- Page 1 Installation Manual AI-VC-101, -102 Video Converter Document # 540116 a DeCrane Aircraft Company 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
-
Page 2: Document Revision History
Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. Document # 540116, Rev. B, 09/2001... -
Page 3: Table Of Contents
Audio International, Inc. AI-VC-101, -102 Installation Manual Table of Contents Section Description Page General Information ...... -
Page 4: General Information
Contact your AI representative for details. Application Introduction The AI-VC-101, -102 provides the needed signal to convert SECAM, PAL, MESECAM, and NTSC standard video inputs into an NTSC standard output signal of 3.58. The unit is an active unit that requires only power and ground connections. -
Page 5: Introduction
• Environmental conditions (temperature, humidity, etc.) • Length of cable runs 3.1.2 The AI-VC-101, -102 shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. -
Page 6: Cautions & Warnings
Audio International, Inc. AI-VC-101, -102 Installation Manual Cautions and Warnings 3.3.1 It is important to do a pin-to-pin power and ground check on all connectors. Ensure that power and ground are applied only where specified. Damage to the unit may result if power or ground is applied to the wrong points. -
Page 7: Physical Characteristics
3.6.1 Electrical Specifications: Electrical Power 290mA @ +28 VDC 3.6.2 The AI-VC-101, -102 has two BNC connector locations on the rear of the unit. BNC 1 is designated as video input; BNC 2 is designated as video output. 3.6.3 The AI-VC-101, -102 requires one (1) 9-pin connector (Positronic connector for AI-VC-101, and D-subminiature for AI-VC-102). -
Page 8: Pinout Assignments And Descriptions
Post-Installation Test 2.9.1 Load the video source with selected material. With the aircraft and video power “ON”, apply power to the AI-VC-101, -102. 2.9.2 Verify that the selected material has been converted and may be viewed on the appropriate screen. -
Page 9: Reference Drawings
Audio International, Inc. AI-VC-101, -102 Installation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the AI-VC-101, -102. Document # 540116, Rev. B, 09/2001 Page 8 of 9... - Page 10 Audio International, Inc. AI-VC-101, -102 Installation Manual Document # 540116, Rev. B, 09/2001 Page 9 of 9...
