Page 3
• The materials in this document are for information use only and are subject to change without notice. While reasonable efforts have been made in the preparation of this document, to assure its accuracy, Seyeon Tech. assumes no liability resulting from errors or omissions in this document; or from the use of the information contained herein.
MS Internet Explorer or Netscape Communicator. There is no need other specific software to view real-time live images over the Internet. FW-3170 server is state-of-the art device and leads new generation of monitoring and security solution.
FW-3170 User’s Manual Part 1 1.3. Technical Specification of FW-315 Model Name FW-3170 32bit Embedded CPU Flash 8Mbytes /SDRAM: 128Mbytes Hardware Linux version 2.6.14 operating system Battery backed up real-time clock Video Motion JPEG compression H.264 NTSC: 704x480,352x240,176x112 Resolution PAL: 704x576,352x288,176x144...
Page 6
FW-3170 User’s Manual Part 1 PWR Consumption DC 12Volt 500 mA Temperature: 32° ~ 122°F (0° ~ 50°C) Operating Environment Humidity: 20 ~ 80% RH(non-condensing) Console cable for system set up Test LAN cable Accessories CD for User Guide, Installation wizard...
FW-3170 User’s Manual Part 1 1.4. FW-3170 Packing List FW-3170’s packing box includes the following items. FW-3170 Power Supply Unit (Power Cable & SMPS DC12V 0.8A Adapter) Direct Cable CD (User’s Manual, Installation wizard, Picture, etc) Table 2 : FW-3170 Packing List Please check all the listed items are included in your package.
RED light – It blinks RED when data is being transmitted on the LAN(Tx/Rx) LED connected LAN port (RED/GREEN) GREEN light – It blinks GREEN only when LAN port is connected without data transmission. Table 3 : FW-3170 Front Panel Description 4041-00 Seyeon Tech Co., Ltd...
DI (SENSOR) Signal input ports for sensor and contact. DO (ALARM) Signal output ports for alarm and light. Table 4 : FW-3170 Rear Panel Description 3. FW-3170 H/W installation and basic setup 3.1. Before installation, Read carefully User’s Manual Check-out if the power source is stable or not at the environment.
Following steps show the physical installation process for FW-3170. Install CCTV cameras at each required position. Connect BNC cable between CCTV camera’s V-out and FW-3170’s V-in. Connect a LAN cable at FW-3170 in your local network. Connect the power cable at FW-3170.
