Summary of Contents for Powerlink PL-APN
-
Page 1: Quick Installation Guide
POWERLINK PL-APN High Power 802.11bgn AP Router Quick Installation Guide Part I: External Installation Direction Package Content AP Router DC 12V Power Adapter Antenna PoE DC Injector Paper QIG Manual/QIG CD www.premiertek.com... - Page 2 POWERLINK PL-APN High Power 802.11bgn AP Router AP Router Connection Before installing the router, connect your PC to the internet through your broadband service. (If there is any problem, contact your ISP.)Then proceed through the following steps. Turn off your PC(s), cable/ ADSL modem and the router.
- Page 3 POWERLINK PL-APN High Power 802.11bgn AP Router Turn on your PC(s) and the cable/ADSL modem. The front LED indicator www.premiertek.com...
- Page 4 POWERLINK PL-APN High Power 802.11bgn AP Router AP Router configuration The AP Router is delivered with the following factory default parameters on the Ethernet LAN interfaces. Default IP Address: 192.168.1.254 Default IP subnet mask: 255.255.255.0 Web login User Name: <empty>...
- Page 5 POWERLINK PL-APN High Power 802.11bgn AP Router PoE DC Injector Configuration POE means Power over Ethernet, usually used with Wireless Device. You can use it to integrate the power and the Ethernet then connected with the RJ45 cable. With POE, you can bring the power and Ethernet with long distance as far as the length of RJ45 cable.
- Page 6 POWERLINK PL-APN High Power 802.11bgn AP Router Part II: Internal Web Management AP Model Setup (ADSL) 1、 Install the antenna & power adapter, and then connect the LAN cable with LAN port of this equipment. Another side of cable line connects with network card of computer. Waiting for booting around 20 seconds.
- Page 7 POWERLINK PL-APN High Power 802.11bgn AP Router 1. In Operation Mode, select Gateway and press Next>> 2. In Time Zone Setting, if you don’t need any change, please press Next>> www.premiertek.com...
- Page 8 POWERLINK PL-APN High Power 802.11bgn AP Router 3. In LAN Interface Setup, you may change the setting of IP address, DHCP and etc. then press Next>> 4. In WAN Interface Setup, select PPPoE for your connection of WAN Access Type and enter User Name &...
- Page 9 POWERLINK PL-APN High Power 802.11bgn AP Router 6. In Wireless Security, select your setup of wireless security (WEP, WPA) and press Finished to reboot around 20 seconds. www.premiertek.com...
- Page 10 POWERLINK PL-APN High Power 802.11bgn AP Router Note: You have to connect ADSL cable with WAN port of this equipment. ============================================================= AP Model Setup (IP Share) 1、 Install the antenna & power adapter, and then connect the LAN cable with LAN port of this equipment.
- Page 11 POWERLINK PL-APN High Power 802.11bgn AP Router 1. In Operation Mode, select Bridge and press Next>> www.premiertek.com...
- Page 12 POWERLINK PL-APN High Power 802.11bgn AP Router 2. In Time Zone Setting, if you don’t need any change, please press Next>> www.premiertek.com...
- Page 13 POWERLINK PL-APN High Power 802.11bgn AP Router 3. In LAN Interface Setup, you may change the setting of IP address, DHCP and etc. then press Next>> 4.In WAN Interface Setup, select DHCP Client for your connection of WAN Access Type and press Next>>...
- Page 14 POWERLINK PL-APN High Power 802.11bgn AP Router 5. In Wireless Basic Setting, select AP for your Mode and change your SSID setup, then press Next>> 6. In Wireless Security, select your setup of wireless security (WEP, WPA) and press Finished to reboot around 20 seconds.
- Page 15 POWERLINK PL-APN High Power 802.11bgn AP Router Select the TCP/IP Settings from left side of setup frame and choice LAN Interface. Then choosing Disable from DHCP and press Apply Changes to reboot around 20 seconds to complete the setup. Note: Please connect cable line with LAN port when you use this equipment to connect IP Share.
