Summary of Contents for Airtronic LT-700
- Page 1 LT-700 Stationary Terminal Operating Manual...
- Page 2 LT-700 Stationary Terminal Operating Manual...
- Page 3 We don’t deliver just our mobile Data Capturing Devices with Standard Software... but also develop to customers specific • Applications for this Devices • PC Applications • Hardware and advise you on • Creating concepts for mobile and stationary data collection •...
-
Page 4: Table Of Contents
Designations ................4 Start Page................5 CONFIGURATIONS MANAGER..........6 SERVER MENU....................7 WEB-APPLICATION-SERVER .................8 MDE-SERVER....................9 DNC-SERVER....................10 NETWORK MENU....................11 LT-700 Terminal LAN Settings ..............11 LT-700 Router Administration ..............12 Login ......................13 Status ......................14 System ......................15 Network.......................16 Logout ......................16 Factory Default....................17 Factory Default Settings ................17 Resetting to Factory Default State ...............18... - Page 5 Clear Data Port Buffer ...................25 Status Query ....................26 Return Error/Message ...................26 Return Status ....................27 Firmware Update of the LT-700 .......... 28 By means of Firmware Image from SD Card ..........28 Default Port Configuration..........29 Eliminating Errors ............... 30 Technical Data ..............31...
-
Page 6: Connectors
Connectors ______________________________________________________________ Connectors ETHERNET USB USB DC_IN LAN0(WAN) LAN1 INPUT/OUTPUT 12V-24V ETHERNET LAN0(WAN) LAN/WAN ETHERNET LAN1 USB A1/A2 Connector for external devices with USB Interface (e.g. barcode scanner) USB B USB Host Interface MDE INPUT/OUTPUT RS-232 for connection of a MDE device RS-232 for connection of a DNC Machine DC_IN 12V-24 V Power Supply... -
Page 7: Designations
Designations_____________________________________________________________ Designations LT-700 is the name for the entire device, containing the LT-700 Terminal and the LT-700 Router. LT-700 Router consists essentially of the WIZnet module and is part of the LT-700. LT-700 Terminal essentially consists of the Linux computer and is part of the LT-700. -
Page 8: Start Page
CONFIGURATIONS MANAGER _____________________________________________ Start Page After a cold start of the LT-700, the web page, which is specified in the WEB APPLICATION SERVER under URL, is displayed. By default, this is the page https://www.aitronic.de/de/impressum: Startseite By holding down the key and pressing key F1 the CONFIGURTAIONS MANAGERs login screen is called. -
Page 9: Configurations Manager
CONFIGURATIONS MANAGER _____________________________________________ CONFIGURATIONS MANAGER The buttons at the bottom of the CONFIGURATION MANAGER are assigned by their respective position to the function keys F1 ... F5 which are located below the display. On the following login page, for example, the following function keys can be used as an alternative to the buttons: START LOGIN... -
Page 10: Server Menu
CONFIGURATIONS MANAGER _____________________________________________ SERVER MENU SERVER MENU <back Return to the Menu Main Page Calling page WEB-APPLICATION-SERVER Calling page DNC-SERVER Calling page MDE-SERVER Connections to a web server, which determines the user interface of the device, to a DNC server serving the communication of a serial interface and to an MDE server, which is responsible for the storage and analysis of MDA data, can be established. -
Page 11: Web-Application-Server
CONFIGURATIONS MANAGER _____________________________________________ WEB-APPLICATION-SERVER WEB-APPLICATION-SERVER Active ai-browser will be started when booting the system Protocol Connection Protocol Host IP Port Host Port Path Path and start of web page User User Passw Password Debug Log information: stdout Output on the standard console Output to file /var/log/aiBrowser.log file no debug output... -
Page 12: Mde-Server
CONFIGURATIONS MANAGER _____________________________________________ MDE-SERVER MDE-SERVER Active ai-mde will be started when booting the system Format Output format Host IP Port Host Port Spool-Dir Path and name of spool file Debug Log information: stdout Output on the standard console Output to file /var/log/aiMDE.log file no debug output none... -
Page 13: Dnc-Server
CONFIGURATIONS MANAGER _____________________________________________ DNC-SERVER DNC-SERVER Active ai- dnc will be started when booting the system. Host IP Port Host Port Debug Log information: stdout Output on the standard console Output to file /var/log/aiDNC.log file no debug output none <back Return to page SERVER MENU <save>... -
Page 14: Network Menu
LT-700 Terminal LAN Settings <back Return to page NETWORK MENU <save> Save settings DHCP Enabling DHCP, the DHCP server of the LT-700 router provides the necessary settings IP Address of LT-700 Terminal Netmask Netmask of LT-700 Terminal Gateway Gateway of LT-700 Terminal... -
Page 15: Lt-700 Router Administration
CONFIGURATIONS MANAGER _____________________________________________ LT-700 Router Administration There are several ways for the administration of the LT-700 Router (the specified IP addresses are valid only if the appropriate settings have not been changed): LT-700 The LT-700 Router administration can be done directly via the user interface of the LT-700. -
Page 16: Login
CONFIGURATIONS MANAGER _____________________________________________ Login The authorization is made with the password "1478963". On the following pages is a rough outline of where to find what settings. ____________________________________________________________________ aitronic... -
Page 17: Status
CONFIGURATIONS MANAGER _____________________________________________ Status Overview About respectively status of system, memory, network, DHCP / DHCPv6 leases, wireless and associated stations Firewall IPv4 and IPv6 Firewall Status Routes ARP Table and active IPv4 and IPv6 routes System Log System Log Kernel Log Kernel Log Processes Overview of the active system processes and their states... -
Page 18: System
CONFIGURATIONS MANAGER _____________________________________________ System System Settings of hostname, time zone, time synchronization, and logging Administration Router Password and SSH Access Software Configuration, installed and available packages, download and installation of packages Startup Enable/disable of installed init scripts Scheduled Tasks Definition of scheduled tasks LED Configuration Customizing the behavior of the device LED’s Backup / Flash Backup / Restore configuration files, reset to default, flashing... -
Page 19: Network
CONFIGURATIONS MANAGER _____________________________________________ Network Interfaces Overview of the interfaces LAN, WAN, WLAN, global network options Wifi Wireless overview, associated stations. Switch Virtual Local Area Network Settings (VLAN). DHCP and DNS DHCP and DNS settings Hostnames Definition of host names and IP addresses Static Routes Routes specify via which interface and gateway a certain host or network can be reached... -
Page 20: Factory Default
SSID: „hostname-xxxxxx“ (hostname is „lt-700“, xxxxxx are the last 6 digits of the MAC address of the WAN interfaces and are only added automatically when the host name is „lt-700“) Password: „aitronic“... -
Page 21: Resetting To Factory Default State
The LT-700 can be reset to its factory default state either by pressing the reset button for more than 10 seconds or by using the "Reset to defaults" in the LT-700 Router Administration under Backup→System Flash Firmware. In the browser "System - Erasing ... -
Page 22: Setting Up Wi-Fi Wireless (Wwan)
Setting up Wi-Fi Wireless (WWAN) By default Wifi is operated in master mode. If Internet access should take place via Wi-Fi, Wi-Fi has to be set up as described in the LT-700 Router Administration as follows. There are 2 alternative ways:... -
Page 23: Main Operating Modes
192.168.210.210 In LAN Mode the interfaces are split into WAN (Internet) and LAN/WLAN (private subnet). LAN port #0 is assigned to the WAN interface. The LT-700 Router periodically sends broadcast packets to the LAN/WLAN subnet and maintains connection with the stations. -
Page 24: Wlan Mode
In WLAN Mode the WLAN port is used as WAN port and all Ethernet ports are used as LAN ports. After completion of this setting, the LT-700 Router connects in the future after a re-boot automatically with the wireless router. Devices that are connected via LAN ports, assigned a private IP. -
Page 25: Services And Programs
Services and Programs ____________________________________________________ Services and Programs MDE (ai-mde) Output Program Version: # /usr/local/aitronic ai-mde --version Program Start Automatically, please refer: /etc/init.d/ai-mde Manually: etc/init.d/ai-mde [start,stop,restart] Optional: # /usr/local/aitronic ai-mde [--remotehost={uri}] [-- tcpport={port} –debug={dbg}] Server IP address Server configuration port port Debug Output none = aus file = /var/log/aimde.log... -
Page 26: Csv
Services and Programs ____________________________________________________ dd.mm.yyyy hh:nn:ss;1;00000000<CR/LF> NONE dd.mm.yyyy hh:nn:ss 00000000<CRLF> Offline Data Storage If no connection to a server is possible, the MDE data will be stored in the file /var/spool/ai-mde. Once a successful connection is made, the data will be transmitted and deleted the spool file. -
Page 27: Configuration
Services and Programs ____________________________________________________ The program reads the parameters from the configuration file /etc/aitronic/ai-dnc.conf. The parameters can be edited in the web interface (refer to Configuration via web interface). Configuration Open Data Port <?xml version="1.0" encoding="utf-8"?> <ai-dnc> <config> <tcpaddr>192.168.0.108</tcpaddr> <tcpport>8757</tcpport> <port>/dev/ttySAC1</port>... -
Page 28: Debug Control
Services and Programs ____________________________________________________ Debug Control <?xml version="1.0" encoding="utf-8"?> <ai-dnc> <config> <debug>{option}</debug> </config> {option} none = debug output disabled. stdout = output via standard terminal. /Path/FileName = output to log file. Heartbeat Control <?xml version="1.0" encoding="utf-8"?> <ai-dnc> <config> <heartbeat>{zeit}</heartbeat> </config> {zeit} = time in seconds after a <aibridge/>... -
Page 29: Status Query
Services and Programs ____________________________________________________ Status Query <?xml version="1.0" encoding="utf-8"?> <ai-dnc> <cmd> <status/> </cmd> </ai-dnc> Return: Status-Response Return Error/Message <?xml version='1.0' encoding='utf-8'?> <ai-dnc> <err>0</err> <msg>ok</msg> </ai-dnc> Is not a aibridge xml file Failed to parse file ____________________________________________________________________ aitronic... -
Page 30: Return Status
Services and Programs ____________________________________________________ Return Status <?xml version='1.0' encoding='utf-8'?> <ai-dnc <err>0</err <msg>ok</msg <stat>3</stat <status>ConnectedState - A connection is established</status <trans>0</trans> </ai-dnc> trans Number of bytes transferred stat Status: 0 - UnconnectedState - The socket is not connected 1 - HostLookupState - The socket is performing a host name lookup 2 - ConnectingState - The socket has started establishing a connection 3 - ConnectedState - A connection is established 4 - BoundState - The socket is bound to an address and port (for servers) -
Page 31: Firmware Update Of The Lt-700
Firmware Update of the LT-700 By means of Firmware Image from SD Card Save settings in backup file. Plug in SD card with the firmware image. Press boot button Bot while switching on the LT-700. Upload settings from backup file. ____________________________________________________________________ aitronic... -
Page 32: Default Port Configuration
Eliminating Errors _________________________________________________________ Default Port Configuration Serielle Port MDE Interface RS-232 Baud Rate 115.200 Bd Data Bits Parity None Stop Bits Flow Control None Serieller Port DNC Interface RS-232 Baud Rate 115.200 Bd Data Bits Parity None Stop Bits Flow Control None ____________________________________________________________________ aitronic... -
Page 33: Eliminating Errors
Eliminating Errors _________________________________________________________ Eliminating Errors Symptom Mögliche Ursache WAN status contains no IP address. There can be no DHCP server achieved. ____________________________________________________________________ aitronic... -
Page 34: Technical Data
Technical Data ___________________________________________________________ Technical Data Hardware 1 GHz Samsung S5PV210 with PowerVR SGX540 Graphics Controller Memory 512 MB SLC NAND Flash, 512 MB DDR2 RAM Display Resistive LCD Touch Screen, diagonal: 4,3 inch, resolution: 480 x 272 Keyboard 20 keys (T9 text entry), 5 function keys Interfaces 2 x RS-232, 2 x USB/Client, 1x USB/Host, 2 x Ethernet (10/100 Mbps, 1,5 KV isolation)
