Camera) This function is a fully automatic function.
  • Page 21 Video Input Function This device supports the video input function.  Plug in the video cable in the AV-Input on the side of the device.  The device will detect automatically when there are video signals, and will automatically switch the current function to the video display state.

  • Page 22: Troubleshooting

    No power on Battery drained Please refer to the instruction of battery charging in this manual, only consider to use Marbella charger to charge our device. Faulty Unit The screen freeze or stays Press on the Reset Button at the on the screen for long time.
  • Page 23 Service Location Local Service Centre - Singapore Service Location in Singapore Maka GPS Technologies Private Limited 2 Alexandra Road Unit #02-03, Delta House Singapore 159919 Tel: (65) 6276 0889 Fax: (65) 6270 7123 24Hrs Hotline (65) 6100 1239 Opening Hours: 9am – 6:30pm (Monday to Friday) Close 12pm –...
